| Brand | SAXON |
|---|---|
| Origin | Germany |
| Model | DPM1.0 |
| Instrument Type | Aerosol Detector |
| Measurement Principle | Laser Light Scattering |
| Particle Size Range | 40 nm – 10 µm |
| Range | 0–300 mg/m³ |
| Resolution | 0.1 mg/m³ |
| Repeatability | ≤ ±3% |
| Accuracy | ≤ ±5% of full scale up to 150 mg/m³ |
| Exhaust Gas Temperature Limit | < 800 °C |
| Probe Melting Point Limit | < 70 °C |
| Sampling Probe | 400 mm flexible stainless-steel probe with 2 m heated sampling line |
| Response Time (T90) | < 15 s (with 2 m heated line) |
| Heating Time | < 10 min |
| Zero Calibration Time | 20 s |
| Built-in Functions | Automatic zero adjustment, internal data logger |
| Communication Interfaces | RS232, USB, Bluetooth |
| Display | Color touchscreen |
| Language Support | English, German |
| Operating Ambient Temperature | 5–40 °C |
| Relative Humidity | ≤ 95% RH (non-condensing) |
| Power Supply | 230 VAC / 50 Hz, max. 250 VA (including probe) |
| Dimensions (W×H×D) | ~190 × 275 × 330 mm |
| Weight | ~7.5 kg |
