| Origin | Germany |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | FISCHERSCOPE PMP10 |
| Pricing | Available Upon Request |
| Measurement Principle | Micro-Resistance (4-Point Probe) |
| Thickness Range | 0–120 µm |
| Accuracy | ±0.5 µm (5–50 µm), ≤1% of reading (50–80 µm), ≤2% of reading (>80 µm) |
| Test Area | 10 × 15 mm |
| Compliance | ISO 2178, ASTM B499, IPC-4552A, RoHS-compliant design |
| Key Features | Fully automated inline inspection |
|---|---|
| X-ray tube | 110–130 kV, 300–500 µA, focal spot ≤5 µm |
| Imaging system | 4″/6″ FOV, resolution 75/110 lp/cm, X-CCD 1024×1024 pixels |
| Repeatability | ±40 µm |
| Throughput | ≥12 ppm (4-corner inspection) |
| Cooling | Forced-air |
| Origin | Guangdong, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | XG5000 |
| Pricing | Upon Request |
| X-ray Tube | Sealed, integrated high-voltage source |
| Tube Voltage | 90 kV |
| Tube Current (max) | 200 µA (software-limited to 89 µA) |
| Cooling | Forced-air |
| Geometric Magnification | 12×–48× |
| X-Y-Z Travel Range | 400 mm × 450 mm × 150 mm |
| Image Intensifier FOV | 2″ / 4″ |
| Spatial Resolution | 75–110 lp/cm |
| Radiation Leakage | ≤1 µSv/hr (per IEC 61331-1 & ISO 4037) |
| System Dimensions | 1028 × 1025 × 1840 mm |
| Weight | ~760 kg |
| Power Supply | AC 250 V, 10 A |
| Operating Temperature | 22 ± 3 °C |
| Compliance | CE, RoHS, GB/T 18871-2002 (China National Radiation Safety Standard) |
| Brand | Zhengye |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | OEM/ODM Manufacturer |
| Product Category | Domestic |
| Model | Zhengye X-ray Inspection System |
| Pricing | Available Upon Request |
