Precise TITAN 35A Nitrogen Generator

Overview

The Precise TITAN 35A Nitrogen Generator is an integrated, on-demand gas supply system engineered for continuous, high-reliability nitrogen production in analytical laboratories, pharmaceutical QC environments, and industrial R&D settings. Utilizing advanced hollow fiber membrane separation technology, the TITAN 35A selectively permeates oxygen, carbon dioxide, water vapor, and other trace gases through semi-permeable polymeric membranes—leaving a purified nitrogen stream with ≥99.9% volumetric purity. Unlike pressure swing adsorption (PSA) systems, membrane-based generation offers inherently stable output without cycling, no consumable adsorbents, and minimal maintenance due to its solid-state architecture and absence of moving parts beyond two precision-engineered oil-free scroll compressors. Designed for seamless integration into sensitive instrumentation—including LC-MS, GC-MS, FTIR, and elemental analyzers—the unit delivers consistent flow (0–35 L/min), regulated pressure (up to 100 psi / 6.9 bar), and ultra-dry nitrogen with a certified dew point of −50 °C—meeting or exceeding ISO 8573-1 Class 2 requirements for compressed air quality in critical applications.

Key Features

• Integrated dual oil-free air compressors eliminate dependency on external compressed air infrastructure—reducing installation complexity and contamination risk.
• Robust hollow fiber membrane module with proprietary surface treatment ensures long-term flux stability and resistance to humidity-induced performance drift.
• Acoustic optimization via multi-layer composite insulation and vibration-dampening mounting yields operational noise ≤54 dB(A) at 1 meter—suitable for open-plan labs and ISO Class 5 cleanroom-adjacent spaces.
• Mobile chassis with industrial-grade casters and locking brakes enables repositioning without tools; footprint optimized for benchtop or floor-standing deployment.
• Intelligent control system with real-time monitoring of inlet pressure, membrane differential pressure, outlet purity (via internal electrochemical sensor), and thermal status—supporting predictive maintenance alerts.
• No liquid phase components or phthalate-containing materials; fully compliant with USP and ICH Q5C guidelines for inert gas use in biopharmaceutical manufacturing.

Sample Compatibility & Compliance

The TITAN 35A is validated for use with nitrogen-sensitive analytical platforms requiring Class 2–3 compressed gas quality per ISO 8573-1. Its output meets ASTM D6349 specifications for carrier and purge gas in chromatographic applications and satisfies FDA 21 CFR Part 11 data integrity prerequisites when paired with optional audit-trail-enabled software modules. The system conforms to UL 61010-1 (Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use) and carries CE marking under the EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU. All wetted materials—including stainless-steel regulators, PTFE-sealed solenoid valves, and fluoropolymer-coated membrane housings—are compatible with ISO 10993-5 cytotoxicity testing protocols.

Software & Data Management

The embedded microcontroller logs all operational parameters—including runtime hours, compressor cycles, pressure differentials, and purity deviations—at 10-second intervals. Data export is supported via USB-C interface in CSV format, enabling traceability for GLP/GMP audits. Optional Ethernet connectivity (TITAN Connect Module) adds remote monitoring, SNMP alerting, and integration with LabVantage or Thermo Fisher SampleManager LIMS via RESTful API. Firmware updates are digitally signed and delivered over secure HTTPS channels, maintaining compliance with NIST SP 800-53 Rev. 5 IA-7 and IR-4 controls.

Applications

• LC-MS and GC-MS mobile phase and collision gas supply—ensuring baseline stability and minimizing ion suppression artifacts.
• Inert blanketing for glove boxes, solvent evaporation stations, and moisture-sensitive synthesis reactors.
• Carrier gas for elemental analyzers (e.g., CHNS/O instruments) where hydrocarbon-free nitrogen is mandatory.
• Purge gas for FTIR spectrometers and optical interferometers requiring low-humidity, particle-free environments.
• Process validation support in pharmaceutical manufacturing, including lyophilizer chamber purging and vial stoppering inertion.
• Calibration gas dilution systems requiring stable, traceable nitrogen base streams.

FAQ

Does the TITAN 35A require external compressed air?
No—it integrates two oil-free scroll compressors and requires only standard AC power (110–240 V, 50 Hz).
Can it support multiple instruments simultaneously?
Yes, provided total demand remains within 35 L/min at ≥100 psi; manifold distribution with calibrated flow restrictors is recommended for multi-port configurations.
What maintenance intervals are required?
Primary scheduled maintenance includes annual inspection of pre-filters and desiccant cartridges; membrane life exceeds 15,000 operating hours under specified ambient conditions.
Is the nitrogen purity verified in real time?
Yes—an integrated electrochemical oxygen sensor provides continuous ppm-level O₂ measurement with automatic alarm thresholds configurable via front-panel interface.
How does altitude affect performance?
The unit is rated for stable operation up to 2000 meters above sea level; flow and purity specifications assume inlet air density correction per ISO 8573 Annex B.
