| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | OEM Manufacturer |
| Model | YC-050 |
| Extraction Vessel Capacity | 50 L |
| Batch Feed Range | 0.3–10 kg |
| Heating Method | Jacketed Thermal Oil Circulation (Pressure-Free) |
| Condenser Area | 2 m² |
| Vacuum Range | 0 to −0.08 MPa |
| Temperature Control Accuracy | ±2 °C |
| Heating Power | 18 kW (380 V) |
| Cooling Water Consumption | 2 t/h at <0.3 MPa |
| Material of Construction | SUS304 Stainless Steel (Contact Parts) |
| Concentration Density Range | 1.10–1.38 (w/w, herbal extract) |
| Optional Ultrasound Module | 15–60 kHz, focused transducer configuration |
| Brand | Pilotech |
|---|---|
| Origin | Shanghai, China |
| Manufacturer | Yes |
| Type | Domestic |
| Model | YC-020 |
| Price | USD 7,700 (FOB Shanghai) |
| Extraction Vessel Volume | 25 L |
| Batch Feed Capacity | 0.3–5 kg |
| Minimum Feed | 0.3 kg |
| Evaporation Rate (Water) | 4–6 kg/h |
| Vacuum Degree (Evaporator Chamber) | –0.08 MPa |
| Temperature Control Accuracy | ±2 °C |
| Heating Power | 4.5 kW @ 380 V |
| Cooling Water Consumption | 1 t/h @ < 0.3 MPa |
| Construction Material | SUS304 Stainless Steel |
| Overall Dimensions | 1500 × 800 × 1900 mm |
| Footprint | ~2.4 m² |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | YC-020 |
| Price | USD 7,700 (FOB Shanghai) |
| Extraction Vessel Volume | 25 L |
| Batch Feed Capacity | 0.3–5 kg |
| Minimum Feed | 0.3 kg |
| Evaporation Rate (Water) | 4–6 kg/h |
| Concentrated Extract Density Range | 1.10–1.38 g/mL |
| Vacuum Level in Evaporator Chamber | –0.08 MPa (absolute) |
| Temperature Control Accuracy | ±2 °C |
| Heating Power | 4.5 kW @ 380 V AC |
| Cooling Water Consumption | 1 m³/h @ <0.3 MPa pressure |
| Construction Material | AISI 304 stainless steel |
| Overall Dimensions (W×D×H) | 1500 × 800 × 1900 mm |
| Footprint | ~2.4 m² |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | OEM/ODM Manufacturer |
| Product Origin | Domestic (China) |
| Model | YC-010 |
| Pricing | Upon Request |
| Brand | PiloTech |
|---|---|
| Origin | Shanghai, China |
| Manufacturer | Yes |
| Country of Origin | China |
| Model | YC-010 |
| Extraction Chamber Volume | 10 L |
| Temperature Control Accuracy | ±2 °C |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | OEM Manufacturer |
| Product Origin | Domestic (China) |
| Model | YC-050 |
| Pricing | Upon Request |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | OEM Manufacturer |
| Product Origin | Domestic (China) |
| Model | YC-100 |
| Pricing | Upon Request |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | YC-010 |
| Pricing | Upon Request |
| Extraction Vessel Capacity | 10 L (effective) |
| Construction | 3-layer stainless steel (inner polished, middle thermal oil jacket, outer PU insulation) |
| Condenser Area | 0.5 m² (tubular) |
| Vacuum Range | 0 to –0.08 MPa |
| Temperature Control | PID-regulated, ±2 °C accuracy |
| Cooling Water Consumption | 0.5 t/h at <0.3 MPa pressure |
| Material Contact Surface | AISI 316L stainless steel |
| Operating Pressure Modes | Vacuum, atmospheric, and positive pressure |
| Optional Ultrasonic Module | Titanium alloy transducer, frequency selectable from 15–60 kHz |
| Brand | PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | YC-050 |
| Pricing | Upon Request |
| Brand | YaCheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | YC-010 |
| Extraction Chamber Volume | 10 L |
| Temperature Control Accuracy | ±2 °C |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | YC-100 |
| Pricing | Upon Request |
| Brand | PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer | Yes |
| Country of Origin | China |
| Model | YC-010 |
| Extraction Chamber Volume | 10 L (effective) |
| Temperature Control Accuracy | ±2 °C |
| Operating Pressure Range | −0.08 MPa to +0.1 MPa (vacuum to slight positive pressure) |
| Condenser Surface Area | 0.5 m² |
| Cooling Water Consumption | 0.5 t/h at < 0.3 MPa |
| Construction Material | 316L stainless steel (wetted parts), insulated triple-wall tank with polyurethane foam |
| Heating Method | Thermostatic oil-jacketed circulation (pressure-free jacket) |
| Optional Features | Integrated ultrasonic extraction module (15–60 kHz, titanium alloy transducer) |
| Brand | YaCheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | YC-100 |
| Heating Power | 380 V / 27 kW |
| Extraction Vessel Capacity | 100 L |
| Batch Feed Range | 5–20 kg |
| Vacuum Range | 0 to −0.08 MPa |
| Temperature Control Accuracy | ±2 °C |
| Condenser Surface Area | 3 m² |
| Cooling Water Consumption | 3 t/h @ < 0.3 MPa |
| Construction Material | SUS304 stainless steel (contact surfaces) |
| Operating Pressure Range | Full vacuum to positive pressure |
| Concentrate Density Range | 1.10–1.38 (for herbal extracts) |
| Optional Ultrasonic Frequency Range | 15–60 kHz (focused transducer type) |
| Brand | Yacheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | YC-100 |
| Capacity | 100 L |
| Batch Feed Range | 5–20 kg |
| Heating Method | Thermal Oil Circulation (Jacketed, Pressure-Free) |
| Condenser Area | 3 m² (Tube-Type) |
| Vacuum Range | 0 to –0.08 MPa |
| Temperature Control Accuracy | ±2 °C |
| Heating Power | 27 kW (380 V) |
| Cooling Water Consumption | 3 t/h (< 0.3 MPa) |
| Construction Material | SUS304 Stainless Steel (Contact Parts) |
| Compliance | FDA-Compliant Surface Finish, GMP-Compatible Design, GLP-Ready Configuration |
| Optional Module | Ultrasonic Extraction (15–60 kHz, Probe-Type, Focused Energy) |
| Brand | YaCheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | YC-050 |
| Capacity | 50 L |
| Max. Feed Load | 10 kg/batch |
| Min. Feed Load | 0.3 kg/batch |
| Heating Method | Jacketed Thermal Oil Circulation (Pressure-Free) |
| Vacuum Range | 0 to –0.08 MPa |
| Temperature Control Accuracy | ±2 °C |
| Heating Power | 18 kW @ 380 V |
| Cooling Water Consumption | 2 t/h @ < 0.3 MPa |
| Condenser Area | 2 m² |
| Construction Material | SUS304 Stainless Steel (Contact Parts) |
| Concentration Density Range | 1.10–1.38 (w/w, herbal extract) |
| Optional Ultrasound Frequency | 15–60 kHz (focused transducer type) |
| Brand | YaCheng / PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic (China) |
| Model | YC-020 |
| Quotation | Available Upon Request |
| Vessel Capacity | 20 L |
| Batch Feed Range | 0.3–5 kg |
| Temperature Control Accuracy | ±2 °C |
| Heating Power | 9 kW (380 V AC) |
| Vacuum Range | 0 to −0.08 MPa (gauge) |
| Condenser Surface Area | 0.5 m² |
| Cooling Water Consumption | 1 t/h @ < 0.3 MPa |
| Construction Material | SUS304 Stainless Steel |
| Operating Pressure Range | −0.08 MPa to +0.3 MPa (gauge) |
| Concentrate Density Range | 1.10–1.38 g/mL |
| Footprint | ~2.5 m² |
| Brand | PILOTECH |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | YC-010 |
| Extraction Chamber Volume | 10 L |
| Temperature Control Accuracy | ±2 °C |
| Operating Pressure Range | −0.08 MPa to +0.1 MPa (vacuum to slight overpressure) |
| Construction Material | 316L stainless steel (wetted parts) |
| Heating Method | Jacketed thermal oil circulation (pressure-free) |
| Condenser Surface Area | 0.5 m² (tubular) |
| Optional Ultrasonic Module | Titanium alloy transducer, frequency selectable from 15–60 kHz |
| Cooling Water Requirement | 0.5 t/h at < 0.3 MPa |
