| Brand | PCRmax |
|---|---|
| Origin | United Kingdom |
| Model | AC-1 |
| Instrument Type | Gradient PCR Thermal Cycler |
| Sample Capacity | 96-well (0.2 mL) or 384-well module (field-replaceable) |
| Max Heating/Cooling Rate | 3.4 °C/s |
| Temperature Accuracy | ±0.25 °C |
| Inter-well Temperature Uniformity | ±0.3 °C |
| Temperature Range | 4–100 °C |
| Gradient Range | 10–100 °C |
| Gradient Span | 1–29 °C |
| Gradient Channels | 12 independent temperature zones |
| Heat Lid Temperature | 35–115 °C (adjustable, manually pressure-controlled) |
| Heat Lid Uniformity | ±5 °C |
| Heat Lid Preheating Time | <2 min |
| Display | 7" 1080P full-color LCD touchscreen |
| OS | Embedded Android-based firmware |
| Onboard Program Storage | ≥1,000 protocols |
| USB Expansion Support | Yes (USB-A & USB-B) |
| Power Consumption (30-cycle run) | 0.3 kWh |
| Dimensions (W×D×H) | 200 × 260 × 430 mm |
| Rated Power | 425 W |
| Noise Level | <50 dB(A) |
| Brand | PCRmax |
|---|---|
| Origin | United Kingdom |
| Model | AC-2 |
| Sample Capacity | Two independent blocks (configurable as two 96-well, two 384-well, or mixed 96/384 modules) |
| Max Heating Rate | 3.4 °C/s |
| Temperature Accuracy | ±0.1 °C |
| Block Uniformity | ±0.3 °C |
| Temperature Range | 4–100 °C |
| Gradient Range | 10–100 °C |
| Gradient Span | 1–29 °C |
| Gradient Steps | 12 distinct temperatures with identical hold times |
| Thermal Lid | Adjustable manual pressure, 35–115 °C (or off), uniformity ±5 °C, preheat time <2 min |
| Cooling Method | Peltier-based semiconductor |
| Programmable Cycles | Up to 99 |
| Onboard Storage | ≥1000 protocols |
| Interface | 1× USB-A, 1× USB-B |
| Power | 900 W |
| Dimensions (W×D×H) | 470 × 535 × 330 mm |
| Noise Level | <50 dB (per module) |
