| Brand | BATOP |
|---|---|
| Origin | Germany |
| Model | PCA- |
| Wavelength Options | 800 nm / 1064 nm / 1550 nm |
| Antenna Types | Bow-tie, Parallel-line, Butterfly, Interdigital Array, Finger-gap, Logarithmic Spiral |
| Lens Options | Aspheric Silicon Lenses (Collimating or Focusing) |
| Compliance | RoHS-compliant semiconductor fabrication |
| Packaging | Hermetically sealed, anti-reflection coated Si substrate housing |
| Brand | Batop |
|---|---|
| Origin | Germany |
| Model | TDS10XX |
| Spectral Range | 0.05–4 THz (laser-dependent) |
| Spectral Resolution | 2 GHz (equivalent to ~0.025 cm⁻¹) |
| Imaging Resolution | 1280 × 1024 pixels |
| Field of View (TFOV) | 8° |
| Instantaneous Field of View (IFOV) | 0.18 mrad |
| Frame Rate | 15 fps |
| Beam Diameter | 22 mm (collimated), 1 mm @ 1 THz (focused) |
| Sample Size Support | up to 30 × 30 mm (collimated), ≥5 × 5 mm (focused) |
| Dynamic Range | >65–75 dB |
| Scan Range | 500–650 ps |
| THz Pulse Repetition Rate | 1–30 kHz (10 kHz default) |
| Bias Voltage for PCA Emitter | 10 V |
| Operating Mode | Free-space or fiber-coupled (1550 nm / 1060 nm options) |
| Environmental Compatibility | N₂-purged sample chamber |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | CrF-65 |
| Laser Type | Solid-State CW Tunable Laser |
| Gain Medium | Cr⁴⁺:Mg₂SiO₄ (Chromium-doped Forsterite) |
| Tuning Range | 1210–1290 nm |
| Output Power | Up to 400 mW (typ.) |
| Spatial Mode | TEM₀₀ |
| Spectral Bandwidth | ≤10 cm⁻¹ (FWHM) |
| Pump Source | Diode-pumped, 1064 nm or 1342 nm Nd:YVO₄/Nd:YAG laser (requires external pump, up to 10 W) |
| Beam Diameter (1/e²) | ~0.8 mm |
| Beam Divergence (full angle) | <1.5 mrad |
| Polarization | Linear, >100:1 |
| Cooling | Water-cooled (recommended for stable CW operation) |
| Compliance | CE-marked, RoHS-compliant |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | PErL |
| Wavelength Range | 1530–1565 nm (C-band) |
| Pulse Width | 250 fs – 5 ps (fixed options) |
| Average Output Power | up to 50 mW |
| Repetition Rate | RF-synchronized output |
| Power Supply | +5 V DC (with included 110/220 V AC adapter) |
| Package Type | OEM-integrated compact module |
| Compliance | CE-marked, RoHS-compliant |
| Pulse Shape | Near-transform-limited |
| Timing Jitter | < 50 fs RMS (integrated from 10 kHz to 10 MHz) |
| Phase Noise | Low time-variant optical phase noise |
| Pulse Baseline | Suppressed residual pedestal (< 1% of peak intensity) |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | EFO |
| Wavelength | 1560 ± 10 nm |
| Pulse Width | <80 fs (EFO-80/10), 250–5000 fs (EFO-T/50), 100–250 fs (EFOA-T/P) |
| Average Output Power | 10 mW (EFO-80/10), 50 mW (EFO-T/50), 100–250 mW (EFOA-T/P) |
| Repetition Rate | 70 MHz (EFO-80/10), 25–80 MHz (EFO-T/50), 70 MHz (40–80 MHz optional for EFOA) |
| Polarization | Linear, Vertical or Horizontal (EFO-80/10), Horizontal (EFO-T/50, EFOA) |
| Spatial Mode | TEM₀₀ |
| Output Coupling | FC/APC fiber port (~1 mW service tap), optional free-space or polarization-maintaining fiber |
| RF Sync Output | SMA connector (200–300 mV into 50 Ω) |
| Lock Status Monitor | SMA (3.5 V / 0 V) + LED indicator |
| Laser Head Dimensions (L×W×H) | 108×210×50 mm (70 mm height with baseplate) for EFO-80/10 |
| Power Supply Dimensions | 230×200×85 mm (EFO-80/10, EFO-T/50), 230×200×130 mm (EFOA) |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | TiC |
| Core Type | Solid-State CW Laser Oscillator |
| Pumping Requirement | 532 nm CW DPSS or Argon-Ion Laser |
| Tuning Mechanism | Manual Birefringent Filter or Motorized USB-Controlled Filter Drive |
| Optional Intracavity Etalons | Single or Dual for Linewidth Narrowing |
| Output Options | Free-Space TEM₀₀ Beam or Fiber-Coupled (SM, FC/FC, 1 m, 4 µm Core) |
| Power Range (Oscillator Only) | ≥1.5 W @ 800 nm (5 W Pump) |
| Fiber-Coupled Power | ≥400 mW @ 800 nm |
| Linewidth | <45 GHz (free-running), <20 GHz (with one etalon), <2 GHz (with two etalons) |
| Beam Divergence | <2 mrad |
| Polarization | Linear, >100:1 (free-space output, 5 W pump) |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | TiF-100 |
| Configuration Options | TiF-100 (external pump) / TiF-100F (integrated industrial pump laser) |
| Tuning Range | 715–980 nm |
| Pulse Width | <100 fs |
| Avg. Output Power | up to 1.5 W (@ 10 W pump) |
| Repetition Rate | 80 MHz |
| Beam Quality | TEM₀₀ |
| Polarization | Linear, horizontal |
| Beam Divergence | <1 mrad |
| Power Stability | <1% RMS |
| Control Interface | USB-driven motorized wavelength tuning |
| Optional Features | Birefringent filter, etalon, prism pair or APC for dispersion pre-compensation |
| Dimensions | 610 × 450 × 197 mm |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | TiF-15 |
| Type | Solid-State Femtosecond Oscillator |
| Tuning Range | 760–840 nm |
| Pulse Width (factory-configured) | <15 fs (TiF-15), <30 fs (TiF-15F) |
| Avg. Output Power | up to 500 mW @ 6 W pump |
| Repetition Rate | 90 MHz (TiF-15), 80 MHz (TiF-15F) |
| Pump Power Max | 6 W |
| Beam Quality | TEM₀₀ |
| Polarization | Linear, horizontal |
| Beam Divergence | <1 mrad |
| Power Stability | <1% RMS |
| Control Interface | USB |
| GDD Compensation Support | Yes (external prism pair or tunable compressor compatible) |
| Dimensions | 650 × 330 × 128 mm |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Manufacturer Type | Authorized Distributor |
| Product Category | Imported |
| Model | ANTAUS |
| Core Architecture | All-Fiber Oscillator + Amplifier with Free-Space Pulse Compressor |
| Pulse Energy | > 2 µJ |
| Average Output Power | > 5 W |
| Pulse Duration (FWHM) | < 350 fs |
| Repetition Rate | 2.5 MHz (standard), adjustable down to single-shot via optional AO pulse picker |
| Wavelength Options | 1030 nm, 1040 nm, or 1050 nm (custom wavelengths available) |
| Spatial Mode | TEM₀₀ |
| Polarization | Linear, horizontal |
| Beam Quality (M²) | < 1.2 |
| Long-Term Power Stability (12 h) | < 1% RMS |
| Cooling | Air-cooled only (no water cooling required) |
| Footprint (Optics Unit) | 350 × 220 × 120 mm |
| Footprint (Power Supply Unit) | 470 × 385 × 155 mm |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | EFOA-SH |
| Wavelength | 780 ± 5 nm (SH) / 1560 ± 10 nm (Fundamental) |
| Pulse Width (FWHM) | <100 fs |
| Average Power | >140 mW @ 780 nm |
| Repetition Rate | 65 ± 5 MHz or 80 ± 5 MHz |
| Spectral Bandwidth | ~7.5 nm |
| Pulse Energy | 1.1 nJ |
| Output Beam | TEM₀₀, Linearly Polarized |
| RF Sync Output | SMA |
| Mode-Lock Status Indicator | SMA + LED |
| Operating Temperature | 22 ± 5 °C |
| Warm-up Time | 20 min |
| Power Supply | 110/220 VAC, 50/60 Hz |
| Laser Head Dimensions | 278 × 242 × 111 mm |
| Control Unit Dimensions | 291 × 202 × 134 mm |
| Crystal Oven Controller Dimensions | 160 × 200 × 75 mm |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Manufacturer Type | Authorized Distributor |
| Product Category | Imported |
| Model | TiF-Kit |
| Core Components | Solid-State Laser System Components |
| Pump Source | 532 nm DPSS Laser |
| Pulse Duration | <15–100 fs (model-dependent) |
| Tuning Range | 715–980 nm (TiF-Kit-100) |
| Avg. Output Power | Up to 1.5 W |
| Repetition Rate | 70–95 MHz (fixed cavity) |
| Polarization | Linear, Horizontal |
| Spatial Mode | TEM₀₀ |
| Max. Pump Power | 2–15 W (model-dependent) |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | OG8/1 |
| Wavelength Range | 250–2100 nm |
| Max. Output Voltage | 12 kV |
| Repetition Rate (Input) | Up to 150 MHz |
| Pulse Selection Mode | Single-shot to 100 kHz |
| Rise Time | ≤700 ps |
| Jitter | <200 ps |
| Gate Width (HV Pulse Duration) | Adjustable up to 1250 ns |
| Synchronization Input | Optical or Electrical |
| Delay Adjustment Range | Up to 800 µs |
| Polarization | Linear (Horizontal, optional rotator) |
| Transmission Efficiency | >90% @ 800 nm |
| Dimensions | 410 × 324 × 186 mm |
| Compliance | CE, RoHS |
| Software Interface | USB 2.0 with LabVIEW-compatible drivers |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | EFOA-UB |
| Spectral Range | 1100–2000 nm |
| Average Output Power | >150 mW |
| Repetition Rate | 50–70 MHz |
| Laser Head Dimensions | 180 × 210 × 70(90) mm |
| Power Supply Unit Dimensions | 230 × 200 × 100 mm |
| Type | Solid-State Femtosecond Fiber Laser-Based Supercontinuum Generator |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | TeMa |
| Core Configuration | Diode-Pumped Solid-State Femtosecond Oscillator |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | PErL |
| Wavelength (fixed) | 1560 ± 10 nm |
| Pulse Duration (fixed) | 0.25–5 ps |
| Average Output Power | >50 mW |
| Repetition Rate (fixed) | 60 ± 5 MHz |
| Output | FC/APC fiber connector |
| RF Sync Output | SMA (200–300 mV into 50 Ω) |
| Polarization Extinction Ratio | Not specified |
| Dimensions | 136 × 76 × 24 (27) mm |
| Power Supply | +5 V DC |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | TiF-50 |
| Tuning Range | 730–950 nm |
| Pulse Width | <50 fs |
| Output Power | up to 1.2 W (at 10 W pump) |
| Repetition Rate | 80 MHz |
| Pump Power Max | 10 W |
| Beam Quality | TEM₀₀ |
| Polarization | Linear, horizontal |
| Beam Divergence | <1 mrad |
| RMS Power Stability | <1% |
| Dimensions | 610 × 450 × 197 mm |
| Optional Features | Motorized wavelength tuning (USB), birefringent filter, etalon, prism pair / APC for dispersion pre-compensation, electromagnetic shutter for fs/CW switching |
| Brand | Avesta |
|---|---|
| Origin | Russia |
| Model | CrF |
| Type | Solid-State Femtosecond Oscillator |
| Central Wavelength | 1250 nm (tunable 1230–1270 nm) |
| Pulse Width (FWHM) | <35 fs to <140 fs (model-dependent) |
| Average Output Power | 400–800 mW |
| Repetition Rate | 30 MHz or 95–96 MHz |
| Pulse Energy | >4 nJ to >20 nJ |
| Beam Mode | TEM₀₀ |
| Polarization | Linear, horizontal |
| Beam Divergence | <2 mrad |
| Cooling | Thermoelectric (Peltier) + Closed-Loop Water Chiller |
| Integrated Pump Source | 15 W Yb-doped Fiber Laser |
| Startup Mechanism | SESAM-based Self-Starting or Electro-Optic Triggering |
| Power Stability | <2% RMS (CrF-450TP), <5% RMS (CrF-700SP-L) |
| Brand | AOS/Advanced Optics Solutions |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Special Monitoring Units |
| Pricing | Upon Request |
| Brand | AOS / Advanced Optics Solutions |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Import Status | Imported |
| Model | Multi Wavelength Reference |
| Pricing | Available Upon Request |
| Certification | Calibrated and Certified by Physikalisch-Technische Bundesanstalt (PTB), Germany — Equivalent to NIST Traceability |
| Key | Brand: AOS/Advanced Optics Solutions |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Monitoring Unit for Cascaded FBG |
| Pricing | Upon Request |
| Brand | AOS/Advanced Optics Solutions |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Wavelength Reference |
| Pricing | Available Upon Request |
| Key | Brand: AOS / Advanced Optics Solutions |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | DV-1000 Monitoring Unit for Single FBG |
| Pricing | Available Upon Request |
| Brand | AlphaLas |
|---|---|
| Origin | Germany |
| Model | LASKIT-500 |
| Laser Type | Diode-pumped Nd:YAG/Nd:YVO₄ solid-state laser system |
| Output Wavelengths | 1064 nm (fundamental), 532 nm (intracavity/intra-cavity SHG), 266 nm (FHG, optional), 355 nm (THG, optional) |
| Operating Modes | CW @ 1064 nm |
| Q-switched @ 1064 nm (passive, Cr⁴⁺ | YAG) |
| Pulse Width Range | 10–100 ns (depending on gain medium & configuration) |
| Repetition Rate | 5–100 kHz |
| Average Power (1064 nm, CW) | 300–500 mW |
| Average Power (532 nm, CW) | 10–40 mW |
| Average Power (532 nm, Q-switched) | 5–30 mW |
| Integrated Components | Peltier-cooled pump diode with driver & TEC controller (LDD1-1T or LPS1-2T), Nd:YAG/Nd:YVO₄ crystal mount with water cooling, fixed plano-concave cavity mirrors, Cr⁴⁺:YAG saturable absorber (AR/AR coated), AR-coated KTP frequency-doubling crystal (intra- and extracavity configurations), optical breadboard, IR-VIS alignment converter (15 mm clear aperture), ultrafast photodetector UPD-300-SP (320–1100 nm, <300 ps rise time), CCD linear array CCD-2000M (2048 px, for M², autocorrelation, spectral analysis) |
| Modularity | Tool-free crystal/mirror exchange |
| Optional Upgrades | EOD active Q-switching (electro-optic deflector), PC active Q-switching (Pockels cell), monolithic microchip Cr⁴⁺:Nd:YAG laser (1064 nm, ~800 ps, ~10 kW peak power), external SHG/THG/FHG modules |
| Brand | AlphaLas |
|---|---|
| Origin | Germany |
| Model | PICOPOWER-LD |
| Type | Diode-Pumped Solid-State (DPSS) Picosecond Laser Source |
| Wavelength Options | 375, 405, 450, 488, 520, 635, 670, 785, 976, 1030, 1064, 1300, 1550 nm (custom wavelengths available) |
| Pulse Width | <40 ps (typ. <50 ps across most wavelengths) |
| Repetition Rate | 0.1 Hz – 20 MHz (optional up to 80 MHz) |
| Peak Power | Up to 3 W (wavelength- and configuration-dependent) |
| Average Power | 0.2–1.0 mW @ 20 MHz (up to 2.0 mW @ 40 MHz, depending on wavelength) |
| Beam Quality | TEM₀₀ (slightly elliptical) |
| Beam Divergence | 0.5–1.5 mrad |
| Output | Collimated free-space (with integrated spatial filter) or optional fiber-coupled (SMF or PMF) |
| Triggering | External TTL input & synchronized TTL output |
| Control Interface | Built-in digital frequency generator with front-panel display |
| Compliance | CE-marked |
Show next
