| Brand | KD Scientific |
|---|---|
| Origin | USA |
| Model | KDS Legacy Series (Single/Dual/Multi-Channel) |
| Flow Rate | 0.001 µL/h |
| Accuracy | <1% |
| Repeatability | ±1% |
| Compliance | CE-certified |
| Drive Force | Up to 18 kg (40 lb) |
| Syringe Capacity Range | 10 µL – 140 mL |
| Control Interface | Front-panel menu, PC (RS232/USB), footswitch, and external valve triggers |
| Brand | KD Scientific |
|---|---|
| Origin | USA |
| Model | Legato 130 |
| Instrument Type | Microinfusion Syringe Pump |
| Flow Rate | 3.66 pL/min – 3.818 mL/min |
| Accuracy | ±0.5% |
| Syringe Capacity | 0.5 µL – 1000 µL |
| Display | 4.3" WQVGA TFT Color Touchscreen |
| Certifications | CE, UL, CSA, CB Scheme, RoHS, WEEE |
| Power Input | 12–30 VDC |
| Dimensions | 22.6 × 17.78 × 9.32 cm |
| Weight | 1.96 kg |
| Operating Temperature | 4–40 °C |
| Storage Temperature | −10–70 °C |
| Humidity | 20–80% RH (non-condensing) |
| Max Linear Force | 5 kg |
| Motor | 1.8° Stepper with 1/16 Microstepping |
| Microstep Resolution | 3200 steps/rev |
| Min/Max Step Time | 27.5 sec / 52 µsec per microstep |
| Min/Max Plunger Speed | 0.433 µm/min / 228.97 mm/min |
| Interfaces | RS485 (IEEE-1394 6-pin), USB Type B, 15-pin D-Sub I/O & TTL, Mini Phono Jack for Footswitch |
| Non-volatile Memory | Yes |
| Programmable Steps | 2 programs × 50 steps each |
| Operation Modes | Infuse/Withdraw |
| Injection Volume Resolution | Sub-nanoliter to picoliter level |
| Brand | KD Scientific |
|---|---|
| Origin | USA |
| Model | Legato |
| Instrument Type | Microfluidic Syringe Pump |
| Flow Rate | 0.5 pL/min |
| Accuracy | ±0.35% |
| Repeatability | 0.5 pL/min |
