| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-01 |
| Instrument Type | Benchtop Spray Freeze Dryer |
| Application Scope | R&D and Analytical Laboratories |
| Maximum Batch Capacity | 3 L per cycle |
| Spray Freezing Rate | 300–2500 mL/h |
| Collection Efficiency | ≥98% (based on 15% dextrin solution) |
| Construction Material | SUS304 Stainless Steel |
| Control System | PLC with 10-inch Color Touchscreen |
| Integrated Refrigeration | Built-in Compressor (No External Chiller Required) |
| Power Supply | 220 V AC, 3 kW |
| Heating Method | Radiant Heating with Adjustable Temperature Setpoint |
| Footprint | ~1 m² |
| Vacuum Interface & Compressed Air Inlet | Standard Fitted |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-3000 |
| Instrument Type | Standard Shelf-Type Freeze Dryer |
| Application Scope | Laboratory Use |
| Processing Capacity | 1500 mL/batch |
| Total Process Duration | <6 hours/batch |
| Inlet Air Temperature | ≤−50 °C |
| Cold Trap Temperature | ≤−60 °C |
| Ultimate Vacuum (Empty) | <20 Pa |
| Vacuum Pump Power | 1.1 kW |
| Spray Pressure Range | 1–3 bar |
| Compressed Air Flow Rate | 32 L/min |
| Nozzle Type | Adjustable Dual-Channel Coaxial Atomizer |
| Display Interface | Color LCD Touchscreen (showing inlet temperature, fan frequency, peristaltic pump speed, needle-cleaning frequency) |
| Brand | YaCheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Standard Shelf-Type Spray Freeze Dryer |
| Batch Capacity | 1.5 L per cycle |
| Total Processing Time | < 6 hours (1.5 L load) |
| Inlet Air Temperature | ≤ −50 °C |
| Cold Trap Temperature | ≤ −60 °C |
| Ultimate Vacuum Pressure | < 20 Pa (empty chamber) |
| Vacuum Pump Power | 1.1 kW |
| Spray Pressure Range | 1–3 bar (adjustable) |
| Compressed Air Flow Rate | 32 L/min |
| Nozzle Type | Adjustable coaxial two-fluid spray nozzle |
| Display | Full-color LCD touchscreen (inlet temp, fan frequency, peristaltic pump speed, anti-clogging needle frequency) |
| Compliance | Designed for GLP-compliant lab environments |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-01 |
| Instrument Type | Standard Shelf-Type Freeze Dryer |
| Application Scope | Laboratory Use |
| Maximum Batch Capacity | 3 L per cycle |
| Spray Freezing Rate | 300–2500 mL/h |
| Collection Efficiency | ≥98% (based on 15% dextrin solution) |
| Construction Material | SUS304 Stainless Steel |
| Control System | PLC with 10-inch Color Touchscreen |
| Integrated Refrigeration | Built-in Compressor (No External Chiller Required) |
| Power Supply | 220 V, 3 kW |
| Heating Method | Radiant Heating |
| Vacuum Interface & Compressed Air Inlet | Standard Fitted |
| Footprint | ~1 m² |
| Mobility | Equipped with Casters |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | YC-3000 |
| Price | USD 28,000 (FOB Shanghai) |
| Application Scope | R&D and Small-Batch Processing in Academic & Industrial Laboratories |
| Cooling System | Air-Cooled Hermetic Compressor |
| Condenser Temperature | ≤ −60 °C |
| Spray Freezing Temperature | < −15 °C |
| Chamber Pressure (Vacuum) | < 20 Pa (No Load) |
| Spray Pressure Range | 2–5 bar (Adjustable) |
| Air Compressor Output | 4.2 m³/h |
| Cold Air Flow Rate | 5.5 m³/min |
| Batch Capacity | 245 mL per Cycle |
| Display | Full-Color LCD Touchscreen (Chamber Temp, Peristaltic Pump Speed, Fan Frequency, Needle Clearance Frequency, Chamber Pressure) |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-3000 |
| Instrument Type | Standard Shelf-Type Freeze Dryer |
| Application Scope | Laboratory Use |
| Batch Capacity | 1500 mL per cycle |
| Total Process Time | <6 hours (1500 mL) |
| Inlet Air Temperature | <−50 °C |
| Cold Trap Temperature | ≤−60 °C |
| Ultimate Vacuum Pressure | <20 Pa (empty chamber) |
| Vacuum Pump Power | 1.1 kW |
| 雾化压力 | 1–3 bar (adjustable) |
| Air Compressor Output | 32 L/min |
| Nozzle Type | Concentric Dual-Fluid Nozzle with Vertical Adjustment |
| Display | Color LCD Touchscreen (Inlet Temp, Fan Frequency, Peristaltic Pump Speed, Needle Clearance Frequency) |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-01 |
| Instrument Type | Standard Shelf-Type |
| Application Scope | Laboratory Use |
| Maximum Batch Capacity | 3 L per cycle |
| Spray Freezing Throughput | 300–2500 mL/h |
| Final Product Collection Efficiency | ≥98% (based on 15% dextrin test) |
| Control System | PLC with 10-inch color touchscreen |
| Construction Material | SUS304 stainless steel |
| Power Supply | 220 V, 3 kW |
| Integrated Refrigeration | Yes (built-in compressor) |
| Heating Method | Radiant heating, temperature programmable |
| Vacuum Interface & Compressed Air Inlet | Standardized onboard ports |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-01 |
| Instrument Type | Benchtop Spray Freeze Dryer |
| Application Scope | Research & Development Laboratories |
| Maximum Batch Capacity | 3 L per cycle |
| Spray Freezing Throughput | 300–2500 mL/h |
| Collection Efficiency | ≥98% (based on 15% dextrin solution) |
| Control System | PLC with 10-inch color touchscreen |
| Construction Material | SUS304 stainless steel |
| Integrated Refrigeration | Built-in compressor (no external chiller required) |
| Power Supply | 220 V AC, 3 kW |
| Heating Method | Radiant heating with programmable temperature control |
| Vacuum Interface | Standard KF-25 port |
| Compressed Air Inlet | Integrated |
| Footprint | ~1 m² |
| Mobility | Equipped with casters |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Standard Shelf-Type Freeze Dryer |
| Batch Capacity | 1500 mL per cycle |
| Processing Time | <6 hours per batch (1500 mL) |
| Inlet Air Temperature | <−50 °C |
| Cold Trap Temperature | ≤−60 °C |
| Ultimate Vacuum | <20 Pa (empty chamber) |
| Vacuum Pump Power | 1.1 kW |
| Spray Pressure Range | 1–3 bar (adjustable) |
| Air Compressor Output | 32 L/min |
| Nozzle Type | Adjustable coaxial two-fluid spray nozzle |
| Display | Color LCD touchscreen (inlet temp, fan frequency, peristaltic pump speed, needle purge frequency) |
| Compliance | Designed for GLP-compliant lab environments |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YC-01 |
| Instrument Type | Standard Shelf-Type Freeze Dryer |
| Application Scope | Laboratory Use |
| Maximum Batch Capacity | 3 L per cycle |
| Spray Freezing Throughput | 300–2500 mL/h |
| Collection Efficiency | ≥98% (based on 15% dextrin solution) |
| Construction Material | SUS304 Stainless Steel |
| Control System | PLC with 10-inch Color Touchscreen |
| Integrated Refrigeration | Built-in Compressor |
| Power Supply | 220 V, 3 kW |
| Heating Method | Radiant Heating |
| Vacuum Interface & Compressed Air Inlet | Standardized Onboard Ports |
| Footprint | ~1 m² |
| Mobility | Equipped with Casters |
