| Brand | Taecheng |
|---|---|
| Origin | South Korea |
| Model | TSA-101 / TSA-102 / TSA-103 |
| Temperature Range | 0–540 °C |
| Temperature Uniformity | ±1.0 °C (at setpoint) |
| Temperature Stability | ±1.0 °C |
| Internal Chamber Dimensions | 200 × 200 × 200 cm |
| External Dimensions | 300 × 300 × 300 cm |
| Operating Ambient Temperature | 15–60 °C |
| Heating Power | 6.3 kW (9 × 0.7 kW heating plates) |
| Total Electrical Capacity | 7.85 kW |
| Power Supply | 3-phase, 220 V or 380 V |
| Airflow Rate | 25 m³/min |
| Adjustable Air Velocity | 1–5 m/s (standard operating velocity: 3 m/s) |
| Chamber Liner Material | SUS 316 stainless steel (1.5 mm thickness) |
| Sample Tray | 1 × SUS 304 tray with electric vertical lift mechanism |
| Safety Systems | Dual-stage overtemperature protection (digital controller + independent safety limiter), explosion-relief safety door with automatic power cutoff, intrinsically safe blower motor (1.5 kW inverter-driven, flameproof), ceramic fiber insulation (HEAT-LAB certified), sample surface temperature monitoring probe, motor thermal relay, tray locking mechanism, ambient air intake damper, audible alarm for fault conditions |
| Weight | ~600 kg |
| Mobility | Four swivel casters with locking brakes |
| Brand | TEA SUNG |
|---|---|
| Origin | South Korea |
| Model | TSA-102 |
| Oven Type | High-Temperature Forced-Air Drying Oven |
| Temperature Range | 0–540 °C |
| Temperature Uniformity | ±1.0 °C (at setpoint, measured per ISO 17025-compliant internal mapping) |
| External Dimensions | 300 × 300 × 300 cm (W × H × D) |
| Internal Chamber Dimensions | 200 × 200 × 200 cm (W × H × D) |
| Heating Power | 6.3 kW (9 × 0.7 kW heating plates) |
| Total Electrical Capacity | 7.85 kW |
| Supply Voltage | 3-phase, 220 V or 380 V |
| Airflow Rate | 25 m³/min |
| Adjustable Air Velocity | 1–5 m/s |
| Fan Motor | 1.5 kW inverter-driven explosion-proof motor (SUS 304 construction) |
| Chamber Liner Material | SUS 316 stainless steel, 1.5 mm thickness |
| Shelf | 1 × SUS 304 adjustable shelf with electric vertical lift mechanism |
| Insulation | Full-ceramic fiber (HEAT-LAB certified), rated for continuous operation up to 540 °C |
| Safety Systems | Dual independent overtemperature cut-off (digital PID + mechanical backup), explosion-relief safety door with automatic power cutoff, airflow failure detection, motor thermal relay protection, sample surface temperature monitoring probe, and audible alarm for abnormal conditions |
| Weight | Approx. 600 kg |
| Mobility | Four locking casters (industrial-grade, non-marking) |
