| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | MiniTest 300 |
| Weight | 5 kg |
| Minimum Detectable Leak Rate | 5 × 10⁻⁸ Pa·m³/s |
| Maximum Inlet Pressure | 200 hPa (abs.) |
| Operating Temperature | +10 °C to +35 °C |
| Storage Temperature | +10 °C to +55 °C |
| Acoustic Noise Level | < 70 dB(A) |
| Power Supply | 100–240 V, 50/60 Hz |
| Interface Options | RS-485, RJ-25, Gauge, I/O D-sub 9, Remote Control D-sub 9 |
| Wireless Remote Range | up to 100 m (RC 500 optional) |
| Sensor Technology | Quartz Window Mass Filter |
| Warm-up Time to Ready State | ≤ 30 min |
| Display | 3.5-inch LCD |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | ModuLine Gauge |
| Interface Options | PROFIBUS |
| Sensor Types | Capacitance Manometer (TPR series), Cold Cathode Ionization Gauge (IKR series) |
| Operating Temperature Range | –40 °C to +80 °C |
| Weight | 0.14–0.65 kg |
| Vacuum Range | 10⁻¹¹ mbar to 10³ mbar (depending on sensor module) |
| Sealing | Metal-sealed variants available |
| Radiation & EMI Resistance | Yes |
| Application Domain | Particle accelerator beamlines, UHV/XHV research systems, industrial vacuum process monitoring |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Product Type | Oil-Free Diaphragm Pump |
| Model | MVP 015 |
| Pumping Speed | 1.5 m³/h |
| Ultimate Vacuum | ≤ 4.5 mbar (abs) |
| Noise Level | ≤ 45 dB(A) |
| Weight | 2.7 kg |
| Motor Power | 1.5 W |
| Dimensions (L×W×H) | 180 × 120 × 160 mm |
| Voltage Options | AC 100–240 V / DC 24 V |
| Stages | 2-stage |
| Corrosion-Resistant Option | Available (MVP 015-2 DC / MVP 015-4 DC) |
| Inlet Port | G 1/8" or DN6 ISO-KF |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Pump Type | Dry Diaphragm Vacuum Pump |
| Oil-Free Operation | Yes |
| Ultimate Pressure (with gas ballast) | ≤ 4.5 mbar |
| Ultimate Pressure (without gas ballast) | ≤ 3.5 mbar |
| Pumping Speed | 0.95 m³/h |
| Noise Level | 26.5 dB(A) |
| Weight | 14.3 kg |
| Inlet Port | DN 16 & G 1/4" |
| Motor Supply | 100–115 / 208–236 V, 50/60 Hz |
| Stages | 2-stage |
| Compliance | CE, RoHS, UL Recognized (per model) |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | MVP015-2 |
| Power Supply | 24 V DC |
| Noise Level | <50 dB(A) |
| Operating Temperature Range | 5–40 °C |
| Pumping Speed (at 100 mbar) | 1.5 m³/h |
| Ultimate Vacuum (with gas ballast open) | ≤10 mbar |
| Ultimate Vacuum (with gas ballast closed) | ≤3 mbar |
| Motor Type | Electronically Commutated DC Motor (ECM) |
| Stages | Two-stage |
| Gas Ballast | Magnetic Solenoid Valve |
| Maintenance Interval | Up to 2 years under typical lab conditions |
| Weight | ~6.2 kg |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | OmniControl |
| Measurement Principle | Vacuum Pressure Monitoring and Pump Control via RS-485 and Analog Interfaces |
| Enclosure Rating | IP20 |
| Operating Temperature | 0°C to +50°C |
| Power Supply Options | 100–240 V AC ±10%, 47–63 Hz |
| Power Consumption | 300 W (OmniControl 200) / 411 W (OmniControl 300) / 522 W (OmniControl 400) |
| Output Voltages | 24 V DC (200/300) or 48 V DC (400) |
| Max Output Current | 11.4 A (200) / 15 A (300) / 8.33 A (400) |
| Display | 3.5-inch capacitive touchscreen |
| Mounting Options | Rack-mountable, desktop, or portable configurations |
| Compliance | Designed for integration with Pfeiffer Vacuum RS-485–enabled pumps (HiPace, HiScroll, HiLobe, MVP) and digital vacuum gauges |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | GSD350 O1 |
| Mass Range | 1–100 amu |
| Maximum Inlet Pressure | 1200 hPa |
| Detection Limit | < 100 ppb |
| Gas Flow Rate | 1–2 sccm (0 °C) |
| Analog Inputs | 5 × (−10 to +10 V, 14/16 bit) |
| Capillary | Stainless Steel, 1 m |
| Inlet Heating Temperature | Up to 200 °C |
| Filament | Dual Iridium with Y₂O₃ coating |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | GSD350 O3 |
| Mass Range | 1–100 amu |
| Maximum Inlet Pressure | 1200 hPa |
| Detection Limit | < 100 ppb |
| Gas Flow Rate | 1–2 sccm (at 0 °C) |
| Analog Inputs | 5 × (−10 to +10 V), 14/16 bit |
| Capillary Material | Stainless Steel |
| Capillary Length | 1 m |
| Sample Inlet Heating Temperature | Up to 200 °C |
| Filament Type | Iridium, Dual Y₂O₃-coated |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | GSD350 |
| Detection Principle | Quadrupole Mass Spectrometry (QMS) |
| Mass Range | 1–300 u (standard configuration) |
| Detection Limit | < 10⁻¹⁴ mbar (partial pressure, typical) |
| Response Time | < 1 s (for 10–90% step change, with optimized inlet) |
| Operating Pressure Range | 10⁻⁵ – 10⁻³ mbar (ion source) |
| Interface Temperature | Up to 200 °C (heated capillary inlet) |
| Data Acquisition Rate | Up to 100 spectra/s (full scan) |
| Compliance | CE, RoHS, ISO 9001 certified manufacturing |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | OmniStar® GSD 350 / ThermoStar® GSD 350 |
| Mass Range | 1–100 amu / 1–200 amu / 1–300 amu |
| Inlet Capillary | Stainless Steel (OmniStar®) or Quartz (ThermoStar®) |
| Max Capillary Temp | 350 °C |
| Sample Pressure | up to 1000 hPa (mbar) |
| Gas Flow Rate | 1–2 sccm |
| Detection Limit (C-SEM) | < 100 ppb |
| Resolution (10% valley) | Adjustable 0.5–2.5 amu |
| Dwell Time | 1 ms–16 s/amu |
| Mass Peak Separation (e.g., m/z 40/41) | < 10 ppm / < 20 ppm / < 50 ppm |
| Detector | C-SEM and Faraday |
| Analyzer | PrismaPro® Quadrupole Mass Filter |
| Dimensions (L×W×H) | 615 × 358 × 274 mm |
| Weight | 23 kg |
| Software | PV MassSpec |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Import Status | Imported |
| Model | OMNISTAR™ / THERMOSTAR™ |
| Pricing | Upon Request |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Pump Type | Oil-Lubricated Dual-Stage Rotary Vane |
| Ultimate Pressure (with gas ballast) | 1×10⁻² hPa |
| Ultimate Pressure (without gas ballast) | 5×10⁻⁴ hPa |
| Pumping Speed (50 Hz) | 9 m³/h |
| Pumping Speed (60 Hz) | 10.5 m³/h |
| Inlet Flange | DN 25 ISO-KF |
| Motor Power (50 Hz) | 0.45 kW |
| Motor Speed (50 Hz) | 1500 rpm |
| Cooling | Air-cooled |
| Protection Class | IP 43 |
| Oil Capacity | 0.95 L |
| Weight | 26 kg |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Pump Type | Oil-Lubricated Rotary Vane |
| Ultimate Vacuum | 5×10⁻⁴ hPa (2005–2021 models) / 1×10⁻³ hPa (2033/2063 models) |
| Pumping Speed | 5–66 m³/h (50 Hz / 60 Hz) |
| Inlet/Outlet Flange | DN 25 or DN 40 ISO-KF |
| Weight | 25–103.5 kg |
| Motor Options | Single-Phase or Three-Phase |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | PBR 360, IMR 265 |
| Measurement Range | 5×10⁻¹⁰ to 1000 hPa (PBR 360) |
| Operating Temperature | 5–60 °C (PBR 360), 0–50 °C (IMR 265) |
| Bakeout Temperature | 180 °C (PBR 360), 150 °C (IMR 265) |
| Accuracy | ±10–30 % (PBR 360), ±15 % (IMR 265, 1×10⁻⁵–1 hPa) |
| Repeatability | ±2–5 % (PBR 360), ±2 % (IMR 265, 1×10⁻⁵–1×10⁻¹ hPa) |
| Output Signal | 0.774–10 V |
| Interface | DN 25/40 ISO-KF, DN 16/40 CF |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | PCR 280 |
| Measurement Principle | Capacitance manometry with integrated Pirani sensor |
| Range | 5 × 10⁻⁵ to 1500 hPa |
| Vacuum Port Options | DN 16 ISO-KF, DN 16 CF-F, or custom flange |
| Operating Voltage | 15–30 V DC |
| Output Signal | 1.2–8.68 V analog |
| Bakeout Temperature | 80 °C |
| Accuracy | ±50% (5 × 10⁻⁴–1 × 10⁻³ hPa), ±15% (1 × 10⁻³–100 hPa), ±5% (100–950 hPa), ±2.5% (950–1100 hPa) |
| Ultimate Pressure | 5000 hPa (overpressure limit) |
| Weight | 120 g |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | PKR 251 |
| Measurement Principle | Pirani + Cold Cathode |
| Range | 5×10⁻⁹ to 1000 hPa |
| Vacuum Interfaces | KF 25, CF 40, KF 40 |
| Accuracy | ±30% (1×10⁻⁸ to 100 hPa) |
| Repeatability | ±5% |
| Operating Temperature | 5–55 °C |
| Bakeout Temperature | up to 150 °C |
| Power Supply | 15.0–30.0 V DC |
| Max. Power Consumption | ~2 W |
| Output Signal | 0–10.5 V analog voltage |
| Weight | ~700 g |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | PKR 361 |
| Measurement Principle | Pirani + Cold Cathode |
| Range | 5×10⁻⁹ to 1000 hPa (calibrated for air or N₂) |
| Vacuum Port Options | KF 25, CF 40, KF 40 |
| Repeatability | ±1% of reading (1×10⁻⁸ to 100 hPa) |
| Bakeout Temperature | ≤150 °C |
| Anode Material | Molybdenum |
| Flange Material | 1.4435 stainless steel |
| Compliance | CE, RoHS, EN 61326-1 |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | PKR251 |
| Measurement Principle | Integrated Pirani and Cold Cathode Gauge |
| Range | 5×10⁻⁹ to 1000 hPa (air/N₂) |
| Vacuum Port | DN25 ISO-KF, DN40 ISO-KF, DN40 CF-F |
| Max. Absolute Pressure | 10,000 hPa (inert gases, <55 °C) |
| Accuracy | ±30% (1×10⁻⁸–100 hPa) |
| Repeatability | ±5% (1×10⁻⁸–100 hPa) |
| Output Signal | 0–10.5 V analog |
| Supply Voltage | 15.0–30.0 V DC |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | QMG 250 M1 |
| Detection Principle | Quadrupole Mass Spectrometry (QMS) |
| Configuration Type | Benchtop Modular System |
| Mass Range | 1–300 u |
| Detection Limit | <1×10⁻¹⁴ mbar (typical for H₂) |
| Response Time | ≤1 s (for major species under optimized inlet conditions) |
| Repeatability | ±0.5% RSD for H₂, O₂, CO₂ at stable vacuum and temperature |
| Operating Vacuum Range | 1×10⁻⁹ – 1×10⁻³ mbar (with turbomolecular pumping) |
| Interface | Capillary Inlet (standard), optional heated transfer line |
| Compliance | CE, RoHS, ISO 9001 manufacturing environment |
| Software | PV MassSpec v3.x (supports ASTM E1946-22 data reporting templates, GLP-compliant audit trail, 21 CFR Part 11 optional module) |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Pump Type | Oil-Lubricated Rotary Vane Pump |
| Model | SmartVane 55 |
| Pumping Speed | 29–45 m³/h (at 3 hPa) |
| Ultimate Vacuum | 0.2 hPa |
| Noise Level | 54 dB(A) (at 3 hPa) |
| Motor | Integrated IPM Motor with Standby Mode |
| Power Consumption | ~330 W (standby) / 580 W (full speed) |
| Input Voltage | 100–240 V, 50/60 Hz |
| Inlet Flange | DN 40 ISO-KF |
| Outlet Flange | DN 25 ISO-KF |
| Weight | 36 kg |
| Protection Class | IP20 |
| Communication Interface | 15-pin Sub-D female (ON/OFF, Standby, RS485) |
| Oil Capacity | 1.75 L (H1 or F4 grade) |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Pump Type | Turbo Molecular Pump |
| Pumping Speed (N₂) | 53 L/s |
| Intermediate Port Speed (N₂) | 0.15 L/s |
| Ultimate Pressure (N₂) | < 4 × 10⁻⁷ hPa |
| Compression Ratio (N₂) | > 1 × 10⁸ |
| Max. Starting Pressure (N₂) | 20 hPa |
| Inlet Flange | DN 63 |
| Outlet Flange | G 1/4" |
| IP Rating | IP54 |
| Certifications | CE, UL/CSA, 2014/30/EU (EMC), 2014/35/EU (LVD) |
| Weight | 2.3 kg |
| Startup Time | ~1.8 min (to full speed) |
| Bearing System | Hybrid Ceramic Bearings |
| Max. Rotational Speed | 90,000 rpm |
| MTBF | ≥ 100,000 hours |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | ThermoStar GSD301 |
| Detection Principle | Quadrupole Mass Spectrometry (QMS) |
| Mass Range | 1–300 u (standard), upgradable to 500 u |
| Detection Limit | <10⁻¹⁴ mbar (partial pressure, typical) |
| Ion Source | Gas-tight dual-filament design |
| Inlet System | Integrated Pt-capillary inlet, max. temp. 350 °C, vacuum-rated to 5×10⁻³ mbar |
| Pumping System | Dual-stage turbomolecular pumping (HiPace 80 + backing pump) |
| Software | QuadStar™ v4.x (supports ASTM E2554, ISO 11348, GLP-compliant audit trail, 21 CFR Part 11 optional modules) |
| Interface Compatibility | Fully compatible with TA Instruments, Mettler Toledo, NETZSCH, SETARAM, PerkinElmer, LINSEIS, Seiko, Micromeritics, Quantachrome TGA/DTA/DSC/adsorption systems |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | TPG 201 |
| Measurement Principle | Pirani (thermal conductivity) |
| Pressure Range | 1000 to 5 × 10⁻⁴ hPa |
| Vacuum Interface | KF 16 |
| Operating Temperature | 5 to 40 °C |
| Accuracy | ±30 % at 10–100 hPa |
| Display | Integrated LCD |
| Power Supply | Rechargeable battery or external stabilized DC supply |
| Weight | 0.195 kg |
| Housing Material | Corrosion-resistant stainless steel |
| Heating Option | Available for low-outgassing and UHV-compatible operation |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | TPR 270, TPR 271 |
| Measurement Principle | Thermal Conductivity (Pirani) |
| Measured Medium | Gases |
| Range | 1×10⁻⁴ to 1000 hPa (TPR 270) |
| Accuracy | ±10 % to ±30 % of reading |
| Repeatability | ±2 % |
| Operating Temperature | 5 to 60 °C |
| Bakeout Temperature | Up to 80 °C (standard), up to 250 °C (with optional high-temp flange variants) |
| Output Signal | TPR 270: 1.5–8.5 V |
| TPR 271 | 2.2–8.5 V |
| Filament Material | TPR 270: Tungsten |
| TPR 271 | Platinum or Rhodium |
| Flange Options | DN 16 ISO-KF, DN 16 CF-F, 1/8" NPT, 8-VCR |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | TPR 280 |
| Measurement Principle | Pirani |
| Range | 5 × 10⁻⁴ to 1000 hPa |
| Vacuum Interface | KF 16 (DN 16 ISO-KF) |
| Output Signal | 2.2–8.5 V DC |
| Supply Voltage | 14–30 V DC |
| Filament Material | Tungsten |
| Housing Material | Stainless Steel |
| Electrical Feedthrough | Glass |
| Operating Temperature | 5–60 °C |
| Bakeout Temperature | 80 °C (250 °C optional) |
| Accuracy | ±15% of reading (10⁻³–100 hPa) |
| Repeatability | ±2% of reading (10⁻³–100 hPa) |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | TPR 280 / TPR 281 |
| Measurement Range | 1.0 × 10³ hPa to 5.0 × 10⁻⁴ hPa |
| Operating Temperature | 80 °C (standard) / 250 °C (high-temp version) |
| Accuracy | ±15 % of reading |
| Burst Pressure | 1000 kPa |
| Weight | 80 g (TPR 280, standard) / 130 g (TPR 280, high-temp) / 80 g (TPR 281, corrosion-resistant) |
| Flange Options | DN 16 ISO-KF, DN 16 CF, 1/8" NPT, 8 VCR |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | TPR280 |
| Measurement Principle | Pirani thermal conductivity gauge |
| Range | 5 × 10⁻⁴ – 1000 hPa |
| Vacuum Port Options | DN16 ISO-KF, DN16 CF-R, 1/8" NPT, 8 VCR |
| Operating Temperature | 80 °C or 250 °C (depending on version) |
| Accuracy | ±15 % of reading |
| Maximum Pressure Resistance | 1000 kPa |
| Output Signal | 0–10 V analog |
| Weight | 80 g (80 °C version, DN16 ISO-KF) / 130 g (250 °C version, DN16 ISO-KF) |
| Brand | Pfeiffer Vacuum |
|---|---|
| Origin | Germany |
| Model | QMG 250 |
| Detection Principle | Quadrupole Mass Spectrometry |
| Configuration | Online, Integrated Vacuum System |
| Mass Range | up to 300 amu |
| Repeatability | ≤ ±0.5% RSD (for masses < 300) |
| Response Time | < 1 s (typical for partial pressure monitoring) |
| System Includes | QMG 250 quadrupole mass spectrometer, HiCube 80 turbomolecular pump set, PKR 251 cold cathode vacuum gauge, and custom four-way stainless-steel chamber assembly |
