Dumbbell Specimen Cutter ZKY-II

Overview

The Dumbbell Specimen Cutter ZKY-II is a precision mechanical cutting system engineered for the standardized preparation of tensile test specimens from non-metallic sheet materials—primarily polymers, elastomers, composites, and thermoplastics. It operates on the principle of guided template-based milling, utilizing interchangeable standardized cutting templates (dies) to ensure strict compliance with dimensional tolerances defined in international mechanical testing standards. The device is specifically designed to produce Type I and Type II dumbbell-shaped specimens as specified in GB/T 1040.2–2022 (equivalent to ISO 527-2:2012), enabling direct compatibility with universal testing machines used in quality control laboratories, R&D centers, and third-party certification facilities. Its rigid cast-iron base, linearly constrained worktable, and fixed-spindle high-torque motor deliver consistent cut geometry across repeated operations—critical for achieving high inter-laboratory reproducibility in tensile property evaluation.

Key Features

• Template-guided cutting architecture ensures repeatable specimen geometry without manual layout or freehand machining.
• Interchangeable standard templates (Type I included; Type II available as optional accessory) conform precisely to GB/T 1040.2 and ISO 527-2 specimen outlines.
• 28 mm diameter hardened steel cutting tool mounted on a fixed-position, belt-driven spindle provides stable rotational speed and minimal deflection during feed.
• ±0.2 mm dimensional accuracy across all critical specimen features—including gauge width, shoulder radius, and parallel section length—verified per ISO/IEC 17025 calibration protocols.
• Robust 450 × 320 mm aluminum alloy worktable with T-slot configuration allows secure clamping of specimens up to 15 mm thick using standard C-clamps or vacuum fixtures (not supplied).
• Integrated safety guard with interlocked power cutoff prevents operation when access panel is open, meeting basic CE machinery directive requirements (2006/42/EC) for guarded stationary equipment.

Sample Compatibility & Compliance

The ZKY-II accommodates flat sheet specimens ranging from 1 mm to 15 mm in thickness, including rigid PVC, polyethylene (PE), polypropylene (PP), ABS, silicone rubber, fiber-reinforced laminates, and foamed polymer substrates. Specimens must exhibit sufficient structural integrity to withstand lateral shear forces during cutting without delamination or edge chipping. The system complies with specimen geometry requirements in GB/T 1040.2–2022, ISO 527-2:2012, and ASTM D638–23 (Type I and Type IV geometries achievable with appropriate template sets). While not certified to ISO 17025 itself, the cutter supports GLP-compliant workflows when integrated into laboratory quality management systems that include documented maintenance logs, operator training records, and periodic verification using traceable gauge blocks.

Software & Data Management

The ZKY-II is a fully mechanical, non-programmable instrument with no embedded firmware, touchscreen interface, or digital connectivity. All operational parameters—including feed rate, depth of cut, and template selection—are manually controlled by the operator. This design eliminates software validation requirements under FDA 21 CFR Part 11 and simplifies qualification for GMP environments where electronic record integrity is mandated. Maintenance and calibration records—including date of last template wear inspection, spindle bearing lubrication, and dimensional verification using certified calipers—must be retained per internal SOPs aligned with ISO/IEC 17025 clause 7.7. Optional accessories (e.g., Type II template set) are assigned unique inventory IDs for traceability within LIMS or QMS platforms.

Applications

• Preparation of tensile specimens for mechanical characterization in polymer manufacturing QA/QC labs.
• Routine specimen fabrication prior to testing per ISO 527, ASTM D638, or GB/T 1040 series standards.
• Supporting accreditation audits (e.g., CNAS, A2LA) requiring documented specimen preparation consistency.
• Educational use in materials science laboratories for hands-on instruction in standardized mechanical testing protocols.
• Research applications requiring rapid generation of geometrically identical specimens for comparative stress–strain analysis.

FAQ

Is the ZKY-II compatible with ISO 527-2 Type IA or Type V specimens?
No—the standard configuration supports only Type I and Type II geometries per GB/T 1040.2. Custom templates for other ISO or ASTM types are not available from the original equipment manufacturer.
Does the machine require compressed air or coolant supply?
No—it operates solely on 220 V AC power and does not incorporate pneumatic or liquid cooling systems.
Can the ZKY-II cut metal sheets?
No—it is explicitly designed for non-metallic materials. Attempting to cut metals may damage the cutting tool and compromise dimensional accuracy.
What maintenance schedule is recommended?
Spindle bearings should be lubricated every 200 operating hours; cutting tools require visual inspection for edge wear before each batch; worktable surfaces must be cleaned and deburred after every use to prevent accumulation of polymer residue.
Is metrological calibration provided with delivery?
A factory-issued dimensional verification report (using NIST-traceable calipers) is included, but full ISO/IEC 17025 calibration must be performed onsite by an accredited provider prior to first use.
