| Brand | Zhonghuan Furnace |
|---|---|
| Origin | Tianjin, China |
| Model | YA-Y16 |
| Temperature Range | RT–1600 °C (≤1400 °C under load) |
| Heating Rate | 0–20 °C/min adjustable |
| Heating Element | MoSi₂ rods |
| Thermocouple Type | Type B |
| Temperature Control Accuracy | ±1 °C |
| Temperature Measurement Accuracy | Class 0.2 |
| Sample Chamber Dimensions | 80 × 100 × 140 mm |
| Standard Sample Size | 3 × 8 × 60 mm |
| Fixture Material | Alumina |
| Indenter Material | Silicon Carbide |
| Maximum Load Capacity | 5 kN |
| Dimensional Shrinkage Resolution | 1 µm (dual-lens mode) / 10 µm (single-lens mode) |
| Image Acquisition Frequency | User-configurable |
| Power Supply | 220 V, 50 Hz, 5 kW |
| Brand | ZHONGHUAN FURNACE |
|---|---|
| Origin | Tianjin, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | HTV-2000 |
| Operating Temperature Range | Ambient to 2000 °C |
| Vacuum Level | ≤1×10⁻³ Pa |
| Atmosphere Options | High Vacuum or Inert Gas (Ar/N₂) |
| Heating Zone Dimensions | 550 mm × 60/50 mm (L×Φ) |
| Uniform Temperature Zone Length | 40 mm |
| Sample Size Range | 2×2 mm to 15×15 mm |
| Image Resolution | 10 µm/pixel |
| Dimensional Measurement Accuracy | ±10 µm per pixel |
| Contact Angle Range (optional module) | 0–180° |
| Contact Angle Precision (optional module) | ±0.1° |
| Power Supply | 380 V, 30 kW |
| Instrument Dimensions | 1080×1560×1866 mm |
| Net Weight | 830 kg |
