| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJLCD-30 |
| Drop Height Range | 400–1800 mm |
| Max. Specimen Weight | 700 g |
| Max. Specimen Dimensions | 350 × 350 × 50 mm |
| Drop Surface Dimensions | 350 × 350 × 50 mm |
| Drop Angle Options | 0°, 45°, 90° |
| Positioning Accuracy | ±0.5 mm |
| Vacuum Suction Cups | Six Ø16 mm units |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Rated Power | 400 W |
| Compressed Air Requirement | ≥0.6 MPa, clean and dry |
| Overall Dimensions | 800 × 900 × 2400 mm |
| Net Weight | 270 kg |
| Compliance | IEC 60068-2-32 |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJBLC-73 |
| Drop Height Range | 300–2000 mm |
| Maximum Specimen Weight | 60 kg |
| Maximum Specimen Dimensions | 1000 × 800 × 800 mm |
| Drop Surface Dimensions | 1700 × 1200 × 3015 mm |
| Height Display Accuracy | ≤ ±2% of set value |
| Drop Angle Tolerance | ≤ ±5° |
| Motor Power | 0.5 HP |
| Power Supply | AC 380 V, 50 Hz, 10 A |
| Machine Weight | 435 kg |
| Compliance Standards | ISO 2248, JIS Z0202-87, GB/T 4857.5–1992 |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJBLC-73 |
| Drop Height Range | 300–2000 mm |
| Max. Specimen Weight | 435 kg |
| Max. Specimen Dimensions | 1000 × 800 × 800 mm |
| Drop Surface Dimensions | 1000 × 800 × 800 mm |
| Height Display Accuracy | ≤ ±2% of set value |
| Drop Angle Tolerance | ≤ ±5° |
| Motor Power | 0.5 HP |
| Power Supply | AC 380 V, 50 Hz, 10 A |
| Overall Dimensions (L×W×H) | ≈ 1700 × 1200 × 3015 mm |
| Machine Weight | 435 kg |
| Compliance | ISO 2248, JIS Z 0202-87, GB/T 4857.5–1992 |
| Accuracy Class | Grade 1 or higher |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | QJLCSW-86 |
| Price | USD 7,800 (FOB Shanghai) |
| Drop Height Range | 10–200 mm |
| Maximum Specimen Weight | 2 kg |
| Maximum Specimen Dimensions | 80 × 140 mm |
| Drop Surface Dimensions | W550 × H750 × D650 mm |
| Test Speed | 6–20 cycles/min |
| Control System | PLC + 7-inch HMI touchscreen |
| Power Supply | AC 220 V, 50/60 Hz |
| Pneumatic Source Requirement | ≥0.5 MPa |
| Machine Weight | ~40 kg |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJGO-1 Dual-Drum |
| Drop Heights | 500 mm and 1000 mm (dual-position simultaneous operation) |
| Maximum Specimen Weight | up to smartphone-class devices (~250 g typical) |
| Specimen Compatibility | Small electronic consumer products (e.g., mobile phones, Bluetooth earphones, remote controls, power banks, chargers, calculators, CD players, electronic dictionaries) |
| Compliance Standards | GB/T 2423.8, GB 2099–2008, IEC 60068-2-32, IEC 60884-1, EN 50075 |
| Rotation Speed | 5 rpm (fixed-speed motor-driven drum) |
| Drop Frequency | 5–15 impacts per minute |
| Counting Range | 6-digit digital counter |
| Power Supply | 220 V AC, 1500 W total |
| Net Weight | 120 kg |
| Drive System | Gearmotor with speed-reduction gearbox (standard) |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJGO-1 |
| Drop Height | 1000 mm |
| Maximum Specimen Weight | 120 kg |
| Maximum Specimen Dimensions | 500 mm × 1000 mm |
| Drop Surface Dimensions | 500 mm × 1000 mm |
| Rotational Speed | 5 rpm |
| Drop Frequency | 5–15 impacts/min |
| Power Supply | 220 V AC, 1500 W |
| Compliance | GB/T 2423.8, GB 2099–2008, IEC 60068-2-32, IEC 60884-1, EN 50075 |
| Brand | Qinji |
|---|---|
| Origin | Shanghai, China |
| Model | LCD-30 |
| Drop Height Range | 400–1800 mm (±0.5 mm positioning accuracy) |
| Max. Specimen Weight | 700 g |
| Max. Specimen Dimensions | 350 × 350 × 50 mm |
| Drop Surface Dimensions | 350 × 350 × 50 mm |
| Drop Angles | 0°, 45°, 90° |
| Suction Cup | Six Ø16 mm vacuum cups |
| Compliance | IEC 60068-2-32 |
| Drive System | Servo motor + synchronous timing belt |
| Control System | Touchscreen HMI + PLC |
| Air Supply | ≥0.6 MPa clean compressed air |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Rated Power | 400 W |
| Overall Dimensions | 800 × 900 × 2400 mm |
| Net Weight | 270 kg |
| Drop Surface Material | Granite or concrete (customizable) |
| Surface Roughness | Ra 0.59 µm (granite), Ra 1.29 µm (concrete) |
| Brand | Qinji |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | QJLCSW-86 |
| Price Range | USD 7,000–14,000 (FOB Shanghai) |
| Drop Height Range | 10–200 mm |
| Max. Specimen Weight | 2 kg per station (4 kg total dual-station capacity) |
| Max. Specimen Dimensions | 550 mm (W) × 750 mm (H) × 650 mm (D) |
| Drop Surface Dimensions | 550 mm (W) × 750 mm (H) × 650 mm (D) |
| Test Cycle Rate | 6–20 drops/min |
| Control System | PLC + 7-inch HMI touchscreen interface |
| Power Supply | AC 220 V ±10%, 50/60 Hz |
| Pneumatic Supply | ≥0.5 MPa |
| Machine Weight | ~40 kg |
| Footprint | 550 mm (W) × 750 mm (H) × 650 mm (D) |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | QJBLC-73 |
| Price | USD 4,200 (FOB Shanghai) |
| Drop Height Range | 300–2000 mm |
| Max. Specimen Weight | 60 kg |
| Max. Specimen Dimensions | 1000 × 800 × 800 mm |
| Drop Surface Dimensions | 1700 × 1200 × 3015 mm |
| Height Display Accuracy | ≤ ±2% of set value |
| Drop Angle Tolerance | ≤ ±5° |
| Drive Motor | 0.37 kW (1/2 HP), AC induction |
| Power Supply | AC 380 V, 50 Hz, 10 A |
| Machine Weight | 435 kg |
| Accuracy Class | Grade 1 or higher |
| Test Orientation | Face, Edge, and Corner Drop |
| Height Indication | LED digital display |
| Compliance Standards | ISO 2248, JIS Z 0202-1987, GB/T 4857.5–1992 |
