| Brand | Top Cloud-agri |
|---|---|
| Origin | Zhejiang, China |
| Manufacturer Type | OEM/ODM Producer |
| Model | TPZJ-2010 |
| Measurement Range (Diameter) | 450–2500 mm (Outer), 0–12.7 mm (Displacement) |
| Radius Range | 5–9999.9 mm |
| Resolution | 0.005 mm / 0.0005 in |
| Accuracy (Displacement) | ≤ ±0.02 mm |
| Radius Measurement Error | ΔR ≤ 0.01 × R/S |
| Repeatability | < 1% of measured radius |
| Operating Temperature | 0–40 °C |
| Relative Humidity | ≤80% RH (non-condensing) |
| Power Supply | 3 V CR2032 lithium coin cell |
| Max. Measurement Speed | >1.5 m/s |
| Probe Span (Large Radius Gauge) | 200 mm |
| Standard Probe Sets | Five radius-specific jaw kits (10/20/30/60/100 mm spans) |
| Display | LCD with dual-unit (mm/in) toggle, data hold, zero reset, auto/manual power-off |
| Interface | RS232 & USB output (optional), metric/imperial conversion |
