Shimadzu GCMS-QP2010 Used Gas Chromatograph-Mass Spectrometer System

Overview

The Shimadzu GCMS-QP2010 is a high-performance, single-quadrupole gas chromatography–mass spectrometry (GC-MS) system engineered for precise qualitative and quantitative analysis of volatile and semi-volatile organic compounds. Built on Shimadzu’s proven GC-2010 gas chromatograph platform and coupled with the QP2010 mass spectrometer, this refurbished instrument delivers robust separation efficiency, high mass accuracy, and reliable ion detection across a wide dynamic range (m/z 1.5–1090). Its core measurement principle relies on electron ionization (EI) followed by mass filtering via a temperature-stabilized quadrupole mass analyzer, with real-time data acquisition synchronized to chromatographic elution profiles. Designed for laboratory environments requiring regulatory-compliant workflows—particularly in environmental testing, food safety screening, forensic toxicology, and pharmaceutical impurity profiling—the GCMS-QP2010 supports method development aligned with ISO/IEC 17025 accreditation requirements and provides traceable performance under GLP and GMP-aligned operational protocols.

Key Features

• High-speed scanning capability at up to 20,000 atomic mass units per second (u/sec), enabling full-spectrum acquisition during narrow peak elution in fast GC gradients.
• Advanced Scanning Speed Protocol (ASSP) algorithm, which dynamically optimizes detector gain and dwell time to maintain signal-to-noise ratio during rapid scan cycles.
• Integrated AOC-20i autosampler with AOC-20s 100-position sample tray, supporting unattended batch analysis with programmable injection volume, solvent wash, and syringe purge routines.
• Capillary column inlet with electronic pressure control (EPC), ensuring reproducible carrier gas flow and retention time stability across multi-day sequences.
• Energy-efficient design: standby power consumption reduced by 36% versus prior-generation systems; associated CO₂ emissions lowered by 30% over equivalent operational hours.
• Modular vacuum system featuring dual-stage rotary vane pump, optimized for stable ion source pressure (10⁻⁵ Pa range) and extended maintenance intervals.

Sample Compatibility & Compliance

The GCMS-QP2010 accommodates standard 0.25–0.53 mm ID fused-silica capillary columns (e.g., DB-5ms, HP-5MS, Rtx-5Sil MS) and accepts liquid, solid (via thermal desorption or solvent extraction), and gaseous samples following appropriate preparation. It meets instrumental performance criteria outlined in ASTM D5845 (determination of oxygenates in gasoline), EPA Method 8270D (semivolatile organics), and EU Directive 2002/65/EC for pesticide residue analysis. While not supplied with factory calibration certificates, the system has undergone functional verification—including tune report generation, mass axis calibration, and sensitivity verification using decafluorotriphenylphosphine (DFTPP)—prior to refurbishment and is delivered with documented test results consistent with ISO/IEC 17025 Clause 6.5.2 (verification of equipment fitness for purpose).

Software & Data Management

Controlled exclusively via Shimadzu LabSolutions GCMS software (version 5.x or later), the system supports full method development, real-time spectral monitoring, library search (NIST, Wiley, and custom libraries), quantitative calibration curve generation (linear, quadratic, weighted least squares), and audit-trail-enabled data review. LabSolutions complies with FDA 21 CFR Part 11 requirements when deployed with validated user access controls, electronic signatures, and immutable audit logs—features configurable during site-specific IT validation. Raw data (.qgd files) and processed reports are exportable in CSV, PDF, and XML formats for LIMS integration. All software licenses are transferable upon purchase; no dongle or activation lock is present.

Applications

• Environmental analysis: PAHs, PCBs, organochlorine pesticides, and phthalate esters in soil, water, and air matrices.
• Food and beverage testing: mycotoxins, flavor compounds, adulterants, and packaging migrants.
• Pharmaceutical QC: residual solvents (ICH Q3C), genotoxic impurities, and extractables/leachables profiling.
• Forensic chemistry: drug metabolites, synthetic cannabinoids, and novel psychoactive substances in biological fluids.
• Materials science: volatile decomposition products from polymers, adhesives, and coatings.

FAQ

Is this instrument fully refurbished and tested before shipment?
Yes. Each GCMS-QP2010 undergoes comprehensive functional verification at SpectraLab Scientific’s ISO 9001-certified refurbishment facility, including vacuum integrity checks, mass calibration, sensitivity assessment, and chromatographic resolution testing using certified reference standards.
Does the system include original Shimadzu documentation and software media?
All units ship with digital copies of the GCMS-QP2010 Operation Manual, LabSolutions User Guide, and preventive maintenance checklist. Physical media is not included; software is pre-installed and licensed for immediate use.
Can this system be integrated into an existing LIMS environment?
Yes. LabSolutions supports ODBC-compliant database export and structured data output compatible with major LIMS platforms (e.g., Thermo Fisher SampleManager, LabVantage, STARLIMS) via standardized file formats and configurable export templates.
What consumables and spare parts are recommended for initial operation?
Recommended first-use inventory includes: GC column (e.g., 30 m × 0.25 mm × 0.25 µm DB-5ms), inlet liner (glass wool-packed, deactivated), septa (11 mm, high-temp), gold-plated ferrules, DFTPP tuning standard, and pump oil for the rotary vane vacuum pump.
Is remote technical support available post-purchase?
Yes. SpectraLab Scientific provides 90 days of complimentary remote diagnostics and application troubleshooting via secure screen-sharing and log-file analysis, staffed by ASE-certified GC-MS specialists with ≥10 years’ field experience.
