FARO Quantum FaroArm Portable Coordinate Measuring Machine (CMM) Rental Service
| Brand | FARO |
|---|---|
| Origin | Switzerland |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Quantum FaroArm |
| Instrument Type | Portable Articulated Arm CMM |
| Rental Mode | Daily Rental |
| Rental Duration | Day(s) |
| Rental Fee | USD 400/day |
| Deposit | USD 0 |
| Lead Time | 7 Business Days |
| Payment Terms | 100% T/T in Advance |
Overview
The FARO Quantum FaroArm is a high-precision, portable articulated coordinate measuring machine engineered for metrology-grade dimensional verification in dynamic industrial environments. Based on the principle of kinematic linkage with six degrees of freedom (6-DOF), the system employs high-resolution absolute encoders at each joint and a patented internal temperature-compensated inertial measurement unit (IMU) to deliver traceable, ISO 10360-compliant spatial accuracy. Designed for field-deployable metrology, it eliminates the constraints of fixed-floor CMMs while maintaining repeatability within ±0.018 mm volumetric length error (VLE) across its standard 1.2–3.7 m measurement envelope — scalable via modular arm extensions. Its carbon-fiber composite construction ensures structural rigidity and thermal stability under ambient fluctuations typical of shop-floor or aerospace hangar conditions.
Key Features
- Lightweight architecture: Weighing approximately 9 kg, the Quantum FaroArm enables rapid deployment and single-operator handling without auxiliary support structures.
- Patented internal balancing mechanism: Ensures neutral torque across all joint configurations, enabling stable, fatigue-free operation at any orientation — including overhead, inverted, or confined-space positions.
- Integrated environmental compensation: Built-in temperature and humidity sensors feed real-time corrections to the firmware, sustaining metrological integrity per ISO 10360-2 across 10–40 °C operating ranges.
- Hot-swappable USB 3.0 interface: Supports plug-and-play connectivity with Windows-based host systems; no driver reinstallation required during field reconnection.
- Rechargeable lithium-ion battery: Delivers up to 7 hours of continuous measurement runtime, certified to UL 2054 and IEC 62133 standards for safe on-site operation.
- Multi-modal probe compatibility: Supports tactile probing (standard sphere/cone calibration in <60 seconds), laser line scanners, and photogrammetric targets — all managed within a unified CAM2 Measure software environment.
Sample Compatibility & Compliance
The Quantum FaroArm is validated for dimensional inspection of metallic and non-metallic components with surface finishes ranging from matte cast iron to polished aluminum alloys. It complies with ASTM E1316 (Standard Terminology for Nondestructive Examinations), ISO 17025:2017 (General requirements for the competence of testing and calibration laboratories), and supports audit-ready documentation per FDA 21 CFR Part 11 when deployed with CAM2’s electronic signature and audit trail modules. All rental units undergo pre-delivery calibration per ISO/IEC 17025-accredited procedures, with full traceability to NIST standards documented in the Certificate of Calibration.
Software & Data Management
CAM2 Measure v6.x serves as the native metrology platform, providing GD&T evaluation (ASME Y14.5–2018 and ISO 1101), CAD-to-part deviation mapping, SPC statistical reporting (X-bar/R, Cp/Cpk), and automated report generation in PDF, Excel, and XML formats. The software supports offline programming via CAD import (STEP, IGES, Parasolid), enabling measurement sequence development prior to site arrival. For long-term lease agreements, optional CAM2 SmartInspect integration enables centralized fleet monitoring, usage analytics, and preventive maintenance scheduling aligned with ISO 55001 asset management frameworks.
Applications
- Automotive: Body-in-white (BIW) dimensional analysis, fixture validation, stamping die wear assessment, and subassembly gap/flushness verification.
- Aerospace: Turbine blade profile scanning, wing spar alignment checks, and composite layup conformity verification against digital twin models.
- Energy: Steam turbine rotor geometry inspection, pipe spool dimensional compliance (ASME B31.1/B31.3), and weld joint contour analysis.
- Industrial machinery: Large-scale gear housing flatness evaluation, hydraulic cylinder bore concentricity, and custom jig & fixture certification.
- Reverse engineering: High-density point cloud acquisition for legacy part digitization, with direct export to SOLIDWORKS, NX, and CATIA for parametric reconstruction.
FAQ
What calibration documentation accompanies each rental unit?
Each Quantum FaroArm is shipped with a full ISO/IEC 17025-accredited calibration certificate, including uncertainty budgets, encoder linearity verification, and thermal drift test records — all traceable to NIST SRM 2036.
Is on-site operator training included in the rental agreement?
Yes — standard daily rentals include 2 hours of remote or on-site application-specific instruction by a FARO-certified metrologist. Extended leases include quarterly refresher sessions and competency assessments.
Can the system be used in uncontrolled environmental conditions?
The integrated environmental compensation engine maintains specified accuracy across 10–40 °C and 20–80% RH. For extreme conditions (>40 °C or <10 °C), optional external thermal shielding kits are available upon request.
Are measurement data files compatible with enterprise PLM systems?
CAM2 exports native .cmm and .xml formats fully interoperable with Teamcenter, Windchill, and 3DEXPERIENCE platforms via standardized AP242 STEP schemas.
What happens if hardware requires service during the rental period?
A replacement unit is dispatched within 24 business hours under our SLA-backed support agreement; all diagnostic logs and firmware versions are archived for root-cause analysis and regulatory review.
