| Brand | Top Cloud-agri |
|---|---|
| Origin | Zhejiang, China |
| Manufacturer Type | Direct Producer |
| Model | YD-1 |
| Instrument Category | Specialized Smoke Point Analyzer for Fats and Oils |
| Measurement Principle | Visual Observation of Blue Smoke Onset under Controlled Heating |
| Accuracy (Indication Error) | ±0.5% of full scale |
| Repeatability | ≤2% RSD |
| Response Time | ≤60 s |
| Stability (Drift over 4 h) | ≤5% of reading |
| Sample Type | Refined or Crude Vegetable Oils (e.g., soybean, rapeseed, palm, sunflower) |
| Dual-Test Reproducibility | ≤2 °C |
| Output | Analog mercury-in-glass thermometer + digital LED display |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Operating Environment | 0–40 °C, ≤80% RH |
| Dimensions (Main Unit) | 450 × 600 × 900 mm (L×W×H) |
| Dimensions (Control Panel) | 255 × 275 × 385 mm |
| Weight | 10 kg |
