Leica ICC50 HD Microscope Camera

Overview

The Leica ICC50 HD Microscope Camera is a dedicated digital imaging solution engineered for integration with Leica DM series upright microscopes—particularly optimized for the DM500 and DM750 platforms. It employs a high-sensitivity 3.1-megapixel progressive-scan CMOS sensor to deliver real-time, full-HD (1080p-capable) live imaging directly to HDMI monitors or connected PCs without intermediate frame grabbers. Unlike generic USB webcams, the ICC50 HD is optically calibrated to match the conjugate image plane of Leica’s infinity-corrected optical path, minimizing parfocal shift and chromatic aberration during acquisition. Its embedded image processing pipeline applies hardware-accelerated white balance, gamma correction, and noise reduction—ensuring consistent color fidelity across varying illumination conditions (halogen, LED, or transmitted/darkfield). Designed for routine laboratory use, it supports both GLP-compliant documentation workflows and rapid visual assessment in teaching, quality control, and technical service environments.

Key Features

• Native 2048 × 1536 pixel resolution (3.1 MP) CMOS sensor with 12-bit ADC for high dynamic range capture
• Dual-mode operation: standalone HDMI output for immediate viewing on HD displays, or USB 2.0 interface for PC-based acquisition and analysis
• Integrated SD card slot (up to 32 GB, FAT32 formatted) enabling autonomous image/video capture without host computer dependency
• Dedicated hardware controls including programmable function buttons for instant switching between preset illumination modes, exposure compensation, and HDMI/PC mode toggling
• Included infrared remote control supporting live image review, gallery navigation, video clip recording (AVI, MJPEG), and parameter adjustment from benchtop distance
• Firmware-upgradable architecture (v1.62+ required for gallery playback and HDMI metadata overlay)

Sample Compatibility & Compliance

The ICC50 HD is mechanically and optically matched to Leica’s standardized trinocular port interface (23.2 mm or 25 mm diameter), ensuring secure, vibration-damped mounting on DM500/DM750 microscopes without adapter-induced vignetting. It maintains compatibility with standard Köhler illumination configurations—including brightfield, phase contrast, and simple polarized light—though not designed for fluorescence applications requiring high quantum efficiency or low-noise cooling. From a regulatory standpoint, the device complies with EU Directive 2014/30/EU (EMC), 2011/65/EU (RoHS), and carries CE marking under the Low Voltage Directive. While not FDA 510(k)-cleared as a medical device, its design adheres to ISO 13485-aligned quality management practices per Leica Microsystems’ German manufacturing facility (certified to ISO 9001:2015). Data integrity features—including timestamped file naming, EXIF metadata embedding, and audit-ready folder structures—support basic GLP documentation requirements.

Software & Data Management

The ICC50 HD operates natively with Leica Application Suite (LAS) EZ—a lightweight, wizard-driven software package supporting single-image capture, basic annotation (text, arrows, scale bars), and linear/area measurement with calibration import. For advanced workflows, it integrates seamlessly with full-featured LAS X platforms, enabling Z-stack acquisition (multi-focus), region-of-interest (ROI) intensity profiling, and export to TIFF, JPEG, or Leica’s proprietary LIF format. All captured media retain embedded metadata (exposure time, gain, magnification, objective ID, date/time), facilitating traceability in regulated environments. Image archives are organized into dated folders with sequential numbering; SD card contents can be synchronized automatically via LAS EZ’s “Import from Camera” module. No proprietary drivers are required—USB enumeration follows UVC 1.1 standards, enabling plug-and-play compatibility with Windows 10/11 and macOS 12+ systems.

Applications

• Educational microscopy labs: Real-time HD projection for classroom instruction and collaborative observation
• Industrial QC/QA: Rapid visual inspection of solder joints, surface defects, textile weave patterns, or PCB traces using calibrated measurement tools
• Clinical cytology support: Documentation of peripheral blood smears or urine sediments under brightfield or phase contrast (non-diagnostic use)
• Materials science: Monitoring grain structure, coating uniformity, or particle dispersion in metallurgical or polymer samples
• Technical service centers: Remote troubleshooting via HDMI output to wall-mounted displays or streaming to internal networks (via third-party capture cards)

FAQ

Does the ICC50 HD require a computer to operate?
No. It functions fully standalone when connected to an HDMI-compatible display and powered via USB or optional DC adapter.
What is the maximum supported SD card capacity?
32 GB, formatted as FAT32. Cards larger than 32 GB must be partitioned accordingly.
Can I perform measurements directly on the HDMI display?
No—measurement tools are only available within LAS EZ or LAS X software on a connected PC.
Is the camera compatible with non-Leica microscopes?
Mechanical mounting may be possible with third-party C-mount adapters, but optical performance (e.g., field flatness, color accuracy) is not guaranteed outside Leica DM-series integration.
Does firmware update v1.62 enable new hardware capabilities?
No—it unlocks enhanced UI features (SD gallery playback, HDMI overlay options) but does not alter sensor performance or resolution.
