| Brand | Parker |
|---|---|
| Origin | United Kingdom |
| Model | LCM20 |
| Calibration Standards | ACFTD & MTD |
| Channel Count | 6 |
| Detection Principle | Single-Point Source Laser (SPSL) Light Scattering |
| Display | Integrated LCD Handheld Unit |
| Data Storage | 300 Test Records |
| Pressure Rating | Up to 420 bar |
| Flow Compatibility | Up to 400 L/min (with system integration) |
| Communication | RS232 @ 9600 baud |
| Compliance | ISO 4406, ISO 11171, NAS 1638, ASTM D6786 |
| Software | DAT μm Trend Analysis Suite (free firmware updates included) |
| Optional Accessories | Barcode Scanner, Built-in Thermal Printer, Relay Output for External Equipment Control |
| Service | Annual calibration support via Parker Authorized Service Centers |
| Brand | SETA |
|---|---|
| Origin | United Kingdom |
| Model | SA1900-0 |
| Instrument Type | Optical Particle Counter |
| Compliance Standards | IP 565, NB/SH/T 0868, ASTM D7647, ISO 4406, ISO 60970, ASTM D6786, NAS 1638, AS 4059F, ISO 11171, ISO 11500, SAE J183, SAE J749D, GOST 17216, GB/T 5930, GJB 420A–1996, GJB 420B–2006, JIS B 9932:2012, JIS B 9933:2021, JIS B 9934:2012 |
| Sample Viscosity Range | Up to 400 cSt (tested with in-service lubricants, hydraulic fluids, and insulating oils) |
| Sealing Material | FFKM (perfluoroelastomer) |
| Integrated Pressure Pump | Yes |
| Analysis Time | ≤ 3 minutes per sample |
| Control Modes | Standalone operation or PC-controlled via ProTrend software |
| Brand | Optimol |
|---|---|
| Origin | Germany |
| Model | SRV®5 |
| Instrument Type | Reciprocating Tribometer |
| Maximum Friction Force | 2500 N |
| Friction Force Resolution | 1 N |
| Operating Temperature Range | −35 °C to 1000 °C |
| Motion Modes | Reciprocating, Rotational, Tilted (0°–90°), Oscillatory, Non-Continuous Transition |
| Optional Modules | FSA (Friction Signal Analysis), Vacuum Chamber (High Vacuum), Nanopositioning Stage, Electrical Resistance Monitoring, Custom Fixture Integration |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | DSCvesta2 |
| Temperature Range | –180 to 725 °C (atmospheric: RT to 600 °C |
| mechanical cooling | –95 to 725 °C) |
| Heating/Cooling Rate | up to 100 °C/min |
| Gas Flow Range | 0–250 mL/min (resolution: 1 mL/min) |
| Heat Flow Range | ±1000 mW |
| Noise Level | < 0.05 µW |
| Baseline Repeatability (–70 to 300 °C) | ≤ 10 µW |
| Enthalpy Sensitivity | 0.1 µW |
| Sensor Type | Heat-Flow-Type Metallic Sensor with vestaeye® Self-Diagnostic Function |
| Furnace Material | Pure Silver or Pure Platinum |
| Calibration Standards | ≥5 Certified Reference Materials (including Indium, Zinc, Tin, Bismuth, Lead) |
| Software Features | Dual-data logging (raw + corrected), LIMS integration support, export to Word, Excel, JPG, PDF |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | TG-DTA8122 |
| Temperature Range | Ambient to 1100 °C (standard), up to 1500 °C (high-temperature option) |
| Heating Rate | Up to 100 °C/min |
| Balance System | Horizontal differential triple-coil design |
| Max. Sample Mass | 1 g |
| TG Full Scale | ±250 mg (500 mg FS) |
| TG Sensitivity | 0.01 µg |
| DTA Full Scale | ±1000 µV (2000 µV FS) |
| Atmosphere Options | Air, inert gas, vacuum, steam, controlled flow |
| Optional Autosampler | 24 sample positions + 3 reference + 5 calibration positions |
| Standard Operating Modes | Constant Reaction Control (CRC), Step Isothermal Analysis (SIA), Dynamic Rate Control (DRC) |
| Brand | SETA |
|---|---|
| Origin | United Kingdom |
| Model | SA1100-0 |
| Instrument Type | Optical Particle Counter |
| Particle Size Range (ISO 11171) | 4 µm to >70 µm |
| Particle Size Range (ISO 4402) | 2 µm to >100 µm |
| Number of Sizing Channels | 16 |
| Maximum Particle Count per Test | 60,000 particles/mL |
| Sample Viscosity Range | up to 68 mm²/s (direct from bottle), up to 500 mm²/s at 10 bar |
| Sample Temperature Range | 0–70 °C |
| Flow Rate | 30 mL/min |
| Total Sample Volume per Test | 80 mL (including rinse) for IP 565 |
| Maximum Inlet Pressure | 10 bar (310 bar optional) |
| Output Units | particles/mL or particles/10 mL |
| Cleanliness Codes | Cumulative & Differential per ISO 4406, NAS 1638, SAE AS4059, JIS B 9932:2012, JIS B 9933:2021, JIS B 9934:2012, GOST 17216, Defence Standards 91-091 & 91-86, ASTM D975, D6299, D7619, D7647, IP 565, IP 630 |
| Calibration Standard | ISO 11171 |
| Data Interfaces | Ethernet, USB |
| Display | Integrated touchscreen interface |
| Onboard SQC Software | Compliant with ASTM D6299 statistical quality control requirements |
| User Authentication | Password-protected access levels |
| Embedded Test Methods | 14 preconfigured methods |
| Brand | Kittiwake |
|---|---|
| Origin | United Kingdom |
| Model | FG-K17400-KW |
| Instrument Type | Resistive Particle Counter |
| Measurement Range | 0–2000 ppm |
| Accuracy | ±30 ppm |
| Operating Ambient Temperature | 0–65 °C |
| Power Supply | 24 V DC / 0.7 A |
| Weight | 17 kg |
| Dimensions | 380 × 44 × 32 cm |
| Brand | Kittiwake |
|---|---|
| Origin | UK |
| Model | FG |
| Temperature Range | -20 to 65°C |
| Detection Threshold | 0.04 mm (ferrous), 0.135 mm (non-ferrous) |
| Output Signals | 2 × opto-isolated 4–20 mA, 1 × alarm contact (0.1 A max) |
| Communication Interfaces | RS232, RS485 (Ethernet optional) |
| Fluid Compatibility | Mineral oil, synthetic lubricants, emulsified oils |
| Max Operating Pressure | 10 bar |
| Power Supply | 18–30 VDC |
| Ingress Protection | IP65 |
| Weight | 1.5 kg (3.3 lb) |
| Brand | Kittiwake |
|---|---|
| Origin | United Kingdom |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | FG-K16120-KW |
| Pricing | Upon Request |
| Communication Interfaces | CAN Bus, RS232, RS485, Wireless Network |
| Sensor Port | BSP 3/8″ |
| Compatible Fluids | Mineral Oils, Synthetic Lubricants, Hydraulic Fluids |
| Fluid Temperature Range | −20 to +65 °C |
| Maximum Operating Pressure | 10 bar |
| Power Supply | 18–30 VDC |
| Ingress Protection Rating | IP65 |
| Ferrous Debris Detection Range | 0–2000 ppm (by mass) |
| Weight | 2.2 kg |
| Origin | USA |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | FORM DDI |
| Price Range | USD 68,000 – 136,000 |
| Brand | Kittiwake |
|---|---|
| Origin | United Kingdom |
| Model | FG |
| Operating Temperature Range | 0–70°C |
| Ferrous Debris Detection Range | 0–2000 ppm (uncombined, by weight) |
| Oil Quality Index Scale | 0–100 |
| Relative Humidity Measurement | 0–100% RH |
| Temperature Sensing Range | −20–120°C |
| Analog Output | 4–20 mA |
| Digital Interfaces | RS232, RS485, CAN bus, Wi-Fi |
| Maximum System Pressure | 10 bar |
| Maximum Oil Viscosity | 350 cSt @ 40°C |
| Power Supply | 18–30 V DC |
| Ingress Protection Rating | IP65 |
| Weight | 15 kg |
| Brand | TAMSON |
|---|---|
| Origin | Netherlands |
| Model | TV4000 |
| Instrument Type | Vacuum Capillary Viscometer |
| Viscosity Range | 0.0036–20,000 Pa·s |
| Temperature Range | Ambient to 230 °C |
| Temperature Stability | ±0.01 °C |
| Bath Volume | 40 L |
| Bath Opening Dimensions | 260 × 240 mm |
| Vacuum Pressure Range | 30–430 mbar (negative pressure) |
| Vacuum Accuracy | ±0.5 mbar |
| Compliant Standards | ASTM D2171, SH/T 0557, IP 222, EN 12596, AASHTO T 202 |
| Brand | SETA |
|---|---|
| Origin | United Kingdom |
| Model | SA1800-2 |
| Instrument Type | Optical Particle Counter |
| Compliant Standards | ASTM D975, ASTM D6786, ASTM D7619, IP 565, IP 630, NB/SH/T 0868, JIS B 9932:2012, JIS B 9933:2021, JIS B 9934:2012, GB/T 5930 |
| Measurement Principle | Light Obscuration (LO) |
| Sample Throughput | ≤3 min per test |
| Display | Integrated graphical interface with trend visualization |
| Data Interface | USB port for export |
| Onboard Functions | Built-in thermal printer, three pre-programmed test methods, PC-configurable via Partikel software |
