| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Model | ZH-VDO Series |
| Temperature Range | 5–250 °C |
| Temperature Uniformity | ≤ ±1 °C (at setpoint, under vacuum) |
| Chamber Dimensions (W×D×H) | 300 × 300 × 270 mm |
| External Dimensions (W×D×H) | 478 × 500 × 717 mm |
| Chamber Material | 304 Stainless Steel |
| Heating Method | Electric Resistive Heating |
| Vacuum Compatibility | Integrated with external vacuum pump interface (ISO-KF 25 or NW25 flange) |
| Control System | Dual-display microprocessor PID controller with real-time temperature and vacuum status readout |
| Door | Double-layer tempered glass viewport with silicone-gasketed airtight seal |
| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Instrument Type | High-Temperature Forced-Air Oven |
| Temperature Range | Ambient +10°C to 300°C |
| Temperature Uniformity | ≤ ±1°C |
| External Dimensions | 1260 × 1460 × 1670 mm |
| Internal Chamber Dimensions | 1000 × 1000 × 1200 mm |
| Chamber Material | Stainless Steel (AISI 304) |
| Heating Method | Electric Resistive Heating |
| Door | Dual-Layer Tempered Glass with Observation Window |
| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Model | DHB |
| Instrument Type | Forced-Air Drying Oven |
| Maximum Operating Temperature | 250 °C |
| Heating Method | Electric Resistance Heating with Forced Convection |
| Chamber Material | Stainless Steel (AISI 304) |
| External Construction | Stainless Steel Clad |
| Temperature Uniformity | ±1.5 °C at 100 °C (typical, per ISO 17025-compliant validation) |
| Compliance | Designed to support GLP/GMP-relevant thermal processing workflows |
| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Instrument Type | Vacuum Drying Oven |
| Maximum Operating Temperature | 250 °C |
| Heating Method | Electric Resistance Heating with Forced Air Circulation |
| Chamber Construction | Fully Stainless Steel (Interior and Exterior Walls, except viewing window and hardware) |
| Door | Dual-Layer Tempered Glass with Observation Window |
| Control System | Microprocessor-Based Dual-Display Temperature Controller |
| Vacuum Compatibility | Integrated Vacuum Port for External Vacuum Pump Connection |
| Compliance | Designed to Support GLP/GMP-aligned laboratory workflows |
| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Model | DHG Series |
| Temperature Range | +10–250 °C |
| Temperature Uniformity | ≤ ±1 °C (at 100 °C, steady state) |
| Chamber Dimensions (W×D×H) | 350 × 350 × 350 mm |
| External Dimensions (W×D×H) | 508 × 530 × 785 mm |
| Interior Material | 304 Stainless Steel |
| Heating Method | Electric Resistive Heating with Axial Fan Circulation |
| Application Class | General-Purpose Laboratory Drying & Thermal Stabilization Oven |
| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Instrument Type | High-Temperature Forced-Air Drying Oven |
| Temperature Range | 20–500 °C |
| Temperature Uniformity | ≤ ±1.5 °C |
| External Dimensions | 770 × 830 × 1100 mm |
| Internal Chamber Dimensions | 450 × 550 × 550 mm |
| Chamber Material | Stainless Steel (AISI 304) |
| Heating Method | Electric Resistance Heating |
| Air Circulation | Motor-Driven Forced Convection |
