| Brand | QL |
|---|---|
| Origin | Jiangsu, China |
| Instrument Type | Benchtop |
| Excitation Mode | Spark |
| Detector | High-Performance CMOS Array (CCD-compatible architecture) |
| Focal Length | 401 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 140–680 nm |
| Number of Simultaneous Channels | 60 |
| Optical System | Paschen-Runge Mount with Vacuum-Enclosed Roland Circle |
| Light Source | Digital Plasma Spark Source with High-Energy Pre-Ignition (HEPS) |
| Discharge Frequency | 100–1000 Hz |
| Max Discharge Current | 500 A |
| Vacuum System | Multi-Stage Oil-Backstream Prevention with Differential Pressure Valve & In-Line Oil Trap |
| Analysis Gap | 4 mm |
| Electrode Material | Tungsten Jet Electrode |
| Argon Consumption | Optimized via Integrated Pneumatic Module |
| Data Interface | Gigabit Ethernet (TCP/IP) |
| Dimensions (W×D×H) | 780 × 565 × 360 mm |
| Weight | 78 kg |
| Typical Analysis Time | ~20 s per sample |
| Brand | Qilin / QL |
|---|---|
| Origin | Jiangsu, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | QL-5800E |
| Price | USD 23,500 (FOB Nanjing) |
| Instrument Type | Benchtop |
| Excitation Method | Spark Discharge |
| Detector Type | High-Performance CCD Array |
| Focal Length | 401 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 140–680 nm |
| Number of Spectral Channels | 60 |
| Optical System | Paschen-Runge Mount with Vacuum-Enclosed Roland Circle |
| Light Source | Digital Plasma Spark Source with High-Energy Pre-Ignition (HEPS) |
| Discharge Frequency | 100–1000 Hz |
| Power Supply | AC 220 V, 50/60 Hz, 1000 W |
| Dimensions (W×D×H) | 780 × 565 × 360 mm |
| Weight | 78 kg |
| Typical Analysis Time | ~20 s per sample |
| Electrode Material | Tungsten Jet Electrode |
| Inter-Electrode Gap | 4 mm |
| Vacuum System | Multi-Stage Oil-Backstream Prevention with Differential Pressure Valve and In-Line Oil Trap |
| [Brand | Qilin / QL |
|---|---|
| Origin | Jiangsu, China |
| Instrument Type | Floor-standing |
| Excitation Method | Spark |
| Detector | CCD Array |
| Focal Length | 400 mm |
| Groove Density | 2400 lines/mm |
| Wavelength Range | 130–900 nm |
| Number of Channels | 60] |
| Brand | Qilin / QL |
|---|---|
| Origin | Jiangsu, China |
| Manufacturer Type | Authorized Distributor |
| Regional Classification | Domestic (PRC) |
| Model | QL-5800E |
| Instrument Type | Benchtop |
| Excitation Method | Spark |
| Detector Type | CCD Array |
| Focal Length | 401 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 140–680 nm |
| Number of Detection Channels | 60 |
| Brand | Qilin / QL |
|---|---|
| Origin | Jiangsu, China |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Domestic (China) |
| Model | QL-5800E |
| Instrument Type | Benchtop |
| Excitation Method | Spark Discharge |
| Detector Type | High-Performance CMOS Array (CCD-compatible architecture) |
| Focal Length | 401 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 140–680 nm |
| Number of Detection Channels | 60 |
| Power Supply | AC 220 V, 50/60 Hz, 1000 W |
| Dimensions (W×D×H) | 780 × 565 × 360 mm |
| Weight | 78 kg |
| Typical Analysis Time | ~20 s per sample |
| Inter-electrode Gap | 4 mm |
| Electrode Material | Tungsten |
| Vacuum System | Integrated oil-free vacuum with differential pressure valve and multi-stage oil-trap protection |
| Brand | Qilin / QL |
|---|---|
| Origin | Jiangsu, China |
| Manufacturer Type | Authorized Distributor |
| Country of Manufacture | China |
| Model | QL-5800A |
| Instrument Type | Floor-standing |
| Excitation Method | Spark Discharge |
| Detector Type | Photomultiplier Tube (PMT) |
| Focal Length | 750 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 130–600 nm |
| Number of Analytical Channels | 32 |
| Brand | Qilin (QL) |
|---|---|
| Model | QL-5800E |
| Instrument Type | Benchtop OES |
| Excitation Source | Spark Discharge |
| Detector | CCD Array |
| Focal Length | 401 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 140–680 nm |
| Number of Detection Channels | 60 |
| Optical System | Paschen–Runge Mount with Vacuum-Enclosed Roland Circle |
| Base Materials Supported | Fe, Cu, Al, Ni, Co, Mg, Ti, Zn, Pb, Sn, Ag |
| Analysis Time | ~20 s per sample |
| Dimensions | 780 × 565 × 360 mm |
| Weight | 78 kg |
| Power Supply | AC 220 V, 50/60 Hz, 1000 W |
| Brand | Qilin |
|---|---|
| Model | QL-5800A |
| Instrument Type | Floor-standing |
| Excitation Method | Spark discharge |
| Detector Type | Photomultiplier Tube (PMT) |
| Focal Length | 750 mm |
| Grating Groove Density | 2400 lines/mm |
| Wavelength Range | 130–600 nm |
| Number of Channels | 32 |
| Operating Environment | Argon-purged optical chamber |
| Optical Stability | Thermostatically controlled at 38 °C ±0.2 °C |
| Dimensions (L×W×H) | 1120 × 750 × 920 mm |
| Net Weight | 266 kg |
