SYC Sycs SCQ-25-08 Benchtop Ultrasonic Cleaner with Removable Transducer Plate

Overview

The SYC Sycs SCQ-25-08 is a benchtop ultrasonic cleaner engineered for reliable, repeatable cleaning of laboratory glassware, precision components, medical instruments, and industrial parts in research, quality control, and manufacturing environments. It operates on the principle of acoustic cavitation: high-frequency mechanical vibrations (40 kHz) generated by piezoelectric transducers bonded to the tank bottom induce microscopic bubble formation and collapse within the cleaning solution. This implosive energy dislodges particulate contaminants, organic residues, and thin films from surfaces—regardless of geometry—without mechanical abrasion or chemical aggression. As a split-system design, the SCQ-25-08 separates the ultrasonic generator from the stainless steel tank, enabling flexible placement, improved heat dissipation, and simplified maintenance. Its 85 L capacity and robust 800 W transducer array support medium-to-large batch processing while maintaining uniform energy distribution across the entire tank volume.

Key Features

• Stainless steel 304 tank (830 × 530 × 200 mm internal dimensions) and housing for long-term resistance to aqueous and mild solvent-based cleaning media.
• Dedicated 40 kHz ultrasonic frequency optimized for general-purpose cleaning—balancing penetration depth, cavitation intensity, and surface sensitivity.
• Fixed-output 800 W power delivery ensures consistent energy input; no variable power control required for standardized cleaning protocols.
• Mechanical timer with 1–600 minute range supports both short-cycle degassing and extended soak-cleaning applications.
• Integrated sound-dampening lid reduces ambient noise to ≤65 dB(A) during operation, meeting occupational safety guidelines for continuous lab use.
• Manual fill-and-drain system with integrated drain valve facilitates rapid solution exchange and residue removal between batches.
• Split-system architecture allows independent servicing of generator electronics and tank assembly—minimizing downtime during preventive maintenance.

Sample Compatibility & Compliance

The SCQ-25-08 accommodates a wide range of sample types, including borosilicate glassware (vials, flasks, pipettes), stainless steel tools, ceramic substrates, printed circuit boards (PCBs), and reusable surgical instruments. It is compatible with deionized water, alkaline detergents (e.g., Alconox®, Tergazyme®), and low-volatility solvents (e.g., isopropanol, ethanol) when used within appropriate ventilation and safety protocols. While the unit does not include heating or temperature regulation, its design conforms to IEC 61000-6-3 (EMC emission standards) and IEC 61000-6-2 (immunity requirements). All electrical components meet CE marking criteria for laboratory equipment under Directive 2014/30/EU (EMC) and 2014/35/EU (LVD). The stainless steel construction complies with ISO 8502-3 for surface cleanliness verification prior to coating or bonding processes.

Software & Data Management

The SCQ-25-08 is a manually operated instrument with no embedded microprocessor or digital interface. Its mechanical timer provides deterministic, non-volatile timing without software dependencies—ensuring operational continuity in regulated environments where firmware validation is impractical. For laboratories requiring audit-ready documentation, external data loggers may be used to record start/stop timestamps, cycle duration, and operator ID per cleaning batch. Though lacking native 21 CFR Part 11 compliance features, the device supports GLP/GMP workflows when integrated into SOP-driven cleaning protocols that define acceptance criteria, solution change intervals, and periodic performance verification (e.g., aluminum foil test per ASTM D2603 or conductivity-based residue detection).

Applications

• Routine cleaning of volumetric glassware and chromatography vials prior to HPLC or GC analysis.
• Removal of polishing compounds and metal fines from optical lenses and semiconductor wafers.
• Pre-sterilization cleaning of endoscopic components and dental handpieces in clinical settings.
• Decontamination of filter housings, membrane modules, and sampling probes used in environmental monitoring.
• Supporting ASTM E1979 (Standard Guide for Ultrasonic Cleaning) and ISO 13485-compliant cleaning validation studies.
• Batch cleaning of 3D-printed polymer parts to eliminate uncured resin and support material residues.

FAQ

Is the SCQ-25-08 suitable for cleaning delicate optics or MEMS devices?

Yes—when operated at 40 kHz with low-surface-tension, non-ionic cleaning solutions and controlled exposure time (typically ≤5 min), it effectively removes submicron particles without damaging coated or etched surfaces.
Does the unit include a heater or temperature control?

No. The SCQ-25-08 is a non-heating model. External heated baths or pre-warmed solutions must be used if thermal assistance is required.
Can the ultrasonic frequency be changed on this model?

No. The SCQ-25-08 is configured exclusively for 40 kHz operation. Optional frequency variants (24 kHz, 28 kHz, 60 kHz) are available under separate model numbers.
What maintenance is required for long-term reliability?

Quarterly inspection of transducer plate adhesion, annual verification of generator output stability using calibrated hydrophone measurements, and routine cleaning of the tank interior to prevent mineral buildup.
Is the drain valve compatible with standard laboratory floor drain connections?

Yes—the outlet uses a 1/2-inch NPT thread, allowing direct connection to common lab drainage hoses or waste collection systems.
