| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | EX-TE-03 / EX-TE-05 / EX-TE-10 / EX-TE-30 / EX-TE-50 / EX-TE-100 |
| Capacity | 3–100 L |
| Design Pressure (Vessel) | 0.09 MPa |
| Design Pressure (Jacket) | 0.3–0.4 MPa |
| Heating Power | 3–15 kW |
| Agitation Power | 0.09–0.5 kW |
| Temperature Control Range | Ambient to 120 °C |
| Optional Ultrasonic Frequency | 15–60 kHz |
| Compliance | Designed for GLP-compliant R&D environments |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | EX-TE |
| Pricing | Available Upon Request |
| Vessel Capacities | 3–100 L (6 Models: EX-TE-03 to EX-TE-100) |
| Design Pressure (Inner Vessel) | 0.09 MPa |
| Jacket Design Pressure | 0.3–0.4 MPa |
| Heating Power | 3–15 kW |
| Agitation Power | 0.09–0.5 kW |
| Temperature Control Range | Ambient to 120 °C |
| Optional Ultrasonic Frequency Range | 15–60 kHz (Pulsed or Continuous Mode) |
| Integrated Sensors | Real-time monitoring of extraction temperature, heating temperature, pH, vacuum level, agitation speed/type, and liquid level |
| Origin | Italy |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Import Status | Fully Imported |
| Model | SE03.0V |
| Instrument Type | Floor-Standing Centrifuge |
| Speed Range | 10,000–30,000 rpm (Rated Max: 11,000 rpm) |
| Max RCF | 11,000 × g |
| Max Capacity | 5 L (per batch, with optional 10–1000 L/h continuous operation) |
| Dimensions (W×D×H) | 670 × 455 × 880 mm |
| Power Supply | 3-phase, 380 V, 50 Hz, 1.5 kW |
| Motor Protection | IP55, Class F Insulation, Thermal Overload Protection |
| Drum Material | High-Strength Stainless Steel (AISI 431 shaft, precision-machined disc stack in AISI 304), Dynamic Balance Grade G2.5 |
| Feed/Discharge | Sanitary 304 SS inlet tubing, pressure gauge, micro-controlled discharge valves |
| Compliance | CE-marked, designed per ISO 13485 principles for pharmaceutical process validation support |
| Typical Configuration | Horizontal-axis disc stack centrifuge with integrated 25/50 L feed & clarified product tanks |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | TS-NS |
| Pricing | Upon Request |
| Volumes | 5 L, 10 L, 20 L, 30 L, 50 L, 100 L |
| Heating Power | 5–20 kW |
| Jacket Pressure | 0.3–0.4 MPa |
| Internal Tank Pressure | 0.09 MPa |
| Extraction Temperature | 100 °C |
| Concentration Temperature Range | 40–80 °C |
| Stirring Motor Power | 0.09–0.40 kW |
| Condensing Area | 0.20–0.95 m² |
| Heating Surface Area | 0.20–0.95 m² |
| Vacuum Pump Power | 0.75–2.25 kW |
| Ultimate Vacuum | −0.05 to −0.08 MPa |
| Dimensions (L×W×H, mm) | 1500×1200×550 to 2200×1550×660 |
| Construction Material | SUS304 stainless steel, interior welds polished to 300-grit finish |
| Insulation | Triple-layer thermal insulation |
| CIP System | Integrated Clean-in-Place |
| Heating Method | Electric jacketed heating |
| Optional Ultrasound Frequencies | 15, 20, 28, 30, 35, 40, 50, 60 kHz |
| Compliance | Designed in accordance with GMP principles for pharmaceutical R&D environments |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | TS-NS |
| Capacity Options | 5 L, 10 L, 20 L, 30 L, 50 L, 100 L |
| Heating Power | 5–20 kW |
| Jacket Pressure | 0.3–0.4 MPa |
| Internal Vessel Pressure | 0.09 MPa |
| Extraction Temperature | Up to 100 °C |
| Concentration Temperature Range | 40–80 °C |
| Stirring Motor Power | 0.09–0.40 kW |
| Condensing Area | 0.20–0.95 m² |
| Heating Surface Area | 0.20–0.95 m² |
| Vacuum Pump Power | 0.75–2.25 kW |
| Ultimate Vacuum | −0.05 to −0.08 MPa |
| Dimensions (L×W×H mm) | 1500×1200×550 to 2200×1550×660 |
| Construction Material | SUS304 stainless steel, internal/external welds polished to 300-grit finish |
| Insulation | Triple-layer thermal insulation |
| CIP System | Integrated Clean-in-Place |
| Heating Method | Electric jacketed heating |
| Optional Ultrasound Frequencies | 15, 20, 28, 30, 35, 40, 50, 60 kHz |
| Compliance | Designed per GMP principles for pharmaceutical R&D environments |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | TS-NS |
| Quotation | Available Upon Request |
| Capacities | 5 / 10 / 20 / 30 / 50 / 100 L |
| Heating Power | 5–20 kW |
| Jacket Pressure | 0.3–0.4 MPa |
| Internal Vessel Pressure | 0.09 MPa |
| Extraction Temperature | Up to 100 °C |
| Concentration Temperature Range | 40–80 °C |
| Stirring Motor Power | 0.09–0.40 kW |
| Condensing Area | 0.20–0.95 m² |
| Heating Surface Area | 0.20–0.95 m² |
| Vacuum Pump Power | 0.75–2.25 kW |
| Ultimate Vacuum | −0.05 to −0.08 MPa |
| Ultrasonic Frequency Options | 15–60 kHz (selectable) |
| Construction Material | SUS304 stainless steel, 300-grit electropolished welds |
| Insulation | Triple-layer thermal insulation |
| CIP System | Integrated Clean-in-Place |
| Control System | Centralized PLC-based HMI interface |
| Origin | Italy |
|---|---|
| Type | Floor-Standing Disc Stack Centrifuge |
| Model | SE03.0V |
| Max Speed | 11,000 rpm |
| Max RCF | 11,000 × g |
| Capacity | 50–1,000 L/h (batch min. 10 L) |
| Dimensions (W×D×H) | 670 × 455 × 880 mm |
| Power Supply | 3-phase / 380 V / 50 Hz / 1.5 kW |
| Motor Protection | IP55, Class F Insulation with Thermal Overload Protection |
| Drum Material | High-Strength Stainless Steel (AISI 431 for spindle, AISI 304 for housing and discs) |
| Separation Efficiency | Fat content ≤ 0.05% in skim milk |
| Separation Modes | Two-phase (liquid–solid or liquid–liquid) and three-phase (liquid–liquid–solid) |
| Compliance | Designed to meet hygienic process equipment standards for food, pharmaceutical, and biotech applications |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | EX-TE-03 / EX-TE-05 / EX-TE-10 / EX-TE-30 / EX-TE-50 / EX-TE-100 |
| Capacity | 3–100 L |
| Design Pressure (Vessel) | 0.09 MPa |
| Design Pressure (Jacket) | 0.3–0.4 MPa |
| Heating Power | 3–15 kW |
| Stirring Power | 0.09–0.5 kW |
| Temperature Control | Integrated PID with Digital Display |
| Optional Ultrasonic Frequency Range | 15–60 kHz |
| Safety Features | Low-Level Liquid Protection, Dual-Temperature Monitoring, Expandable Multi-Unit Synchronization |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | EX-TE |
| Pricing | Available Upon Request |
| Vessel Capacities | 3 L, 5 L, 10 L, 30 L, 50 L, 100 L |
| Heating Power | 3–15 kW |
| Agitation Power | 0.09–0.5 kW |
| Design Pressure (Inner Vessel) | 0.09 MPa |
| Design Pressure (Jacket) | 0.3–0.4 MPa |
| Temperature Control | Dual-point (Extraction & Jacket) |
| Safety Features | Low-level liquid protection, real-time temperature monitoring |
| Optional Ultrasound Module | Frequency range 15–60 kHz (focused transducer array, frame-type agitator integration) |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | TS-NS-05 / TS-NS-10 / TS-NS-20 / TS-NS-30 / TS-NS-50 / TS-NS-100 |
| Capacity | 5–100 L |
| Heating Power | 5–20 kW |
| Jacket Pressure | 0.3–0.4 MPa |
| Internal Vessel Pressure | 0.09 MPa |
| Extraction Temperature | up to 100 °C |
| Concentration Temperature Range | 40–80 °C |
| Stirring Motor Power | 0.09–0.40 kW |
| Condensing Area | 0.20–0.95 m² |
| Heating Surface Area | 0.20–0.95 m² |
| Vacuum Pump Power | 0.75–2.25 kW |
| Ultimate Vacuum | –0.05 to –0.08 MPa |
| Ultrasonic Frequency Options | 15–60 kHz (optional) |
| Material | SUS304 stainless steel, electropolished welds (300-grit finish) |
| Insulation | Triple-layer thermal insulation |
| CIP System | Integrated Clean-in-Place |
| Compliance | Designed to meet GMP requirements for laboratory-scale R&D and pilot production |
| Origin | Italy |
|---|---|
| Type | Floor-standing Disc Stack Centrifuge |
| Model | SE03.0V |
| Max Speed | 11,000 rpm |
| Max RCF | 11,000 × g |
| Capacity | 50–1,000 L/h (batch minimum: 10 L) |
| Dimensions (W×D×H) | 670 × 455 × 880 mm |
| Power Supply | 3-phase / 380 V / 50 Hz / 1.5 kW |
| Motor Protection | IP55, Class F Insulation with Thermal Overload Protection |
| Drum Material | High-strength stainless steel (AISI 431 for spindle, precision-machined 304 stainless steel discs) |
| Casing & Frame | AISI 304 stainless steel |
| Separation Efficiency | ≤0.05% residual fat in skim milk |
| Separation Modes | Liquid–Liquid–Solid (three-phase) and Liquid–Solid (two-phase) |
| Feed/Discharge | Sanitary-grade 304 stainless steel piping with pressure gauge and micro-controlled discharge valve |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Regional Origin | Domestic (PRC) |
| Model | EX-TE-03 / EX-TE-05 / EX-TE-10 / EX-TE-30 / EX-TE-50 / EX-TE-100 |
| Quotation | Available Upon Request |
| Vessel Capacity | 3–100 L |
| Jacket Design Pressure | 0.3–0.4 MPa |
| Internal Design Pressure | 0.09 MPa |
| Heating Power | 3–15 kW |
| Agitation Power | 0.09–0.5 kW |
| Optional Ultrasonic Frequency Range | 15–60 kHz |
