Julabo FC1600 Circulating Chiller

Overview

The Julabo FC1600 Circulating Chiller is a high-precision, integrated temperature control system engineered for demanding laboratory and pilot-scale applications requiring stable, continuous cooling—and simultaneous heating—across a wide thermal range. Based on vapor-compression refrigeration with a single-stage hermetic compressor and R134a refrigerant, the FC1600 delivers precise thermal management via forced liquid circulation through external equipment such as rotary evaporators, spectrophotometers, calorimeters, or reactor jackets. Its design eliminates reliance on municipal tap water for cooling—reducing water consumption, minimizing thermal drift from fluctuating supply temperatures, and enabling operation in locations where chilled water infrastructure is unavailable. The unit operates continuously under ambient conditions of 5–40 °C and maintains setpoint stability within ±0.2 °C across its full operating range of −20 to +80 °C, with programmable inlet/outlet temperature differentials and real-time dual LED display of both bath and process temperatures.

Key Features

• Integrated heating and cooling capability: 1.2 kW electric heater enables seamless transition between sub-zero and elevated temperatures without external auxiliary units.
• Air-cooled condensation system with low-noise fan architecture (≤53 dB[A]) ensures reliable operation in standard laboratory environments without dedicated ventilation ducting.
• High-flow, pressure-stable circulation pump (20 L/min at 0.5 bar) supports long fluid paths and multi-instrument distribution networks.
• Dual independent LED displays show both reservoir temperature and user-defined process temperature (e.g., outlet or external Pt100 sensor reading), enhancing operational transparency.
• Top-fill reservoir with visual level indicator and ergonomic access simplifies maintenance and minimizes spill risk during refilling.
• RS232 serial interface enables integration into centralized lab automation systems for remote parameter setting, data logging, and event-triggered control sequences.
• Configurable temperature differential mode allows users to define fixed offsets between inlet and outlet temperatures—critical for maintaining consistent heat exchange rates in jacketed reactors or condensers.
• Compliant with IEC 61000-6-3 (EMC emission standards) and IEC 61000-6-2 (immunity), ensuring electromagnetic compatibility in electromagnetically dense lab environments.

Sample Compatibility & Compliance

The FC1600 is compatible with aqueous and water-glycol mixtures (up to 30% v/v ethylene or propylene glycol), supporting corrosion-resistant circulation loops when paired with stainless steel or fluoropolymer-lined external systems. It meets essential safety and environmental requirements including CE marking per EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU. Refrigerant handling complies with F-Gas Regulation (EU) No. 517/2014, and R134a charge (380 g) falls below thresholds requiring certified technician intervention for servicing. While not intrinsically rated for hazardous area use, the unit may be deployed in general-purpose laboratories adhering to ISO/IEC 17025:2017 quality management principles for temperature-controlled testing environments.

Software & Data Management

The built-in RS232 interface supports ASCII command protocol for bidirectional communication with third-party software platforms—including LabVIEW, MATLAB, or custom SCADA systems—for automated temperature ramping, alarm triggering, and time-stamped data capture. Optional Julabo software packages (e.g., WinTemp Pro) provide graphical trend analysis, audit-trail-enabled parameter change logs, and export to CSV or PDF formats—facilitating compliance with GLP and FDA 21 CFR Part 11 requirements when configured with user authentication and electronic signature modules. All temperature setpoints, stability deviations, and pump status events are timestamped and retained in non-volatile memory for post-run forensic review.

Applications

• Condenser cooling in rotary evaporation systems to maximize solvent recovery efficiency and prevent bumping under vacuum.
• Temperature stabilization of NMR probe preamplifiers and cryogen-free magnet cooling circuits.
• Thermal conditioning of photovoltaic cell test chambers and LED aging racks.
• Process temperature control in small-scale chemical synthesis reactors (≤5 L volume) with jacketed vessels.
• Calibration support for thermocouple and RTD reference baths requiring traceable, stable thermal sinks.
• Environmental stress screening of electronic components using controlled thermal cycling profiles.

FAQ

What is the maximum allowable return fluid temperature when using the FC1600 with an external reactor jacket?
The unit accepts return fluid up to 80 °C; however, sustained operation above 60 °C reduces refrigeration efficiency and accelerates thermal degradation of silicone-based heat transfer fluids.
Can the FC1600 maintain ±0.05 °C stability for extended periods?
No—the specified temperature stability is ±0.2 °C under steady-state conditions per DIN 12876-1; tighter tolerances require active external feedback control via the Pt100 input port.
Is R134a compatible with all common heat transfer fluids?
R134a is chemically inert toward water, ethylene glycol, and propylene glycol solutions; avoid chlorinated solvents or hydrocarbon-based oils due to seal compatibility risks.
Does the FC1600 support Modbus or Ethernet connectivity?
No—only RS232 is natively supported; industrial protocol conversion requires an external serial-to-Modbus gateway.
What maintenance intervals are recommended for optimal long-term performance?
Inspect air filter monthly; clean condenser coils quarterly; verify refrigerant charge and compressor oil integrity annually by authorized Julabo service personnel.
