| Brand | ULVAC-PHI |
|---|---|
| Origin | Japan |
| Model | ADEPT-1010 |
| Instrument Type | Quadrupole SIMS |
| Net Weight | 1,350 kg |
| Shipping Weight | ~2,400 kg |
| Minimum Door Width | >110 cm |
| Minimum Door Height | >200 cm |
| Power Supply | 200–230 V AC, 50/60 Hz, 50 A (single-phase) |
| Grounding | Required |
| Dry Nitrogen Supply | Max. 27 kPa |
| Compressed Air | 0.55–0.70 MPa |
| Oxygen Cylinder | 1,400 PSIG, 99.999% purity |
| Static Magnetic Field | <1 G |
| AC Magnetic Field | <3 mG |
| Operating Temperature | 20°C ± 3°C |
| Relative Humidity | <50% |
| Heat Dissipation (Operational) | 3,300 W |
| Heat Dissipation (Bake-out) | 5,800 W |
