| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Model | GYPS-150 |
| Temperature Range | 0–65°C |
| Temperature Uniformity | ±1.5°C |
| Temperature Fluctuation | ±0.5°C |
| Humidity Range | 30–95% RH (customizable to 20–98% RH) |
| Humidity Deviation | ±3–5% RH |
| Illumination Intensity | 0–25,000 lx (LED, tri-face or vertical configuration) |
| UV Spectrum | UVA (320–400 nm) and UVB (280–320 nm), independently controllable |
| Control System | 7-inch color touchscreen with PID auto-tuning, 999 programmable profiles (100 segments each) |
| Data Logging | Internal storage + USB export to Excel/CSV with timestamps, alarms, and audit trail |
| Compliance | Designed per ICH Q1, USP <1151>, 2015 Chinese Pharmacopoeia Stability Guidelines, GB/T 10586–2006, and GMP data integrity requirements (ALCOA+ principles) |
| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | TDK Series |
| Price Range | USD 280 – 14,000 |
| Temperature Range (Refrigerated Models) | 15–70 °C |
| Refrigeration Capability | Down to 20 °C (±0.3 °C stability) |
| Temperature Resolution | 0.1 °C |
| Heating Power | 1000 W (TDK-24R) |
| Tank Capacity | 24 L |
| Internal Dimensions (TDK-24R) | 400 × 200 × 300 mm (L×W×H) |
| External Dimensions (TDK-24R) | 470 × 230 × 810 mm |
| Timer Range | 1–9999 min |
| Power Supply | AC 220 V, 50 Hz |
| Insulation | ≥5 mm mineral wool |
| Construction | 304 stainless steel inner chamber & lid, electrostatically sprayed steel outer casing |
| Optional Accessories | Dry-run protection, auto-refill (external water source required), 30-segment programmable temperature controller, RS485 interface with PC communication software |
| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Product Category | Domestic |
| Model | TDK-36R |
| Price Range | USD 590 – 910 |
| Temperature Range | 0–100 °C (standard operation 5–100 °C) |
| Inner Chamber Dimensions | 300 mm × 300 mm × 400 mm (W×D×H) |
| Bath Depth | 400 mm |
| Visual Chamber | Transparent Front Panel |
| Construction | 304 Stainless Steel Interior & Lid, Electrostatically Sprayed Steel Exterior |
| Heating System | Submersible Sealed Immersion Heater |
| Control System | Microprocessor-Based PID Controller with LED Display, Timer Function, Auto-Tuning |
| Safety Features | Dry-run Protection (Water Level Sensor), Over-Temperature Alarm & Cut-off, Power-Fail Parameter Memory, Auto-Recovery on Power Restoration |
| Optional | Integrated Circulation Pump (for Uniform Temperature Distribution), R-Series Compressor Cooling Module (for sub-ambient operation down to –10 °C), 30-Stage Programmable Temperature Ramp Profile, Auto-Fill Kit (external water source required) |
| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | ZDM Series |
| Price Range | USD 7,000 – 16,800 |
| Vacuum Level | ≤133 Pa |
| Temperature Range | RT+10°C to 200°C |
| Temp. Resolution | 0.1°C |
| Temp. Uniformity | ±0.1°C |
| Chamber Volume | 90 L / 125 L / 210 L |
| Chamber Dimensions | 450×450×450 mm / 500×500×500 mm / 550×550×650 mm |
| Control System | PLC with Color Touchscreen HMI |
| Sample Capacity | Up to 4 wafer cassettes |
| Process Compatibility | Thermal Evaporation, Sputtering, PECVD, PLD, MBE |
| Compliance | RoHS, REACH |
