LabCompanion TS-2P Series Two-Zone Thermal Shock Test Chamber
| Brand | LabCompanion |
|---|---|
| Model | TS-2P Series |
| Configuration | Two-Zone (Hot/Cold) Dynamic Thermal Shock Chamber |
| Origin | Guangdong, China |
| Manufacturer Type | OEM Manufacturer |
| Regional Classification | Domestic (China) |
| Pricing | Upon Request |
Overview
The LabCompanion TS-2P Series Two-Zone Thermal Shock Test Chamber is an engineered environmental test system designed to evaluate material and component reliability under rapid, repetitive transitions between extreme high and low temperature extremes. It operates on the dynamic two-zone principle: a dedicated high-temperature chamber and a separate low-temperature chamber, with a motorized sample carrier basket that physically transfers test specimens between zones within seconds. This architecture eliminates thermal mass interference from shared air volumes, enabling faster transition rates—typically achieving ≤15-second transfer times and temperature stabilization within 3–5 minutes post-transfer—critical for simulating real-world thermal stress events such as solder joint fatigue, seal integrity failure, or polymer embrittlement in automotive, aerospace, and electronics applications.
Key Features
- Independent Dual-Chamber Architecture: Physically isolated hot and cold zones maintain stable setpoints (e.g., +150 °C and −70 °C) without cross-contamination, ensuring precise thermal gradient control and repeatability across cycles.
- High-Speed Sample Transfer Mechanism: Servo-driven basket elevator with position feedback ensures repeatable, vibration-minimized movement; transfer time configurable to meet MIL-STD-810H Method 503.6 and JEDEC JESD22-A104E requirements.
- Multi-Mode Operational Flexibility: Functions not only as a thermal shock chamber but also as standalone high-temperature oven or low-temperature environmental chamber—enabling pre-conditioning, soak testing, or long-term stability assessment without reconfiguration.
- Robust Thermal Management System: Cascade refrigeration circuit with dual-stage compressors and electric heating elements deliver stable temperature control at ±0.5 °C uniformity (per IEC 60068-3-5) across chamber working volume.
- Industrial-Grade Control Interface: Programmable 10.4″ TFT touchscreen controller with Ethernet/IP connectivity supports up to 999 segments per profile, cycle counting, alarm logging, and USB data export compliant with GLP audit trail requirements.
Sample Compatibility & Compliance
The TS-2P accommodates standard test specimens up to 300 mm × 300 mm × 300 mm (W×D×H) with maximum payload of 20 kg per cycle. Compatible with PCB assemblies, molded plastic housings, battery modules, optical sensors, and hermetically sealed packages. Designed and verified per ISO 16750-4 (Road vehicles – Environmental conditions), ASTM D5229/D5229M (Low-Temperature Impact Resistance), and IEC 60068-2-14 (Test Nb: Change of temperature). Meets structural safety standards EN 61000-6-2/6-4 for electromagnetic compatibility and CE marking directives for machinery (2006/42/EC).
Software & Data Management
Optional LabCompanion TCMS v3.2 software enables remote monitoring, real-time graphing of chamber temperatures and basket position, automated report generation (PDF/CSV), and full compliance with FDA 21 CFR Part 11 through electronic signatures, user role-based access control, and immutable audit trails. All temperature data are timestamped with NIST-traceable internal calibration logs, supporting ISO/IEC 17025 accredited laboratory workflows. Data retention supports ≥1 year of continuous cycle history with automatic backup to network drives or cloud storage via SFTP.
Applications
- Qualification testing of electronic components per AEC-Q200 and IPC-9701 standards
- Thermal cycling validation of adhesives, conformal coatings, and potting compounds
- Failure mode analysis of MEMS devices and optoelectronic modules
- Accelerated life testing of lithium-ion battery cells under thermal abuse scenarios
- Material characterization of composites, elastomers, and thin-film metallization layers
- Process validation for reflow soldering, die attach, and wire bonding processes
FAQ
What is the difference between two-zone and three-zone thermal shock chambers?
Two-zone systems use only hot and cold chambers with direct basket transfer—optimized for speed and cost-efficiency. Three-zone variants add a thermally neutral ambient chamber, reducing thermal inertia during specimen loading/unloading and improving operator safety.
Can the TS-2P perform ramp-and-soak profiles?
Yes—the controller supports programmable ramp rates (0.1–30 °C/min), dwell times (1 s to 999 h), and multi-step sequences, enabling custom profiles beyond standard shock cycles.
Is external calibration support available?
LabCompanion provides optional UKAS-accredited calibration certificates (traceable to NPL) and on-site verification services aligned with ISO/IEC 17025 scope.
Does the system comply with GLP/GMP documentation requirements?
With TCMS v3.2 and enabled audit trail, the system meets ALCOA+ data integrity principles and supports full 21 CFR Part 11 compliance when deployed with validated IT infrastructure.
What maintenance intervals are recommended?
Compressor oil and refrigerant filter replacement every 24 months; door gasket inspection and chamber cleanliness verification every 6 months; annual verification of temperature uniformity and transfer timing per IEC 60068-3-5 Annex B.
