| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | YT1010 |
| Price | USD 215 (est.) |
| Type | Manual Operation |
| Transmittance Range | 0–100% |
| Transmittance Repeatability | ±0.1% |
| Measurement Wavelengths | 380–760 nm (visible), 940 nm (IR peak) |
| Detector | Silicon Photodiode |
| Resolution | 0.10% |
| Measurement Time | ~0.5 s |
| Accuracy | ±1.5% (colorless homogeneous transparent materials), ±1.0% (calibrated with NIST-traceable standard tiles) |
| Sample Thickness Limit | <47 mm |
| Dimensions | 203 × 120 × 29 mm |
| Weight | 515 g |
| Power Supply | 5 V DC via USB-C |
| Light Source Lifetime | ≥5 years / >3 million measurements |
| Display | 3.5-inch TFT true-color LCD |
| Operating Temp. | 0–40 °C, ≤85% RH (non-condensing), <2000 m altitude |
| Storage Temp. | −20–50 °C, ≤85% RH (non-condensing) |
| Interface | USB |
| Languages | English, Simplified Chinese |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YH1100 |
| Pricing | Upon Request |
| Type | Fully Automatic |
| Haze Range | 0–100% |
| Total Transmittance Range | 0–100% |
| Haze Repeatability (Φ20 mm aperture) | < 0.08% (after warm-up and calibration |
| Transmittance Repeatability (Φ20 mm aperture) | < 0.5% (same test condition) |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | HG60 |
| Type | Automatic |
| Haze Range | 0–30% |
| Transmittance Range | 0–100% |
| Haze Repeatability | ±0.2% |
| Transmittance Repeatability | ±0.5% |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Origin | Domestic (China) |
| Model | YH1810 |
| Type | Automatic |
| Haze Range | 1–100 |
| Transmittance Range | 0–100% |
| Haze Repeatability (Φ20 mm aperture) | < 0.05 |
| Transmittance Repeatability (Φ20 mm aperture) | < 0.05 |
| Brand | 3nh |
|---|---|
| Model | NHG60M |
| Type | Manual Gloss Meter |
| Compliance | ISO 2813, ASTM D523, ASTM D2457, GB/T 9754 |
| Display | 3.5-inch capacitive touchscreen (480 × 320 resolution) |
| Power | Rechargeable lithium-ion battery |
| Operating Modes | Standard / Calibration / Reference Mode |
| Auto-power-off | Yes |
| Software | PC-based quality management software with data export, statistical analysis, and audit trail support |
| Design | Ergonomic curved housing, micro-aperture optical path optimized for small-area and textured surfaces |
| Brand | 3nh |
|---|---|
| Model | YH1600 |
| Type | Manual Benchtop Instrument |
| Haze Range | 0–30% |
| Transmittance Range | 0–100% |
| Haze Repeatability (Φ20 mm aperture) | < 0.05 |
| Transmittance Repeatability (Φ20 mm aperture) | < 0.05 |
| Illuminant Options | D65, A, C, D50–D75, F1–F12, CWF, DLF, TL83, TL84, TPL5, U30 |
| Color Spaces | CIE LAB, XYZ, Yxy, LCh, s-RGB, βxy |
| Compliance | ASTM D1003 (non-compensated), ASTM D1044, ISO 13468 (compensated), ISO 14782, GB/T 2410, JJF 1303–2011, CIE 15.2, ASTM E308, JIS K7105/K7361/K7136 |
| Spectral Range | 400–700 nm |
| Spectral Resolution | 10 nm |
| Detector | 256-pixel dual-array CMOS image sensor |
| Integrating Sphere Diameter | Φ154 mm |
| Aperture Options | Φ20 mm / Φ15 mm / Φ8 mm / Φ4 mm |
| Measurement Time | ~1.5 s |
| Display | 7-inch capacitive TFT touchscreen |
| Data Storage | 5,000 standards + 20,000 samples |
| Interface | USB, RS-232 serial (printer), Bluetooth |
| Power | DC 24 V, 3 A |
| Weight | 7.6 kg |
| Dimensions (L×W×H) | 290 × 211 × 511 mm |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Type | Online Non-Contact Gloss Meter |
| Model | YG60L |
| Measurement Angle | 60° |
| Measuring Spot Size (60°) | 9 mm × 15 mm |
| Gloss Range (60°) | 0–1000 GU |
| Resolution | 0.1 GU |
| Non-Contact Distance | 10.0 mm ± 0.1 mm |
| Sample Parallelism Tolerance | ≤ 0.2° |
| Repeatability | ±0.5 GU (0–100 GU), ±0.5% of reading (100–1000 GU) |
| Measurement Time | 0.2 s (fast mode) or 1 s (standard mode) |
| Display | 2.3-inch monochrome LCD |
| Data Storage Capacity | 35,000 records (15,000 in Basic/Continuous mode |
| Interface | USB 2.0, Bluetooth 5.0 |
| Power Supply | USB-powered (external adapter included) |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH, non-condensing |
| Compliance | ISO 2813, ASTM D523, GB/T 9754, JJG 696 (Working Gloss Meter Verification Regulation) |
| Software | Windows-compatible PC software with report generation, audit trail, and GLP-compliant data export |
| Brand | 3nh |
|---|---|
| Model | YT1020 |
| Product Type | Handheld Manual Instrument |
| Transmittance Range | 0–100% |
| Transmittance Repeatability | ±1.0% (certified with NIST-traceable standard reference materials), ±1.5% for colorless homogeneous transparent materials |
| Measurement Time | ~0.5 s |
| Wavelength Coverage | UV–Vis (380–760 nm), IR Peaks (940 nm, 1400 nm), Full IR Band, SHGC & TSER Spectral Modes |
| Resolution | 0.10% |
| Sample Thickness Limit | <47 mm |
| Display | 3.5″ TFT True Color LCD |
| Power | 5 V DC via USB-C |
| Light Source Lifetime | >5 years / >3 million measurements |
| Operating Temp | 0–40 °C, ≤85% RH (non-condensing), <2000 m altitude |
| Storage Temp | −20–50 °C, ≤85% RH (non-condensing) |
| Dimensions | 203 × 120 × 29 mm |
| Weight | 515 g |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Manual Benchtop Instrument |
| Model | YH1102 |
| Haze Range | 0–100% |
| Transmittance Range | 0–200% |
| Haze Repeatability (Φ20 mm aperture) | < 0.05 |
| Transmittance Repeatability | ±0.5% |
| Apertures | Φ20 mm & Φ8 mm |
| Illumination | 400–700 nm LED Array |
| Detector | PD Array Compliant with CIE V(λ) 2° Observer |
| Geometry | 0/D (Normal Incidence Illumination / Diffuse Reception) |
| Integrating Sphere Diameter | Φ154 mm |
| Measurement Time | ~1.5 s |
| Haze Resolution | 0.01% |
| Operating Temperature | 0–40 °C |
| Power Supply | DC 24 V, 3 A |
| Brand | 3nh |
|---|---|
| Model | HG60S |
| Measurement Angle | 60° |
| Gloss Range | 0–200 GU |
| Resolution | 1 GU |
| Repeatability | ±1 GU (0–100 GU), ±1% GU (100–200 GU) |
| Accuracy | Compliant with JJG 698 Class II Working Gloss Meter Standard |
| Spot Size | 9 × 15 mm |
| Measurement Time | 0.5 s |
| Display | 3.5″ TFT Color LCD (320 × 480) |
| Power | 3.7 V / 3200 mAh Li-ion Battery (≥5000 measurements per charge) |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH, non-condensing |
| Interface | USB & RS-232 |
| Language Support | English & Simplified Chinese |
| Weight | ~350 g |
| Dimensions | 160 × 75 × 90 mm (L × W × H) |
| Included Accessories | AC Adapter, USB/RS-232 Cable, User Manual, Cleaning Cloth, Calibration Standard Plate |
| Brand | 3nh |
|---|---|
| Model | HG268 |
| Measurement Angles | 20°, 60°, 85° |
| Display | 3.5-inch color TFT LCD (480 × 320 resolution) |
| Compliance | ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457 |
| Power | Rechargeable Li-ion battery with auto-power-off |
| Operating Environment | Dry, stable temperature |
| Design | Handheld, ergonomic, manual operation |
| Software Interface | PC-based quality management software (optional, USB connectivity) |
| Calibration | Built-in automatic zero and reference calibration routine |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Domestic |
| Model | YG268 |
| Price | USD 495 (FOB Guangdong) |
| Type | Manual Operation |
| Gloss Measurement Angles | 20°, 60°, 85° |
| Gloss Range (60°) | 0–1000 GU |
| Gloss Repeatability (60°) | ±0.2 GU |
| Standard Calibration Check | Automatic |
| Data Storage Capacity | 35,000 measurements |
| Auto Power-Off | Adjustable (30–120 s) |
| Compliance | ISO 2813, ASTM D523, GB/T 9754, JJG 696 |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | OEM/ODM Manufacturer |
| Product Origin | Domestic (China) |
| Model | YG47 |
| Price | USD 560 (FOB Guangdong) |
| Type | Manual Portable Gloss Meter |
| Measurement Angles | 45° and 75° |
| Spot Size | 45°: 10 × 13 mm |
| 75° | 4 × 6 mm |
| Range | 45°: 0–800 GU |
| 75° | 0–150 GU |
| Resolution | 0.1 GU (0–100 GU) |
| Repeatability | ±0.2 GU (0–100 GU) |
| Accuracy | Compliant with JJG 696–2015 “Verification Regulation for Working Gloss Meters” |
| Measurement Time | 0.5 s per angle |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH, non-condensing |
| Display | 2.3-inch monochrome LCD |
| Data Storage | 35,000 readings (Basic/Continuous: 15,000 |
| QC Mode | 10,000 |
| Statistics Mode | 10,000) |
| Power | 1 × AA alkaline or Ni-MH rechargeable battery (≥10,000 measurements per charge) |
| Auto-off | 30–120 s adjustable |
| Dimensions | 160 × 52 × 84 mm |
| Weight | ~300 g (including calibration plate and battery) |
| Interface | USB 2.0 |
| Software | GQC6 Quality Control Software (Windows-compatible, supports report generation, audit trail export, and GLP-compliant data logging) |
| Optional Accessories | Thermal mini-printer, Bluetooth 5.0 adapter |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | YG75 |
| Type | Manual Gloss Meter |
| Measurement Angle | 75° |
| Measurement Spot Size | 4 × 6 mm |
| Measurement Range | 0–150 GU |
| Resolution | 0.1 GU (0–100 GU), 1 GU (100–150 GU) |
| Repeatability | ±0.2 GU (0–100 GU), ±0.2% GU (100–150 GU) |
| Measurement Time | 0.5 s |
| Display | 2.3-inch monochrome LCD |
| Dimensions | 160 × 52 × 84 mm |
| Weight | ~300 g (including calibration tile and battery) |
| Power Supply | 1 × AA alkaline or Ni-MH rechargeable battery (≥10,000 measurements per charge) or USB bus power |
| Auto-off Delay | 30–120 s adjustable |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH, non-condensing |
| Data Storage Capacity | 35,000 readings (Basic/Continuous: 15,000 |
| QC Mode | 10,000 |
| Statistical Mode | 10,000) |
| Language Support | Simplified Chinese, English, Traditional Chinese |
| Compliance | JJG 696 (Chinese National Verification Regulation for Working Gloss Meters) |
| Software | GQC6 Quality Control Software (PC-based, supports report generation, data export, audit trail, and GLP-compliant recordkeeping) |
| Brand | 3nh |
|---|---|
| Model | NHG268 |
| Measurement Angles | 20°, 60°, 85° |
| Display | 3.5-inch TFT color LCD (480 × 320 resolution) |
| Compliance | ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457 |
| Power | Rechargeable Li-ion battery with auto-off function |
| Operating Environment | Dry, stable temperature & illumination |
| Instrument Class | Manual portable gloss meter |
| Origin | Shenzhen, China |
| Manufacturer | 3nh Co., Ltd. |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Handheld Manual Gloss Meter |
| Model | YG60M |
| Measurement Angle | 60° |
| Aperture Size | 2 mm × 4 mm |
| Measurement Range | 0–1000 GU |
| Resolution | 0.1 GU |
| Repeatability | ±0.2 GU (0–100 GU) |
| Measurement Time | 0.5 s |
| Display | 2.3-inch monochrome LCD |
| Data Storage | 35,000 readings (configurable across modes) |
| Power Supply | 1 × AA alkaline or Ni-MH rechargeable battery (≥10,000 measurements per charge) |
| Dimensions | 160 × 52 × 84 mm |
| Weight | ~300 g (including calibration plate and battery) |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH, non-condensing |
| Compliance | JJG 696 (Chinese National Verification Regulation for Working Gloss Meters) |
| Software | GQC6 Quality Control Software (PC-based, USB connectivity) |
| Optional Accessories | Mini thermal printer, Bluetooth 5.0 adapter |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | YH1200 |
| Type | Automatic |
| Haze Range | 0–100 |
| Transmittance Range | 0–100% |
| Haze Repeatability | < 0.05 (Φ20 mm aperture |
| Transmittance Repeatability | < 0.1% (Φ20 mm aperture |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | YG45 |
| Price | USD 350 (approx.) |
| Type | Manual Gloss Meter |
| Measurement Angle | 45° |
| Measurement Spot Size | 10 × 13 mm |
| Measurement Range | 0–800 GU |
| Resolution | 0.1 GU (0–100 GU), 1 GU (100–800 GU) |
| Repeatability | ±0.5 GU (0–100 GU) |
| Measurement Time | 0.5 s |
| Display | 2.3-inch monochrome LCD |
| Data Storage | 35,000 readings (15,000 basic/continuous |
| Power Supply | 1 × AA alkaline or Ni-MH rechargeable battery (≥10,000 measurements per charge) |
| Auto-off Delay | 30–120 s adjustable |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH, non-condensing |
| Compliance | JJG 696 (Chinese National Verification Regulation for Working Gloss Meters) |
| Software | GQC6 Quality Control Software (Windows-compatible, USB interface) |
| Dimensions | 160 × 52 × 84 mm |
| Weight | ~300 g (including calibration plate and battery) |
| Accessories | USB cable, calibration standard plate, user manual, GQC6 software download link |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Automatic |
| Model | YG60S |
| Haze Range | 0–30% |
| Transmittance Range | 0–100% |
| Haze Repeatability | ±0.2% |
| Transmittance Repeatability | ±0.5% |
| Compliance | ISO 2813, ASTM D523, GB/T 9754, JJG 696 |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Manual Benchtop Instrument |
| Model | YH600 |
| Haze Range | 0–100% |
| Transmittance Range | 0–100% |
| Haze Repeatability (Φ20 mm aperture) | < 0.15 |
| Transmittance Repeatability (Φ20 mm aperture) | < 0.15 |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | YH10 |
| Pricing | Upon Request |
| Type | Manual |
| Haze Range | 0–30% |
| Transmittance Range | 0–100% |
| Haze Repeatability | ±0.1 |
| Transmittance Repeatability | ±0.2 |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM/ODM) |
| Product Type | Manual Benchtop Haze & Transmittance Meter |
| Haze Range | 0–100% |
| Total Transmittance Range | 0–200% |
| Haze Repeatability (Φ20 mm aperture) | < 0.05 |
| Transmittance Repeatability | ±0.5% |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | YH1000 |
| Pricing | Upon Request |
| Type | Manual Operation |
| Haze Range | 0–100% |
| Total Transmittance Range | 0–200% |
| Haze Repeatability | <0.15% (20 mm aperture) |
| Transmittance Repeatability | <0.15% (20 mm aperture) |
| Brand | 3nh |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Region Classification | Domestic (China) |
| Model | YG60 |
| Pricing | Upon Request |
| Instrument Type | Automatic |
| Haze Range | 0–30% |
| Transmittance Range | 0–100% |
| Haze Repeatability | ±0.2% |
| Transmittance Repeatability | ±0.5% |
| Compliance | ISO 2813, ASTM D523, GB/T 9754, JJG 696 |
Show next
