| Brand | Edmund Bühler |
|---|---|
| Origin | Germany |
| Model | MSP60 |
| Vacuum Chamber | High-vacuum compatible (≤1×10⁻⁵ mbar) |
| Copper Wheel Diameter | 250 mm (solid, optionally water-cooled) |
| Wheel Tilt Adjustment | Continuous angular control for optimized melt jet impingement |
| Crucible Options | 3-piece boron nitride crucible with adapter |
| RF Generator Power | 12 kW or 25 kW (configurable) |
| Temperature Monitoring | Pyrometer range 500–1700 °C (calibration traceable to NIST standards) |
| Melt Volume Capacity | 5–10 g per run |
| Cooling Rate | >10⁶ K/s (typical for amorphous ribbon formation) |
| Control Interface | Integrated touchscreen HMI with real-time display of wheel speed, RF power, melting duration, vacuum level, and pyrometer feedback |
| Auxiliary Systems | Recirculating chiller (required), compressed air supply (4–6 bar), turbo-molecular or diffusion pump train |
