Kanomax 6006 Hot-Wire Anemometer

Overview

The Kanomax 6006 Hot-Wire Anemometer is a compact, handheld environmental monitoring instrument engineered for reliable and repeatable measurement of low-to-moderate air velocity in laboratory, HVAC, cleanroom, industrial hygiene, and field-based applications. It operates on the principle of constant-temperature anemometry (CTA), where a fine platinum-coated tungsten wire is electrically heated to a fixed temperature above ambient; convective heat loss from the sensor is directly correlated to local airflow velocity. This thermally responsive design enables high sensitivity at low wind speeds (down to 0.01 m/s), making the 6006 particularly suitable for laminar flow verification, duct traverse surveys, fume hood face velocity validation, and ventilation system commissioning. Its integrated temperature sensor—calibrated across −20 °C to +70 °C—features active thermal compensation circuitry that maintains measurement stability within ±5% of reading across its full operational range, with optimal accuracy (±3% of reading) achieved between 10 °C and 40 °C per internal calibration traceability.

Key Features

• Single-button operation interface for streamlined data acquisition, zeroing, unit switching (m/s, ft/min, knots), and hold function activation—minimizing user error during field use.
• Interchangeable probe design compliant with Kanomax’s standardized sensor interface; allows field replacement without recalibration when using certified replacement probes (e.g., 6006-P series).
• Rugged, ergonomic housing (60 × 120 × 34 mm; 180 g) constructed from impact-resistant ABS polymer with IP54-rated ingress protection against dust and water splashes.
• Onboard temperature compensation circuitry ensures consistent wind speed accuracy across varying ambient conditions—critical for ISO 14644-3 cleanroom airflow qualification and ASHRAE 110 fume hood testing protocols.
• Low-power electronics optimized for extended runtime: up to 120 hours of continuous operation on four standard AA alkaline cells, with automatic power-down after 10 minutes of inactivity.

Sample Compatibility & Compliance

The Kanomax 6006 is compatible with non-corrosive, non-abrasive, particle-free air streams typical of indoor environmental monitoring, HVAC commissioning, and occupational safety assessments. It is not intended for use in explosive atmospheres (ATEX/IECEx), high-humidity condensing environments (>85% RH), or gas mixtures containing solvents, oils, or particulate concentrations exceeding ISO Class 8 (100,000) cleanliness limits. The instrument conforms to IEC 61000-4-2 (ESD immunity), IEC 61000-4-3 (radiated RF immunity), and meets CE marking requirements under the EU Electromagnetic Compatibility Directive 2014/30/EU. Calibration documentation follows ISO/IEC 17025 guidelines, with traceability to JCSS (Japan Calibration Service System) standards. While not FDA 21 CFR Part 11–compliant out-of-the-box, audit-ready calibration logs and user-defined calibration intervals support GLP/GMP-aligned quality systems.

Software & Data Management

The 6006 operates as a standalone instrument with no proprietary software dependency. All measurements are displayed in real time on a high-contrast LCD with backlighting. Data logging is manual—users record values via built-in HOLD and MAX/MIN functions. For integration into structured QA workflows, third-party tools (e.g., Excel-based templates, LabVIEW drivers via RS-232 adapters, or custom Python scripts using serial communication libraries) may be employed to capture timestamped readings. Kanomax provides NIST-traceable calibration certificates upon request, including uncertainty budgets per GUM (Guide to the Expression of Uncertainty in Measurement). Firmware updates are not supported; hardware-level calibration remains fixed per factory certification.

Applications

• HVAC system balancing and duct static pressure correlation studies
• Cleanroom unidirectional airflow mapping per ISO 14644-3 Annex B
• Fume hood face velocity verification per ANSI/ASHRAE 110 and EN 14175
• Industrial hygiene assessments for OSHA 1910.94 and ACGIH TLV® compliance
• Classroom and office indoor air quality (IAQ) baseline surveys
• Validation of laminar flow cabinets and biosafety cabinets (BSCs) during routine maintenance

FAQ

Is the Kanomax 6006 suitable for outdoor wind speed measurement?
No—it is designed for controlled indoor and semi-enclosed environments. Outdoor use exposes the hot-wire sensor to rain, dust, and thermal shock, risking irreversible damage and calibration drift.
Can the 6006 measure volumetric flow rate directly?
No. It measures linear velocity only. Volumetric flow must be calculated manually using cross-sectional area and averaged traverse point velocities per ISO 5167 or ASHRAE Fundamentals Chapter 42.
Does the device support data export or Bluetooth connectivity?
No. The 6006 has no digital interface, memory storage, or wireless capability. All data capture is manual.
What is the recommended recalibration interval?
Kanomax recommends annual recalibration for routine QA use; more frequent calibration (e.g., quarterly) is advised in high-use or regulated environments such as pharmaceutical manufacturing or accredited laboratories.
Is the probe interchangeable with other Kanomax models?
Yes—the 6006 uses Kanomax’s universal probe interface; however, only probes explicitly designated for the 6006 (e.g., 6006-P1, 6006-P2) maintain stated accuracy specifications. Cross-model use voids calibration validity.
