Engine Fuel Oil Physical Properties Tester
Filter
Showing all 28 results
| Brand | EMCEE |
|---|---|
| Origin | USA |
| Model | 1153 |
| Measurement Range | 0–2000 pS/m |
| Resolution | ±1 pS/m (0–2000 pS/m) |
| Accuracy | ±2% of reading |
| Operating Temperature | 0–50 °C |
| Display | 5-digit LCD with status text and LED illumination |
| Power | Three 3 V lithium batteries |
| Dimensions | 200.7 × 70 × 43.2 mm (L×W×D) |
| Probe Diameter | 19.05 mm |
| Weight | 365.8 g (12.9 oz) |
| Enclosure | Intrinsically Safe for Class I, Division 1, Group D hazardous locations |
| Compliance | ASTM D2624 |
| Optional Features | Temperature measurement mode, data hold, solvent-resistant hard-shell carrying case with O-ring sealed probe interface |
| Brand | EMCEE |
|---|---|
| Origin | USA |
| Model | Model 1152 |
| Measurement Range | 0–1999 pS/m |
| Resolution | 1 pS/m |
| Accuracy | ±2% of reading + 1 pS/m |
| Display | 3-digit LCD, digit height 0.27 cm |
| Power Supply | 3 × alkaline batteries (6 V total) |
| Operating Temperature | 0–75 °C |
| Probe | Removable stainless-steel, intrinsically safe |
| Safety Certifications | UL, CSA (Canada), LCIE |
| Calibration | Internal reference, field-adjustable via two-button interface ("M" for Measure, "C" for Calibrate) |
| Overrange Indication | Leading "1" on display |
| Enclosure | Solvent-resistant molded polymer housing |
| Grounding | Banana jack terminal |
| Battery Low/Overrange Alerts | Visual indicators |
| Origin | Norway |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | F-100 |
| Pricing | Upon Request |
| Brand | FuLand / csfriend |
|---|---|
| Origin | Hunan, China |
| Model | Compliant with GB/T 5096 |
| Temperature Range | Ambient to 150 °C |
| Temperature Control Accuracy | ±0.1 °C |
| Heating Power | 1200 W |
| Display | LCD (English/Chinese) |
| Test Stations | 6 |
| Diagnostic Function | Built-in Self-Diagnosis & Auto-Tuning Capability |
| Oxygen Bomb Storage Compartment | Integrated |
| Brand | Fland (csfriend) |
|---|---|
| Model | FDR-0571 |
| Standard Compliance | GB/T 8019 |
| Temperature Range | Ambient to 200 °C |
| Temperature Resolution | 0.01 °C |
| Display | 7-inch Touchscreen (Chinese/English Optional) |
| Weighing Precision | 0.0001 g (Integrated METTLER Toledo Analytical Balance) |
| Power Supply | 220 V, 50 Hz |
| Data Export Interface | Optional RS232/USB for LIMS Integration |
| Brand | Flanland / csfriend |
|---|---|
| Origin | Hunan, China |
| Model | FDR-1431 |
| Standards Compliance | SH/T 0701, SH/T 0702 |
| Temperature Control Range | Ambient to 100 °C |
| Temperature Accuracy | ±0.5 °C |
| Vacuum Pressure | 40 kPa ± 2 kPa (displayed via precision pressure gauge) |
| Timing Resolution | 0.01 s, max duration 99 h 99 m 99 s |
| Sample Capacity | Dual independent test units |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Rated Power | 2000 W |
| Operating Environment | 0–45 °C, ≤80% RH |
| Display | LCD with bilingual (Chinese/English) interface |
| Brand | Koehler |
|---|---|
| Origin | USA |
| Model | K33900 |
| Compliance | ASTM D381, IP 131, ISO 6246, DIN 51784, FTM 791-3302, NF M07004 |
| Configuration | 6-position aluminum block bath with integrated steam superheater |
| Temperature Range | Up to 246 °C (475 °F) |
| Temperature Stability | ±0.5 °C |
| Heating Power | 0–3000 W |
| Steam Superheater | Stainless steel chamber, solid-state temperature control (0–290 °C), dry saturated steam delivery |
| Air/Steam Flow Control | Digital mass flow meter + pressure regulator with gauge |
| Safety | Over-temperature cut-off circuit, insulated aluminum block, dual LED display (°C/°F), PID microprocessor temperature control |
| Electrical | 220–240 V, 50/60 Hz, single-phase, 30 A |
| Dimensions (W×D×H) | 53.34 × 52.07 × 71.12 cm |
| Net Weight | 104.3 kg |
| Brand | Koehler |
|---|---|
| Origin | USA |
| Model | K94190 |
| Compliance | ASTM D5001 |
| Test Principle | Ball-on-Cylinder Lubricity Evaluation (BOCLE) |
| Sample Volume | 50 ± 1.0 mL |
| Test Temperature | 25 ± 1 °C |
| Regulated Air RH | 10 ± 0.2 % at 25 °C |
| Dry/Air Flow Rates | 0.5 L/min (through sample), 3.8 L/min (over test surface) |
| Load | 1000 g (±1 g) |
| Cylinder Speed | 240 ± 0.5 rpm |
| Test Duration | 30 ± 0.1 min |
| Test Ring | SAE 8720 steel, Ø49.10–49.25 mm × 13.0–13.11 mm, hardness 58–62 Rc, Rq 0.51–0.71 µm |
| Test Ball | AISI 52100 steel, Ø12.7 mm, hardness 64–66 Rc |
| Power Supply | 230 V AC, single-phase, 5 A |
| Origin | Japan |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | HT-201 |
| Price | Upon Request |
| Brand | Linetechnic |
|---|---|
| Origin | Switzerland |
| Model | 225 / D2068 |
| Compliance | ASTM D2068, IP 387 |
| Operating Temperature Range (Bath) | −10 °C to +40 °C |
| Sample Temperature Range | −50 °C to +80 °C |
| Flow Rate | 20 mL/min |
| Pressure Measurement Range | 0–210 kPa |
| Max. Pressure Threshold | 105 kPa |
| Filtration Capacity Resolution | 0.1 mL |
| Temperature Sensor | PT100 Class A |
| Bath Material | Anodized Aluminum |
| Cooling System | Single-phase air-cooled compressor, CFC-free refrigerant |
| Data Storage Capacity | 60,000 test records |
| Display | 6.4″ TFT/LCD touchscreen (640 × 480 pixels) |
| Processor | AMD Geode 800 |
| Interface | 1 × USB, 1 × 10/100 Mbps LAN |
| Safety Certification | CE |
| Brand | Linetechnic |
|---|---|
| Origin | Switzerland |
| Model | 700 |
| Standard Compliance | ASTM D5191, ASTM D323, IP 394 |
| Measurement Principle | Vapor Pressure via Air-Saturation Method at 37.8 °C |
| Sample Volume | 3 mL |
| Test Chamber Volume | 15 mL |
| Chamber Temperature Control | 37.8 °C ± 0.1 °C (PT100, 1/10 DIN accuracy) |
| Sample Temperature Control | 0 °C (external chiller required) |
| Pressure Range | 0–10 bar absolute (0–145 psi) |
| Vacuum System | Integrated vacuum pump interface |
| Dimensions (W×D×H) | 30 × 70 × 60 cm |
| Weight | 27 kg |
| Power Supply | 230 V / 50 Hz |
| Ambient Operating Conditions | ≤35 °C, ≤80% RH |
| Brand | Linetechnic |
|---|---|
| Origin | Switzerland |
| Model | 226 (ASTM D4539 Compliant) |
| Cooling Range | +80 °C to −45 °C |
| Temperature Accuracy | ±0.1 °C |
| Temperature Resolution | 0.06 °C |
| Vacuum Control | Precisely regulated at 20 kPa |
| Sample Capacity | 6 × 300 mL positions |
| Cooling Rate | 1 °C/h |
| Pass Criterion | ≥180 mL filtrate collected within 60 s under vacuum |
| Temperature Sensor | PT100 Class A |
| Built-in Control System | AMD Geode800 CPU, 12″ TFT touchscreen (1024 × 768), 60,000-test storage capacity |
| Refrigerant | CFC-free compressor system |
| Brand | North |
|---|---|
| Origin | Liaoning, China |
| Manufacturer Type | Authorized Distributor |
| Country of Manufacture | China |
| Model | BF-08 |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Evaporation Bath Heating Power | 2000 W |
| Number of Test Positions | 3 |
| Air Flow Rate at Ambient Temperature | 600 mL/s ±90 mL/s |
| Outlet Air Velocity | 1000 mL/s ±150 mL/s |
| Bath Material | Anodized Aluminum |
| Temperature Control | Digital Intelligent PID Controller |
| Bath Geometry | Helical Air Path with Precision-Drilled Orifices |
| Temperature Monitoring | Dual-Sensor Configuration (Thermometer + RTD Sensor) |
| Compliance Standard | GB/T 8019–2008 |
| Brand | PCS Instruments |
|---|---|
| Origin | United Kingdom |
| Model | ABS |
| Power Supply | 100–230 V AC, 750 VA |
| Operating Temperature | 15–35 °C |
| Operating Humidity | 20–80 % RH (non-condensing) |
| Weight | 34 kg |
| Dimensions | Not specified |
| Compressed Air Requirement | ASTM D5001-compliant (≤0.1 ppm hydrocarbons), dry and oil-free |
| Deionized Water Reservoir Capacity | ~1000 tests per fill |
| Control | Microprocessor-based, fully automated |
| Environmental Compliance | Designed for ISO/IEC 17025-aligned laboratories |
| Software Interface | PC-based control and data logging with audit-trail capability |
| Brand | PCS Instruments |
|---|---|
| Origin | United Kingdom |
| Model | HFRR |
| Frequency Range | 10–200 Hz |
| Stroke Range | 20 µm–2.0 mm |
| Load Capacity | 0–1.0 kg (via calibrated weights) |
| Maximum Friction Force | up to 10.0 N (amplitude-dependent) |
| Operating Temperature | ambient to 150 °C (up to 400 °C with optional high-power heating module) |
| Standard Counterface | 10.0 mm diameter × 3.0 mm thick steel disc |
| Standard Indenter | 6.0 mm diameter hardened steel ball |
| Compliance | ASTM D6079, ASTM D7688, ISO 12156-1, SH/T 0765–2021 |
| Brand | R&P |
|---|---|
| Origin | Germany |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | VP4000 |
| Pricing | Upon Request |
| Standards Compliance | DIN 51581, CEC L-40-A-93, ASTM D5800 |
| Temperature Range | 150–260 °C |
| Temperature Accuracy | ±0.2 °C |
| Temperature Resolution | 0.1 °C |
| Temperature Stability | < ±0.5 °C at Setpoint |
| Air Flow Control | Adjustable via valve or flowmeter |
| Max Differential Pressure | 21 mmWS |
| Pressure Accuracy | ±0.02 mmWS |
| Test Duration | Fixed 60 min |
| Display | LCD showing real-time temperature, pressure, and elapsed time |
| Dimensions (W×D×H) | 278 × 300 × 316 mm |
| Net Weight | 14 kg |
| Gross Weight | 23 kg |
| Included Components | Main unit, vacuum pump with oil filter, evaporation crucible, test ball, differential pressure controller |
| Brand | SETA |
|---|---|
| Origin | United Kingdom |
| Model | 91600-3 |
| Compliance | ASTM D2068, IP 387 (Procedures A, B & C), ASTM D6426 (Cold Soak), IP PM EA/08 |
| Filtration Plug Trend Range | 1.0–30 |
| Filterability Quality Factor Range | 100–1 |
| Maximum Test Pressure | 200 kPa |
| Power Consumption | 500 W |
| Dimensions | 27 × 43 × 26 cm |
| Weight | 10 kg |
| Brand | Shenkai |
|---|---|
| Origin | Shanghai, China |
| Model | SYP2008-II |
| Evaporation Bath | 5-position metal bath |
| Temperature Control Range | 160–165 °C (bath), 150–160 °C (test port) |
| Air Pressure | ≤35 kPa |
| Air Flow per Port | 36 L/min ± 3.6 L/min |
| Heating Power | 3300 W |
| Power Supply | 220 VAC ±10%, 50 Hz ±1 Hz |
| Dimensions | 420 × 420 × 400 mm |
| Standards Compliance | GB/T 8019, ISO 6246, ASTM D381 |
| Brand | Starwood |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Region of Origin | Domestic (China) |
| Model | SDW-326 |
| Pricing | Available Upon Request |
| Brand | Tannas&King |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | SBT DC-II |
| Pricing | Upon Request |
| Dimensions (W×D×H) | 32 × 51 × 74 cm |
| Weight | ~36.3 kg |
| Power Supply | 220–240 VAC, 50/60 Hz |
| Cooling Range | +90 °C to –45 °C (±0.1 °C stability) |
| Max. Cooling Rate | 60 °C/h |
| Heating Capability | Up to 90 °C |
| Sample Capacity | 2 simultaneous tests |
| Control | Single PC can manage up to 4 units |
| Safety Certifications | CE compliant |
| Transport Dimensions | ~81 × 76 × 104 cm |
| Transport Weight | ~125 kg |
| Compliant Standards | ASTM D5133, ASTM D7110, ILSAC GF-2 through GF-6 (A&B), API SL/SM/SN, GB 11121, SH/T 0732, JPI-5S-56-99 |
| Brand | Tannas & King |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | TBR |
| Pricing | Upon Request |
| Brand | Tannas & King |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | TBS2100E-F / TBS3000 |
| Price | Upon Request |
| Dimensions (Viscometer) | 18 × 30.5 × 35.5 cm |
| Dimensions (Control Unit) | 46 × 46 × 15 cm |
| Dimensions (Auto-sampler, optional) | 46 × 51 × 61 cm |
| Weight (Viscometer) | 15.5 kg |
| Weight (Control Unit) | 9 kg |
| Weight (Auto-sampler) | 25.4 kg |
| Voltage | 220–240 V AC |
| Frequency | 50/60 Hz |
| Sample Volume | 50 mL (recommended) |
| Test Duration per Sample | ~5–7 min |
| Temperature Range | 40 °C to 200 °C (±0.1 °C stability) |
| Shear Rate Range | 5×10⁴ s⁻¹ to 7×10⁶ s⁻¹ |
| Speed Steps | 12 discrete settings (800–8000 rpm) |
| Overtemperature Protection | Programmable safety limit |
| Compliance | CE-marked |
| Shipping Weight (Manual System) | 68 kg |
| Shipping Weight (Auto System) | 72.5 kg |
| Shipping Dimensions (Manual) | 61 × 81 × 89 cm |
| Shipping Dimensions (Auto) | 61 × 81 × 127 cm |
| Brand | Tannas & King |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | TEOST |
| Pricing | Upon Request |
| Brand | TUNE VOLT |
|---|---|
| Model | TW-2058AKL |
| Principle | Light Obscuration (Optical Blockage) |
| Particle Size Range | 0.8 µm to 500 µm |
| Detection Channels | 8 user-configurable channels |
| Resolution | <10% |
| Repeatability | RSD <2% |
| Viscosity Limit | up to 350 mm²/s (cSt) |
| Sample Volume | 0.2–1000 mL |
| Sampling Accuracy | ±1% |
| Flow Rate | 5–80 mL/min |
| Vacuum Pressure | up to 0.08 MPa |
| Positive Pressure | up to 0.8 MPa |
| Coincidence Limit | 10,000 particles/mL |
| Power Supply | AC 220 V ±10%, 50 Hz ±10% |
| Dimensions | 400 × 340 × 660 mm |
| Weight | 23.5 kg |
| Brand | PCS Instruments |
|---|---|
| Origin | United Kingdom |
| Model | USV |
| Shear Rate Range | up to 1×10⁷ s⁻¹ |
| Temperature Range | 40 °C to 150 °C |
| Rotor/Spindle Material | Tungsten Carbide |
| Stator Material | Tungsten Carbide |
| Gap Setting | Fixed 1 mm |
| Motor Type | DC Servo Motor |
| Max Speed | 20,000 rpm |
| Acceleration Time (0–full speed) | ≤100 ms |
| Torque Measurement | Integrated via microprocessor-controlled motor and electromagnetic clutch |
| Thermal Management | Optimized gap geometry minimizes shear-induced temperature rise |
| Calibration | No routine gap calibration required due to matched thermal expansion coefficients |
| Brand | Xufeng |
|---|---|
| Origin | Shanghai, China |
| Model | AP-L1 |
| Temperature Range | Ambient to 170 °C |
| Repeatability | ±0.2 °C (light-colored petroleum), ±0.4 °C (dark-colored petroleum, ASTM Color > 8.0) |
| Temperature Sensor | Pt100 Platinum Resistance Thermometer |
| Heating Power | 30 W |
| Stirring Motor Power | 6 W |
| Display | Large Touchscreen LCD |
| Data Storage | 99 test records |
| Interface | RS-232C |
| Dimensions (Controller) | 230 × 430 × 110 mm (W×D×H) |
| Dimensions (Testing Unit) | 230 × 340 × 540 mm (W×D×H) |
| Weight | 20 kg |
| Brand | Xufeng |
|---|---|
| Origin | Shanghai, China |
| Model | AP-L2 |
| Temperature Range | 0 °C to 170 °C |
| Aniline Point Repeatability | ±0.2 °C (light-colored oils), ±0.4 °C (dark-colored oils |
| Temperature Sensor | Pt100 Platinum Resistance Thermometer |
| Heating Power | 30 W |
| Stirring Motor Power | 6 W |
| Display | Large Touchscreen LCD |
| Data Storage Capacity | 99 test records |
| Interface | RS-232C serial port |
| Dimensions (Controller) | 230 W × 430 D × 110 H mm |
| Dimensions (Testing Unit) | 230 W × 340 D × 540 H mm |
| Weight | 20 kg |
| Compliance | GB/T 262, ASTM D611, ISO 2977 |
