| Origin | Europe |
|---|---|
| Detector Type | Back-Illuminated CCD Array (1044 × 64 pixels, 24 µm × 24 µm) |
| Spectral Range | 200–980 nm |
| Optical Resolution (FWHM) | 3–4 nm |
| Wavelength Accuracy | < 0.5 nm |
| Repeatability | < 0.1 nm |
| Thermal Drift | < 0.01 nm/K |
| Stray Light | 0.1% @ 340 nm (Xe lamp) |
| Integration Time | 1 ms to several minutes |
| Acquisition Rate | Up to 100 spectra/s (16-bit digitization) |
| Input Interface | Removable SMA-905 connector (Ø0.5 mm, NA = 0.22) |
| Slit Dimensions | 70 µm × 1400 µm |
| Grating | Flat-field corrected holographic grating |
| Pixel Dispersion | ~0.8 nm/pixel |
| Flash Detection Capability | 10 µs – 10 ms transient events |
