| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Supplier Type | Authorized Distributor |
| Load Capacity | 50–800 kg |
| Peak Acceleration | 30–1000 m/s² |
| Pulse Duration | 20–130 ms |
| Repetition Rate | 10–60 impacts/min |
| Table Surface Dimensions | 500×700 mm to 1000×1000 mm |
| Maximum Drop Height | 0–80 mm |
| Continuous Operation Time | 8 h |
| Power Supply | 220 VAC ±10% / 380 VAC ±10%, 50 Hz |
| Environmental Operating Range | –40 to +50 °C, Humidity <85% RH (at 25 °C) |
| Compliance Standards | GB/T 2423.5–1995, GB/T 2423.6–1995, IEC 60068-2-27, IEC 60068-2-29, JJG 497–2000 |
| Impact Table Surface | 200 × 200 mm |
|---|---|
| Maximum Load Capacity | 10 kg |
| Pulse Duration Range | 0.2–100 ms (programmable, auto-controlled) |
| Peak Acceleration Range | 50–9999 m/s² |
| Waveform Type | Half-sine |
| Shock Direction | Vertical |
| Deceleration Mechanism | Hydraulic-friction dual-stage arrestor |
| Height Adjustment | Digital preset + hydraulic lifting |
| Control & Measurement System | Integrated real-time acquisition unit |
| Frame Weight | 2800 kg |
| Dimensions (W×L×H) | 750 × 2600 × 1000 mm |
| Power Supply | AC 380 V ±10%, 50 Hz, 3 kVA |
| Repetition Rate | 0–100 shocks/min |
| Sampling Rate | 200 kHz |
| Filtering | Analog anti-aliasing + 160 dB/octave digital anti-aliasing filter |
| Compliance Standards | IEC 60068-2-27, GB/T 2423.5, GJB 150.18A, GJB 360B, JJG 497 |
| Software Platform | Windows XP-based with DAO engine, automated Word report generation, real-time display of height, acceleration amplitude, pulse width, and Δv |
| Brand | OEM / Private Label |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Max Load Capacity | 50 kg |
| Peak Acceleration Range | 30–1000 m/s² |
| Pulse Duration | 1–20 ms |
| Shock Repetition Rate | 10–60 impacts/min |
| Table Surface Dimensions | 500 × 700 mm |
| Maximum Drop Height | 0–60 mm |
| Continuous Operation Time | 8 h |
| Overall Dimensions (L×W×H) | 700 × 1100 × 800 mm |
| Waveform Options | Half-sine, Post-peak Sawtooth, Trapezoidal |
| Control Mode | Closed-loop Acceleration Feedback via Photoelectric Sensor |
| Structural Rigidity | High-stiffness Platform with Uniform Acceleration Distribution |
| Brand | OEM / Third-Party Manufacturer |
|---|---|
| Origin | Imported |
| Supplier Type | Authorized Distributor |
| Price | USD 16,500 (FOB) |
| Compliance | ISO 2247, ASTM D880, ISTA 3A, MIL-STD-810H Shock Methods |
| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 16,800 (FOB) |
| Model | OKPZ-50 |
| Drop Height Range | 50–1000 mm (adjustable in 50 mm increments) |
| Impact Mass Options | 300 g, 500 g, 1000 g, 2000 g |
| Hammer Tip Radius | 7.9 mm (5/16″), 12.7 mm (1/2″), 6.35 mm (1/4″), 4.76 mm (3/16″), 3.18 mm (1/8″), 1.59 mm (1/16″) |
| Specimen Holder Radii | 8.1 mm (1/4″), 15 mm (approx. 9/16″) — flat and spherical configurations |
| Dimensions (L×W×H) | 580 × 450 × 1280 mm |
| Net Weight | ~60 kg |
| Waveform Generation | Half-sine, trapezoidal, and terminal-peak sawtooth shock pulses |
| Control Method | Digital height setting with optical feedback loop |
| Compliance | IEC 60068-2-27, MIL-STD-810H Method 516.8, GJB 150.18A, JIS C 0041, ASTM D3332 |
| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| 冲击 Energy Range | 0–100,000 g·mm (0–980.7 J) |
| Peak Acceleration Capability | Up to 100,000 g (theoretical, dependent on mass & pulse duration) |
| Impact Velocity Range | 0–9.3 m/s |
| Table Surface Dimensions | 180 × 180 mm |
| Mass | 2,500 kg |
| Compliance | JESD22-B110, IEC 60068-2-27, ISO 13374-2 |
| Waveform Generation | Half-Sine Pulse (adjustable via interchangeable elastomeric impact seats) |
| Platform Uniformity (within Ø160 mm) | ±10% |
| Repeatability | Acceleration ±10%, Duration ±15%, Δv ±10% |
| Optional Features | Pneumatic braking system, spring-assisted acceleration enhancement, vibration-isolating mounting feet |
| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 16,800 (FOB) |
| Compliance | MIL-STD-810, GJB150.18, IEC 60068-2-29, GB/T 2423.5–2022, GB/T 2423.6–2022 |
| Waveforms | Half-sine, Trapezoidal, Post-peak Sawtooth |
| Max Payload | 50–500 kg |
| Peak Acceleration Range | 25–1200 m/s² |
| Pulse Duration | 1.5–25 ms |
| Drop Height Adjustment | 0–200 mm |
| Repetition Rate | 1–120 impacts/min |
| Actuation | DC Motor + Gear Reducer + Roller Lift Mechanism |
| Control Mode | Closed-loop Acceleration Feedback for Collision Tests |
| Structural Rigidity | High-stiffness Cast-Iron Base & Reinforced Aluminum Alloy Table Surface |
| Air Supply | 7–8 kg/cm² (required for pneumatic damping & positioning) |
| Power Input | AC 220 V ±5%, 50 Hz ±0.5 Hz, Single-phase Three-wire |
| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Manufacturer Type | General Distributor |
| Price | USD 14,000 (approx.) |
| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Max Load Capacity | 50–800 kg |
| Peak Acceleration Range | 30–1000 m/s² (models OKPZ-50 to OKPZ-200) |
| Pulse Duration | 1–30 ms |
| Repetition Rate | 10–60 impacts/min |
| Table Dimensions | 500×700 mm to 1000×1000 mm |
| Maximum Drop Height | 0–80 mm |
| Continuous Operation Time | ≥8 h |
| Power Supply | 220 VAC ±10% / 380 VAC ±10%, 50 Hz |
| Environmental Operating Range | Temperature –40°C to +50°C, Humidity <85% RH (at 25°C) |
| Compliance | GB/T 2423.5–1995, GB/T 2423.6–1995, IEC 60068-2-27, IEC 60068-2-29, JJG 497–2000 |
| Brand | Generic |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 16,500 (FOB) |
| Compliance | MIL-STD-810, IEC 60068-2-29, GB/T 2423.5–2022, GJB 150.18A–2012, GJB 360B–2009 |
| Brand | OEM / Third-Party Manufacturer |
|---|---|
| Origin | Imported |
| Supplier Type | Authorized Distributor |
| Price | USD 16,800 (FOB) |
| Compliance | ISO 13374-2, ASTM D999, IEC 60068-2-27, MIL-STD-810H Method 516.8 |
