| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | QJSCY-1215 |
| Price | USD 7,700 (FOB Shanghai) |
| Temperature Range | Ambient to +60 °C (optional ambient-controlled enclosure available) |
| Rainfall Intensity | Adjustable 0.5–10 L/min/m² (calibrated per IEC 60529 Annex B) |
| Droplet Diameter | 0.1–0.4 mm (monodisperse nozzle array, certified per ISO 16750-4) |
| Wind Speed Range | 0–12 m/s (optional integrated axial fan system) |
| Test Duration | 0–99 h 99 min 99 s (programmable timer with non-volatile memory) |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | Qingji SCY-1215 |
| Price | USD 7,800 (FOB Shanghai) |
| Compliance | GB/T 4208–2017, GB/T 4942.1–1993, IEC 60529:2013 (equivalent) |
| Chamber Interior Dimensions | 800 × 800 × 800 mm (D×W×H) |
| External Dimensions | 1100 × 1300 × 1700 mm (D×W×H) |
| Oscillating Pipe Radius | 400 mm |
| Nozzle Quantity | 25 |
| Nozzle Diameter | Ø0.4 mm |
| Nozzle Spacing | 50 mm |
| Pipe Diameter | Ø16 mm |
| Water Flow Rate per Nozzle | 0.07 L/min |
| Total Flow Rate | ~1.8 L/min |
| Oscillation Angle | ±60° (120° total sweep) |
| Cycle Time per Full Oscillation | ~12 s |
| Timer Range | 00:00:00 to 99:59:59 (h:mm:ss) |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Interior Material | SUS304 2B stainless steel |
| Exterior Enclosure | Cold-rolled steel with anti-rust pretreatment and electrostatic powder coating |
| Sample Tray | Custom stainless steel tray with precision-drilled drainage holes |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | QJSCY-1215 |
| Price | ¥68,000 CNY |
| Temperature Range | Ambient to +60 °C (standard configuration) |
| Rainfall Intensity | Adjustable up to 10 L/min/m² (calibrated per IEC 60529 Annex B) |
| Raindrop Diameter | 0.1–0.4 mm (monodisperse nozzle array) |
| Wind Speed Range | 0–12 m/s (optional integrated blower module) |
| Test Duration | 0–99 h 99 min 99 s (programmable timer with non-volatile memory) |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJCK-395A |
| Temperature Range | −45 °C to +150 °C |
| Compliance | GB/T 28046.4–2011, VW 80000:2009-10 |
| Application Scope | Automotive, Aerospace, Electronics, Appliance Reliability Testing |
