| Brand | LabCompanion |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Model | GFLY |
| Power Supply | 380 V ±10%, 50 Hz, 3-phase 4-wire + PE |
| Total Power | 24 kW |
| Interior Dimensions | 1500 × 1500 × 1600 mm (D×W×H) |
| Exterior Dimensions | 2291 × 4200 × 3411 mm (D×W×H) |
| Test Table | Ø800 mm, 1–10 rpm, Load Capacity ≥65 kg |
| Rainfall Intensity | 10–20 cm/h (adjustable) |
| Raindrop Diameter | 0.5–4.5 mm |
| Wind Speed Range | 5–18 m/s (measured at centerline of turntable inlet) |
| Water Pressure (Rain) | 80–100 kPa |
| Water Pressure (Waterjet) | ≥276 kPa |
| Temperature Range | RT+10°C to +55°C |
| Test Duration | 0–999 min (programmable, cyclic capable) |
| Compliance | GJB 150.8-1986 |
| Brand | LabCompanion |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Model | LabCompanion HV-RT Series |
| Temperature Range | (RT + 10°C) to 55°C |
| Rainfall Intensity | 10–20 cm/h |
| Droplet Diameter | 0.5–4.5 mm |
| Wind Speed | 5–18 m/s (measured at center horizontal plane of turntable inlet) |
| Rain Exposure Duration | 1–999 min |
| Turntable Speed | 1–10 rpm |
| Turntable Diameter | Φ800 mm |
| Turntable Load Capacity | ≥65 kg |
| Internal Chamber Dimensions | 1500 × 1500 × 1600 mm (D×W×H) |
| External Dimensions | 2291 × 4200 × 3411 mm (D×W×H) |
| Power Supply | 380 V ±10%, 50 Hz ±1, 3-phase 4-wire + PE, grounding resistance <4 Ω |
| Total Power Consumption | 24 kW |
| Compliance | MIL-STD-810G Method 506.6, IEC 60529 IPX3/IPX4/IPX5/IPX6, GJB 150.8A-2009 |
| Brand | LabCompanion |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Model | LY-512 |
| Temperature Range | +10°C to +60°C (above ambient) |
| Rainfall Intensity | 10–20 cm/h (measured at turntable surface, adjustable) |
| Water Pressure | 80–892 kPa |
| Wind Speed | 5–18 m/s (horizontal center velocity at air inlet near turntable) |
| Test Duration | 0–999 min (programmable) |
| Spray Arm Oscillation Angles | 60°, 90°, 135° |
| Nozzle Orifice Diameter/Spacing | 0.4 mm / 50 mm |
| Water Flow Rate | 0.6 L/min (adjustable) |
| Turntable Diameter | Ø350 mm |
| Turntable Speed | 1–17 rpm |
| Internal Chamber Dimensions | 800 × 800 × 800 mm (W×H×D) |
| External Dimensions | 1250 × 1800 × 1100 mm (W×H×D) |
| Handheld Sprayer | ~100 × Ø1 mm orifices, 1 m spray distance, 0°–90° adjustable nozzle angle |
| Nozzle-to-Specimen Distance | ≤250 mm |
| Total Water Supply Flow | 25.4 L/min (adjustable) |
| Drive System | Imported frequency inverters for oscillation and rotation control |
| Heating System | Stainless steel finned electric heater |
| Temperature Sensor | PT100 platinum resistance thermometer |
| Control Interface | Color TFT touchscreen programmable controller |
| Cabinet Construction | Outer shell — brushed SUS304 stainless steel |
| Safety Protections | Leakage current cutoff, overcurrent protection, water pressure monitoring, overload fuse, audible alarm, grounding fault detection |
