LabCompanion SH Series Computer-Controlled Salt Spray Test Chamber

Overview

The LabCompanion SH Series Computer-Controlled Salt Spray Test Chamber is an engineered environmental test system designed for standardized accelerated corrosion evaluation of metallic and coated materials under controlled saline atmospheric conditions. Based on the principle of continuous aerosol generation via pneumatic atomization, the chamber maintains precise temperature, humidity, and solution chemistry parameters to replicate aggressive chloride-rich environments—enabling reproducible assessment of coating integrity, galvanic protection performance, and base metal corrosion resistance. The system conforms to internationally recognized salt spray test protocols including neutral salt spray (NSS), acetic acid salt spray (AASS), and copper-accelerated acetic acid salt spray (CASS), supporting both qualitative pass/fail verification and quantitative comparative analysis across production lots and R&D iterations.

Key Features

• Microprocessor-based PID temperature and pressure control with real-time digital display and programmable setpoint retention.
• Dual-chamber thermal management: independent regulation of test chamber (35 °C ±1 °C for NSS; 50 °C ±1 °C for CASS) and saturated air chamber (47 °C ±1 °C / 63 °C ±1 °C), ensuring stable fog nucleation and uniform droplet distribution.
• Calibrated continuous spray system with adjustable nozzle pressure (0.7–1.0 kgf/cm²) and verified spray rate (1.0–2.0 mL/80 cm²/h over ≥16 h), validated per ASTM B117 Annex A1 requirements.
• Pneumatically assisted fog exhaust mechanism prevents condensate re-deposition and maintains consistent chamber humidity (>85% RH) throughout extended test cycles.
• Corrosion-resistant PVC-coated stainless steel construction with transparent acrylic viewing window and integrated safety interlocks.
• Modular design across five chamber volumes (108 L to 1440 L), accommodating samples from small electronic components to large automotive subassemblies.
• Pre-configured compliance modes for NSS, AASS, and CASS testing—including automatic pH adjustment logic for acidic solutions (pH 3.0–3.2) and neutral buffer validation (pH 6.5–7.2).

Sample Compatibility & Compliance

The SH Series accommodates a broad range of sample geometries and mounting configurations—including flat panels, fasteners, printed circuit boards, painted automotive trim, and electroplated hardware—without compromising spray uniformity or chamber airflow dynamics. All models are certified to meet the physical and procedural requirements of multiple international standards: GB/T 2423.17–1993 and GB/T 2423.18–2000 (China), ASTM B117–97 (USA), JIS H8502 (Japan), IEC 60068-2-11 (IEC), CNS 4158 and CNS 4159 (Taiwan), and GB/T 12967.3–1991 (CASS-specific). The system supports GLP-aligned documentation workflows, including time-stamped operational logs, parameter deviation alerts, and manual calibration traceability—facilitating audit readiness for ISO/IEC 17025-accredited laboratories and OEM quality assurance departments.

Software & Data Management

Equipped with embedded Windows CE-based controller firmware, the SH Series provides intuitive touchscreen navigation, multi-step test program sequencing, and configurable alarm thresholds for temperature, pressure, and solution level. Data logging occurs at user-defined intervals (1–60 min), storing up to 30 days of continuous operational history locally. Export options include CSV-formatted reports compatible with LIMS integration and statistical process control (SPC) platforms. While the base system does not include FDA 21 CFR Part 11-compliant electronic signature functionality, optional audit-trail modules are available for GMP-regulated environments requiring full data integrity and user accountability.

Applications

• Qualification of zinc, nickel, chromium, and aluminum alloy coatings per automotive OEM specifications (e.g., GMW14872, Ford CETP).
• Validation of marine-grade stainless steels and duplex alloys for offshore equipment certification.
• Comparative durability assessment of powder-coated vs. liquid-painted substrates in architectural cladding applications.
• Accelerated life testing of PCB surface finishes (ENIG, immersion silver, OSP) under high-humidity chloride exposure.
• Supplier qualification audits requiring third-party witnessed salt spray performance data aligned with ISO 9001 Clause 8.5.1.
• Root cause analysis of field corrosion failures through controlled replication of service-environment stressors.

FAQ

What standards does the SH Series fully support out-of-the-box?
The system is factory-calibrated and preconfigured for ASTM B117, ISO 9227 (NSS/AASS/CASS), GB/T 10125, and JIS H8502, with built-in parameter presets and procedural guidance for each method.
Is compressed air drying or filtration required upstream of the chamber?
Yes—lab-grade oil-free compressed air with ≤0.01 µm particulate filtration and dew point ≤−40 °C is mandatory to prevent nozzle clogging and ensure consistent droplet size distribution.
Can the chamber operate unattended for 96+ hours?
All SH models support continuous operation up to 1000 hours with automatic solution replenishment (via optional external tank interface) and self-diagnostic fault reporting.
How is spray uniformity verified during installation and periodic maintenance?
Uniformity is confirmed using the standard 14-collector array per ASTM B117 Section 7.2, with acceptance criteria requiring ≤15% coefficient of variation across all collection points.
Does LabCompanion provide IQ/OQ documentation packages?
Yes—factory-issued Installation Qualification (IQ) and Operational Qualification (OQ) protocols are available upon request, aligned with ISO/IEC 17025 and pharmaceutical GxP expectations.
