| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Model | HTSWT-02G |
| Max Operating Temperature | 1600 °C |
| Reaction Chamber Diameter | Φ50 mm / Φ70 mm (optional) |
| Effective Chamber Length | 100 mm |
| Sample Dimensions | 30 × 20 × 4 mm |
| Sample Mounting Angle | 30°–45° (adjustable) |
| Heating Element | Silicon Molybdenum Rod |
| Heater Tube Material | Alumina |
| Steam Generation Range | 5–100% RH (or arbitrary humidified gas mixture) |
| Evaporator Temp Limit | ≤150 °C |
| Trace Gas Line Heat Tracing | ≤120 °C |
| Max Steam Flow Rate | 30 L/min |
| Max Steam Velocity | 160 m/s |
| Carrier Gas Control | Mass Flow Controller (up to 5 L/min) |
| Pressure | Ambient (atmospheric) |
| Voltage | 220 V AC |
| Power Rating | 5.5 kW |
| Control Interface | 10.4″ Integrated Touchscreen with PLC-Based Multi-Module Architecture |
| Temperature Program | 50-Step Ramp/Soak Profile |
| Temperature Stability | ±1 °C |
| Data Logging | Real-Time Trend Curves & Exportable Reports (CSV/PDF) |
| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Model | HTWOS-01G |
| Max Operating Temperature | 1600 °C |
| Reaction Chamber Diameter | Φ50 mm / Φ70 mm (optional) |
| Effective Chamber Length | 100 mm |
| Sample Dimensions | 30 × 20 × 4 mm |
| Sample Mounting Angle | 30°–45° (adjustable) |
| Heating Element | Silicon Molybdenum (MoSi₂) Rods |
| Heating Zone Material | Alumina (Al₂O₃) Tube |
| Steam Generation Range | 5–100% RH (or arbitrary humid gas mixture) |
| Evaporator Temp Limit | ≤150 °C |
| Trace Gas Line Heat Tracing | ≤120 °C |
| Max Steam Flow Rate | 30 L/min |
| Max Steam Velocity | 160 m/s |
| Carrier Gas Control | Mass Flow Controller (MFC), 5 L/min full scale |
| Operating Pressure | Ambient (1 atm) |
| Control Interface | 10.4″ Industrial Touchscreen HMI with PLC-based Multi-Module Architecture |
| Temperature Control Accuracy | ±1 °C |
| Programmable Ramp/Soak Profiles | 50-segment |
| Data Logging | Real-time Trend Curves & Exportable CSV Reports |
