| Brand | NewOpto |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Quantas Q1-1053 / Q2-1053 |
| Light Source Type | Infrared Pulsed Solid-State Laser |
| Illumination Mode | External Illumination |
| Wavelength | 1053 nm (1047 nm optional) |
| Fundamental Output Energy | 5–70 mJ |
| Harmonic Outputs | 527 nm (2–35 mJ), 351 nm (1–20 mJ), 263 nm (0.6–11 mJ), 211 nm (0.15–3.5 mJ) |
| Repetition Rate | 10 Hz (factory-fixed) |
| Pulse Width | < 8 ns |
| Pulse-to-Pulse Energy Stability | < 1 % rms (Q1), < 0.7 % rms (Q2) |
| Power Drift | ±3% |
| Beam Profile | Near TEM₀₀, >75% Gaussian |
| Beam Divergence | < 3 mrad (Q1A) to < 1.5 mrad (Q1C/Q1D) |
| Beam Diameter | 1.2–3.0 mm |
| Polarization | Linear, horizontal |
| Optical Jitter | < 1 ns rms |
| Laser Head Dimensions | 113 × 230 × 112 mm (Q1), 113 × 400 × 112 mm (Q2-1053) |
| Harmonic Generator | 113 × 242 × 112 mm |
| Controller Unit | 85 × 165 × 50 mm |
| Power Adapter | 50 × 125 × 32 mm |
| Operating Environment | 15–30°C, 10–80% RH (non-condensing), 90–230 VAC, 30 W, 47–63 Hz |
| Brand | ScanSci |
|---|---|
| Model | ScanSource |
| Spectral Range | 200–1100 nm (standard), optional down to 180 nm |
| Lamp Types | Deuterium (D₂) + Tungsten-Halogen (W) |
| Deuterium Power | 30 W |
| Tungsten Power | 9 W |
| Output Stability (Fluctuation) | ≤2×10⁻⁵ A.U. |
| Long-Term Drift | ±0.3 %/h (D₂), ±0.25 %/h (W) |
| External Control | Shutter, Lamp On/Off, Main Power On/Off |
| Fiber Coupling | SMA 905 |
| Deuterium Lamp Lifetime | 2000 h |
| Tungsten Lamp Lifetime | 2000 h |
| Cooling | Active (fan-cooled) |
| Dimensions | 157 × 178 × 250 mm |
| Compliance | CE, RoHS |
| Brand | NewOpto |
|---|---|
| Origin | Zhejiang, China |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Domestic (China) |
| Model | LLS-LEDs |
| Light Source Type | Solid-State LED |
| Illumination Mode | External Illumination |
| Connector Type | SMA 905 |
| Wavelength Range | 240 nm – 2100 nm |
| Spectral Options | UV, Visible, NIR, Broadband White (3000K–6500K CCT) |
| Coupling | FC/PC or SMA fiber-coupled output |
| Compliance | RoHS-compliant construction, CE-marked for laboratory use |
| Origin | USA |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | NewOpto LS-1 / LS-2 |
| Price | Available Upon Request |
| Brand | NewOpto |
|---|---|
| Origin | Zhejiang, China |
| Model | NewOpto-LEDs |
| Wavelength Range | 225–350 nm |
| Output Power Options | 1–3 mW, 3–5 mW, 10–15 mW, 30–50 mW |
| Emission Window Types | Flat or Hemispherical |
| Spectral FWHM | 12 nm (255 nm), ±5 nm (255–315 nm), ±10 nm (330–350 nm) |
| Package Formats | TO-39, TO-3, LCC |
| Drive Current | 80–900 mA |
| Illumination Mode | External (free-space) |
| Optional Accessories | Constant-current drivers (UVCLEAN-PS-DC-C), pulsed power supplies (UVCLEANPPS1μs/1A, UVCLEANPPS10ns/5.5A), SMA-fiber-coupled and pigtail configurations |
| Multi-wavelength Modules | 8-channel (TO-3), 12-channel (TO-5), 24-channel (LCC) |
| Brand | NewOpto |
|---|---|
| Origin | Zhejiang, China |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Domestic (China) |
| Model | Tunable External-Cavity Diode Laser (ECDL) |
| Light Source Type | Tunable Single-Frequency Semiconductor Laser |
| Illumination Mode | External Illumination |
| Wavelength Options | 780 nm, 852 nm |
| Output Power | Up to 30 mW (diode-dependent) |
| Linewidth (FWHM) | Typically <150 kHz |
| Tuning Range | Typical 10 nm per diode configuration |
| Tuning Mechanism | Cat’s-eye retroreflector + ultra-narrowband interference filter (replacing alignment-sensitive diffraction gratings) |
| Origin | USA |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | sub-THz IMPATT Diode Generator |
| Price Range | USD $4,200 – $7,000 (FOB) |
| Light Source Type | Solid-State Coherent Sub-Terahertz Source |
| Illumination Mode | External Irradiation |
