KeyOrigin: Hunan, China
Manufacturer TypeAuthorized Distributor
Regional OriginDomestic (PRC)
ModelSYD
PricingAvailable Upon Request
Max Load Options30 kN, 50 kN, 100 kN, 200 kN, 300 kN
Relative Indication Error±1%
Hydraulic Pump Rated Pressure25 MPa
Flexural Roller Diameter30 mm
Max Spacing Between Lower Rollers450 mm
Center Distance Between Upper Rollers150 mm
Center Distance Between Lower Rollers450 mm
Support Plate Length155 mm
Max Clearance Between Compression Platens230 mm
Piston Diameter × Stroke125 mm × 80 mm
Piston Stroke120 mm
Motor Power0.75 kW
Overall Dimensions (L×W×H)850 × 600 × 1340 mm
ComplianceGB/T 3722
