| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | ZGC Series |
| Illumination Configuration | Triple-Sided LED Illumination |
| Light Source | High-Efficiency White LED (Standard) |
| Spectral Range | Visible Spectrum (400–700 nm) |
| Temperature Control Range | 0–65°C (Dark), 10–65°C (Illuminated) |
| Temperature Fluctuation | ±0.5°C |
| Temperature Uniformity | ±0.5°C |
| Humidity Control | None (Dry Chamber) |
| Illuminance Range | 0–6,000 lx (ZGC-150-I) to 0–25,000 lx (ZGC-800/T, ZGC-1000/T) |
| Illuminance Adjustment | 4-Step (Single-Side), 6-Step (Dual- or Triple-Side) |
| Chamber Capacity | 150 L to 1000 L |
| External Dimensions | 605×625×1375 mm to 1410×890×1950 mm |
| Power Supply | AC 220 V, 50 Hz |
| Refrigerant | R134a (CFC-Free) |
| Heating Element | Nickel-Chromium Alloy Heater |
| Cooling System | Modular Compressor with Start-Delay & Cycle Protection |
| Air Circulation | Optimized Axial Flow Duct Design with Baffle-Guided Convection |
| Control Interface | 30-Stage Programmable LCD Controller (Standard) |
| Compliance | Designed per IEC 61000-6-3 (EMC), GB/T 2423.2 (High-Temp Testing), and ISO 14644-1 Class 8 Cleanroom-Compatible Surface Finish (Stainless Steel Interior) |
| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | ZGC Series |
| Price Range | USD 14,000 – 18,500 |
| Light Delivery Method | Shelf-Integrated Illumination |
| Light Source | Full-Spectrum LED (350–800 nm) |
| Spectral Range | Visible Spectrum (350–800 nm) |
| Temperature Range (Dark) | 0–50 °C |
| Temperature Range (Illuminated) | 5–50 °C |
| Temperature Uniformity | ±1 °C |
| Temperature Fluctuation | ±1 °C |
| Humidity Range | 40–95 %RH |
| Humidity Fluctuation | ±3–5 %RH |
| Humidity Control Accuracy | ±1 %RH |
| Illuminance Range | 0–25,000 lx |
| Light Intensity Adjustment | Stepless (Continuous) Dimming |
| Illumination Levels | 3 Independent Layers |
| Light Control | Per-Shelf Direct Numeric Input |
| Chamber Capacity | 150–1100 L |
| External Dimensions | Customizable |
| Internal Working Chamber Dimensions | 1320 × 660 × 1280 mm (W × D × H) |
| Display | ≥4-inch Color Touchscreen Controller with Multi-Stage Programmability |
| Connectivity | Wireless PC Interface (Real-Time Monitoring, Parameter Editing, Data Export) |
| Security | Multi-Level Password Protection |
| Air Circulation | Low-Noise Axial Fan System |
| Ventilation | Passive Fresh Air Exchange Port |
| Cooling System | Eco-Friendly Refrigerant, All-Copper Heat Exchangers |
| Heating System | High-Precision PID-Controlled Stainless Steel Finned Heater |
| Insulation | Monolithic High-Density Polyurethane Foam (≥80 mm) |
| Interior Construction | 304 Stainless Steel |
| Exterior Construction | Powder-Coated Cold-Rolled Steel |
| Lighting Mounting | Anodized Aluminum Frame with Transparent Polycarbonate Protective Covers |
| Electrical Interface | IP65-Rated Snap-Connect Waterproof Cabling |
| Door Lock | Mechanical Tamper-Resistant Latch |
| Brand | DRETOP |
|---|---|
| Origin | Shanghai, China |
| Model | ZGC-800T |
| Illumination Method | Triple-side LED illumination |
| Light Spectrum | Full visible spectrum (400–780 nm) |
| Temperature Range | 10–65°C (with light), 0–65°C (without light) |
| Temperature Fluctuation | ±0.5°C |
| Humidity Capacity | Up to 95% RH |
| Illuminance Range | 0–25,000 lx |
| Light Intensity Control | 0–100 stepless adjustable levels |
| Chamber Volume | 800 L |
| External Dimensions (W×D×H) | 1050 × 1150 × 1800 mm |
| Control Interface | Color TFT touchscreen |
| Cooling System | Eco-friendly R134a refrigerant |
| Heating Element | Nickel-chromium alloy heater |
| Air Circulation | Optimized axial airflow duct design |
| Compliance | Designed for GLP-compliant plant physiology and microbiological research environments |
