Xenon Arc Weathering Test Chamber
Filter
Showing 211–240 of 301 results
| Brand | Q-LAB |
|---|---|
| Origin | USA |
| Model | Xe-3 |
| Light Source | Air-Cooled Xenon Arc Lamp (3 Lamps) |
| Spectral Filtering Options | Daylight, Window Glass, Extended UV |
| Irradiance Control | 0.35–0.55 W/m² @ 340 nm (adjustable) |
| Temperature Range | 10–90 °C (operational, chamber air) |
| Humidity Range | 10–95% RH (non-condensing), programmable |
| Sample Capacity | Flat-panel or 3D specimens on sliding tray |
| Compliance | Fully engineered to meet ASTM G155, ISO 4892-2, SAE J2527, AATCC TM16, and GB/T 16422.2 |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3 |
| Light Source | Air-Cooled Xenon Arc Lamp (3-lamp configuration) |
| Spectral Range | Full-spectrum solar simulation (290–800 nm) |
| Irradiance Control | SOLAR EYE® broadband or narrowband (340 nm, 420 nm, TUV) |
| Temperature Control | Black panel temperature (42–120 °C), chamber air temperature (ambient to 80 °C) |
| Humidity Control | Relative humidity (10–95% RH, standard) |
| Optional Features | Water spray (single/dual), back-spray, refrigerated cooling unit (-10 to 80 °C operating range with chiller), Window-Q / Window-B/SL / Window-IR / Daylight / Extended UV-Q/B filters |
| Sample Tray Dimensions | 451 mm × 718 mm |
| Max. Sample Capacity | 51 specimens (51 mm × 102 mm) |
| Lamp Life | ~1500 hours |
| Calibration | AUTOCAL®-enabled, CT202 black panel thermometer & CR20 irradiance meter compatible |
| Compliance | ISO 11341, ISO 4892-2, ASTM G155, ASTM D4459, SAE J2527, AATCC TM16, ISO 105-B02, IEC 60068-2-9 |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3-H |
| Lamp Type | Air-Cooled Xenon Arc Lamp (3-lamp configuration) |
| Lamp Life | 1500 hours |
| Spectral Filtering Options | Daylight, Window Glass (Window-Q, Window-B/SL, Window-IR), Extended UV (UV-Q/B) |
| Irradiance Control | SOLAR EYE® broadband or narrowband (340 nm, 420 nm, TUV) |
| Temperature Control | Black Panel Temperature (42–120 °C), Chamber Air Temperature (ambient to ~80 °C) |
| Humidity Control | Relative Humidity (10–95% RH, standard) |
| Sample Tray Dimensions | 451 mm × 718 mm |
| Max Sample Capacity | 51 specimens (51 mm × 102 mm) |
| Calibration Support | CR20 Irradiance Calibrator, CT202 Black Panel Thermometer |
| Compliance Ready | ASTM G155, ISO 4892-2, SAE J2527, AATCC TM16, ISO 11341, GB/T 16422.2, FDA 21 CFR Part 11 (via optional software audit trail) |
| Brand | Q-LAB |
|---|---|
| Origin | USA |
| Model | Q-LAB Xe-3-H |
| Lamp Configuration | Triple independent xenon arc lamps |
| Sample Tray Dimensions | 451 mm × 718 mm (universal 3D sample support) |
| Exposure Area | 3250 cm² |
| Capacity | Up to 55 standard specimen holders |
| External Dimensions | 179.1 cm (H) × 91.4 cm (W) × 94 cm (D) |
| Irradiance Control | SOLAR EYE broadband feedback system with selectable monitoring at 340 nm, 420 nm, or TUV band |
| Humidity Control | Precision electronic relative humidity sensor |
| Temperature Monitoring | Dual-point control — chamber air temperature and black panel/black standard temperature |
| Spectral Output | Full-spectrum xenon arc radiation filtered to meet international daylight simulation requirements |
| Compliance | ASTM G151, ASTM G155, ISO 4892-2, ISO 105-B02/B04/B06, AATCC TM16/TM169, SAE J2412/J2527, IEC 60068-2-5, GB/T 8427–2019, GB/T 14576–2013, and over 50 additional global weathering standards |
| Brand | Q-LAB |
|---|---|
| Origin | USA |
| Model | Q-LAB Xe-3-HBS |
| Xenon Lamp Power | 1800 W |
| Lamp Configuration | 3 air-cooled xenon arc lamps |
| Lamp Lifetime | 1500 hours |
| Sample Tray Dimensions | 451 mm × 718 mm |
| Max Sample Capacity | 51 pieces (51 mm × 102 mm) |
| Irradiance Control | SOLAR EYE broadband or narrowband (340 nm, 420 nm, TUV) |
| Temperature Control | Black panel temperature (42–120 °C), chamber air temperature (ambient to 90 °C), optional refrigerated cooling unit |
| Humidity Control | Relative humidity (RH) range: 10–95% RH, standard feature |
| Water Spray Options | Front spray (top-mounted dual nozzles), rear spray (backside wetting), dual-fluid spray (e.g., deionized water + acid rain simulant) |
| Filter Types | Daylight, Window Glass (Window-Q, Window-B/SL, Window-IR), Extended UV-Q/B |
| Compliance Support | ASTM G155, ISO 4892-2, SAE J2527, J2412, ISO 11341, IEC 60068-2-9, GB/T 16422.2, AATCC TM16, ISO 105-B02 |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3-HBS |
| Lamp Configuration | 3 x air-cooled xenon arc lamps |
| Spectral Range | Full-spectrum solar simulation (290–800 nm) |
| Irradiance Control | SOLAR EYE broadband or narrowband (340 nm, 420 nm, TUV) |
| Black Panel Temperature Range | 42–120 °C |
| Chamber Air Temperature Range | Ambient to 85 °C |
| Relative Humidity Control | 10–95% RH |
| Water Requirements | Deionized or purified water for spray and humidity systems |
| Spray Options | Front spray (top-mounted dual nozzles), optional rear spray (dual-sided wetting), optional secondary liquid spray (e.g., acid rain simulation) |
| Sample Tray Dimensions | 451 mm × 718 mm |
| Max Sample Capacity | 51 × 51 mm × 102 mm specimens |
| Calibration | Patented AUTOCAL system |
| Compliance Support | ASTM G155, ISO 4892-2, SAE J2527, J2412, AATCC TM16, ISO 11341, GB/T 16422.2, FDA 21 CFR Part 11 (via optional software audit trail) |
| Brand | Q-LAB |
|---|---|
| Origin | USA |
| Model | Xe-3-HC |
| Xenon Lamp Power | 1800 W (3 lamps) |
| Temperature Range | Ambient to 90°C (operational, with refrigeration option) |
| Humidity Range | 20–95% RH |
| Sample Capacity | 55 specimens |
| Sample Tray Dimensions | 45 × 72 cm |
| Sample Tilt Angle | 10° from horizontal |
| Black Panel Temperature Range | 35–110°C (adjustable per sensor) |
| Black Standard Temperature Range | 36–120°C |
| Water Consumption | 0.1 L/min (spray), 44 L/day (humidification) |
| External Dimensions | 78 × 94 × 94 cm |
| Refrigeration Unit Weight | 85 kg |
| Lamp Life Warranty | 1500 hours |
| Compliance | ASTM D2565, D4459, D6695, D7356, ISO 4892-2, ISO 11341, SAE J2527, J2412, GB/T 16422.2, and others |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3-HDS |
| Lamp Type | Air-Cooled Xenon Arc Lamp (3-lamp configuration) |
| Spectral Range | Full-spectrum solar simulation (290–800 nm) |
| Irradiance Control | SOLAR EYE® broadband or narrowband (340 nm, 420 nm, or TUV 300–400 nm) |
| Black Panel Temperature Range | 42–120 °C |
| Chamber Air Temperature Range | Ambient to 90 °C (with optional refrigerated cooling unit) |
| Relative Humidity Control | 10–95% RH (standard) |
| Sample Tray Dimensions | 451 mm × 718 mm |
| Sample Capacity | Up to 51 specimens (51 mm × 102 mm) |
| Dual Spray System | Standard (deionized water + secondary solution, e.g., acid rain or detergent) |
| Calibration | AUTOCAL® automated calibration system |
| Compliance | ASTM G155, ISO 4892-2, SAE J2527, AATCC TM16, ISO 11341, IEC 60068-2-9 |
| Interface | Touchscreen controller with built-in Ethernet, self-diagnostic alerts, GLP/GMP-ready audit trail logging |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3-HS |
| Cooling Type | Air-Cooled |
| Lamp Power | 1800 W |
| Spectral Range | Full-Spectrum Solar Simulation (UV, Visible, IR) |
| Humidity Control | Standard RH Regulation (10–95% RH) |
| Water Spray Function | Dual Nozzle Top-Mounted Spray System |
| Sample Tray Dimensions | 45 × 72 cm |
| Max Sample Capacity | 55 specimens (51 × 102 mm each) |
| Black Panel Temperature Range | 35–110 °C |
| Chamber Air Temperature Range | 25–80 °C |
| Compliance | ASTM G155, ISO 4892-2, SAE J2527, AATCC TM16, ISO 11341, IEC 60068-2-9 |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3-HS |
| Light Source | High-Stability Xenon Arc Lamp |
| Spectral Range | 290–800 nm (full-spectrum solar simulation) |
| Black Standard Temperature Control | 35–110°C |
| Relative Humidity Range | 10–95% RH |
| Water Spray Function | Programmable intermittent rain simulation |
| Lamp Life | ≥1500 hours |
| Compliance | ASTM G155, ISO 4892-2, AATCC TM16, SAE J2527, and other international weathering standards |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Model | Xe-3-HSC |
| Humidity Control | Standard RH control (20–95% RH, ±2% RH accuracy) |
| Temperature Range | 31–120°C (black panel), ambient air temperature independently monitored and controlled |
| Irradiance Control | SOLAR EYE broadband feedback system at 340 nm, 420 nm, or TUV |
| Lamp Configuration | 3 × air-cooled xenon arc lamps (1500 h rated life) |
| Sample Tray Dimensions | 451 mm × 718 mm |
| Max Sample Capacity | 51 × 51 mm × 102 mm specimens |
| Optional Features | Water spray (dual-nozzle, purified water only), refrigerated cooling unit (enables sub-ambient black panel temperatures), dual-fluid spray (e.g., acid rain simulation) |
| Brand | Q-Lab |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Product Origin | Imported |
| Model | Xe-3HSE |
| Xenon Lamp Power | 1800 W × 3 |
| Irradiance Range | 0.55–1.3 W/m²/nm @ 340 nm |
| Light Exposure Cycle | 1–999 h |
| Humidity Range | 20–95% RH |
| Brand | Qingji |
|---|---|
| Origin | Shanghai, China |
| Model | QJXDW3541 |
| Lamp Power | 6 kW |
| Temperature Range | RT+10°C to 80°C ±1°C (adjustable) |
| Humidity Range | RT+10°C to 80°C ±1°C (adjustable) |
| Spectral Range | 290–800 nm |
| Irradiance | 550 W/m² (300–800 nm) |
| Sample Rack Rotation Speed | 5 rpm |
| Interior Chamber Dimensions | 500 × 500 × 600 mm |
| Rainfall Duration | 0–9999 min (adjustable) |
| Rainfall Cycle Interval | 0–240 min (adjustable) |
| Lamp Life | ~2000 h |
| Cooling Method | Air-cooled (3 kW) / Water-cooled (4.5 kW) |
| Lamp Voltage/Current | 220 V ±5%, 20 A |
| Brand | Qinji |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | QJXDW3541 |
| Lamp Power | 4.5 kW (water-cooled) |
| Temperature Range | RT+10°C to 80°C ±1°C |
| Humidity Range | Not specified (condensation-based humidity simulation only) |
| Spectral Range | 290–800 nm |
| Radiant Intensity | 550 W/m² (300–800 nm) |
| Sample Rotation Speed | 5 rpm |
| Chamber Interior Dimensions | 500 × 500 × 600 mm |
| Rainfall Duration | 0–9999 min (adjustable) |
| Rainfall Cycle Interval | 0–240 min (adjustable) |
| Lamp Lifetime | ~2000 h |
| Brand | Qinji |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Domestic (China) |
| Model | Qinji XDW3541 |
| Price | USD 9,200 (FOB Shanghai) |
| Xenon Lamp Power | 6 kW |
| Temperature Range | RT+10°C to 80°C ±1°C (customizable upper limit available) |
| Humidity Range | Not applicable (condensation-based moisture simulation only) |
| Spectral Range | 290–800 nm |
| Irradiance at 340 nm | 0.35–1.50 W/m²/nm (adjustable, calibrated per ISO 4892-2) |
| Lamp Life | ~2,000 h (typical, dependent on operating conditions and power cycling) |
| Sample Rotation Speed | 5 rpm |
| Sample Holder Radius (inner/outer) | 100 / 220 mm |
| Center-to-Sample Distance | 165 mm |
| Chamber Interior Dimensions | 500 × 500 × 600 mm (L×W×H) |
| Rainfall Duration | 0–9999 min (programmable) |
| Rainfall Interval | 0–240 min (programmable) |
| Cooling Method | Hybrid air/water-cooled lamp system (3 kW air-cooling + 4.5 kW water-cooling) |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | QJXDW3541 |
| Price | USD 13,800 (FOB Shanghai) |
| Xenon Lamp Power | 4.5 kW (water-cooled) |
| Temperature Range | RT+10°C to 80°C ±1°C |
| Humidity Range | Not applicable (condensation-based humidity simulation only) |
| Spectral Range | 290–800 nm |
| Irradiance at 340 nm | 0.35–1.50 W/m² (adjustable) |
| Sample Rotation Speed | 5 rpm |
| Chamber Interior Dimensions | 500 × 500 × 600 mm (W×D×H) |
| Sample Holder Radius (inner/outer) | 100 / 220 mm |
| Center-to-Holder Distance | 165 mm |
| Holder Height | 420 mm |
| Rainfall Duration | 0–9999 min (programmable) |
| Rainfall Cycle Interval | 0–240 min (programmable) |
| Lamp Lifetime | ~2000 h |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | QJXDW3541 |
| Price | USD 9,400 (FOB Shanghai) |
| Xenon Lamp Power | 6 kW |
| Spectral Irradiance | 550 W/m² (300–800 nm) |
| Light Exposure Cycle | 0–240 min (adjustable on/off intervals) |
| Humidity Control Range | RT+10°C to 80°C ±1°C |
| Rainfall Duration | 0–9999 min (adjustable) |
| Rainfall Interval | 0–240 min (adjustable) |
| Lamp Lifetime | ~2000 h |
| Sample Holder Rotation Speed | 5 rpm |
| Sample Holder Radii | Inner 100 mm / Outer 220 mm |
| Center-to-Center Distance | 165 mm |
| Sample Holder Height | 420 mm |
| Chamber Interior Dimensions | 500 × 500 × 600 mm (L×W×H) |
| Spectral Range | 290–800 nm |
| Temperature Uniformity | ≤2°C |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | QJXDW3541 |
| Price | USD 7,700 (FOB Shanghai) |
| Xenon Lamp Power | 6 kW |
| Spectral Irradiance | 550 W/m² (300–800 nm) |
| Light Exposure Cycle | 0–240 min (adjustable on/off intervals) |
| Humidity Control Range | RT+10°C to 80°C ±1°C (programmable) |
| Rainfall Duration | 0–9999 min (adjustable) |
| Rainfall Interval | 0–240 min (adjustable) |
| Spectral Output Range | 290–800 nm |
| Lamp Lifetime | ~2000 h |
| Sample Tray Radius (inner/outer) | 100 / 220 mm |
| Turntable Speed | 5 rpm |
| Distance from Lamp Center to Sample Plane | 165 mm |
| Sample Height Capacity | 420 mm |
| Chamber Interior Dimensions | 500 × 500 × 600 mm (W×D×H) |
| Temperature Uniformity | ≤2°C |
| Cooling Method | Air-cooled (3 kW) + Water-cooled (4.5 kW) |
| Lamp Operating Voltage | 220 V ±5% |
| Lamp Operating Current | 20 A |
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | QJXDW3541 |
| Price | USD 7,800 (FOB Shanghai) |
| Xenon Lamp Power | 6 kW |
| Spectral Irradiance | 550 W/m² (300–800 nm) |
| Light Exposure Cycle | 0–240 min (adjustable on/off intervals) |
| Humidity Control Range | RT+10°C to 80°C ±1°C (programmable) |
| Rainfall Duration | 0–9999 min (adjustable) |
| Rainfall Interval | 0–240 min (adjustable) |
| Spectral Output Range | 290–800 nm |
| Lamp Lifetime | ~2000 h |
| Sample Tray Radius (inner/outer) | 100 / 220 mm |
| Turntable Speed | 5 rpm |
| Distance from Lamp Center to Sample Plane | 165 mm |
| Sample Height Capacity | 420 mm |
| Chamber Interior Dimensions | 500 × 500 × 600 mm (W×D×H) |
| Temperature Uniformity | ≤2°C |
| Cooling Method | Air-cooled (3 kW) + Water-cooled (4.5 kW) |
| Lamp Operating Voltage | 220 V ±5% |
| Lamp Operating Current | 20 A |
| Real-time & Integrated Irradiance Monitoring | Yes |
| Brand | Yuelian |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Domestic (China) |
| Model | YL-2206QK |
| Price | Upon Request |
| Temperature Range | RT+10°C to 70°C |
| Humidity Range | ≥95% RH |
| Temp. Uniformity | ≤±2°C |
| Temp. Stability | ≤±0.5°C |
| Humidity Uniformity & Stability | ≤±2% RH |
| Black Panel Temperature | 40°C–65°C |
| Lamp Spacing | 35 mm |
| Sample-to-Lamp Distance | 50 mm |
| Lamp Power | 40 W per tube |
| UV Spectrum | 290–400 nm (UVA-340 or UVB-313 selectable) |
| Condensation Cycle Duration | 0–99 h |
| UV Exposure Duration | 0–99 h |
| Specimen Size | 150 × 75 mm |
| Capacity | ~40 specimens |
| Total Test Duration Range | 0–9999 h |
| Irradiance | ≤50 W/m² |
| Chamber Dimensions (W×D×H) | 1170 × 450 × 500 mm |
| Brand | OK Instruments |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 5,300–12,800 (FOB Shanghai |
| Internal Dimensions (L×W×H, cm) | 50×50×40 |
| Temperature Range | 0–150°C (chamber), 40–85°C (black panel) |
| Humidity Range | 20–75% RH (light cycle), 20–98% RH (dark cycle) |
| Control Accuracy | ±0.5°C / ±2.0% RH |
| Uniformity | ±2.0°C / ±3.0% RH |
| Irradiance | 550 W/m² ±10% (300–800 nm) or 1000 W/m² ±10% (300–1200 nm) |
| Xenon Lamp Power | 1.8 kW / 2.5 kW / 6 kW |
| Lamp Life | ≥1,500 h at standard irradiance setpoint |
| Spray Cycle | 1–999 min (programmable intermittent/continuous) |
| Spray Pressure | 70–127 kPa |
| Sample Mounting | Dual-layer flat mesh rack or 500 mm diameter rotating carousel (0–3 rpm) |
| Construction | Interior — SUS304 stainless steel |
| Power Supply | AC 380 V ±5%, 50 Hz ±0.5 Hz |
| Brand | SHANG ZHUN |
|---|---|
| Origin | Guangdong, China |
| Model | SZCX-100 |
| Lamp Type | Air-cooled long-arc xenon lamp (1 × 1800 W) |
| Spectral Range | 290–800 nm |
| Irradiance Options | 340 nm, 420 nm, 300–400 nm, 280–800 nm (0–1200 W/m²) |
| Black Panel Temperature Range | 30–100 °C ±3 °C |
| Chamber Temperature Range | 0–80 °C ±2 °C (dark condition) |
| Humidity Range | 20–98 %RH ±2.5 %RH (≥75 %RH) / ±3 %RH (<75 %RH) |
| Light Exposure Duration | 0–999 h (programmable) |
| Rain Cycle | 1–9999 min (adjustable on/off intervals) |
| Internal Dimensions (W×D×H) | 500 × 600 × 500 mm |
| External Dimensions (W×D×H) | ~1150 × 1150 × 1950 mm |
| Cooling Method | Forced-air mechanical refrigeration |
| Total Power | ~4 kW |
| Supply | 220 V ±10%, 50 Hz |
| Key | Cooling Method: Water-cooled |
|---|---|
| Light Source | Full-spectrum xenon arc lamp |
| Radiation Range | 300–800 nm (550 W/m² ±10%) / 300–1200 nm (1000 W/m² ±10%) |
| Black Panel Temperature Range | 40–85°C |
| Chamber Temperature Range | 0–150°C |
| Humidity Range | 20–75% RH (light cycle), 20–98% RH (dark cycle) |
| Humidity Control Accuracy | ±2.0% RH |
| Temperature Control Accuracy | ±0.5°C |
| Temperature Uniformity | ±2.0°C |
| Humidity Uniformity | ±3.0% RH |
| Spray Duration | 1–999 min (intermittent or continuous) |
| Spray Pressure | 70–127 kPa |
| Sample Mounting | Dual-layer flat mesh rack or 500 mm diameter rotating turntable (0–3 rpm) |
| Lamp Power | 1.8 kW / 2.5 kW / 6 kW |
| Lamp Lifetime | ~1500 h |
| Construction | Interior: SUS304 stainless steel |
| Exterior | SUS34 stainless steel or powder-coated steel |
| Power Supply | AC 380 V ±5%, 50 Hz ±0.5 Hz |
| Compliance Standards | GB/T 8427, GB/T 16422-2, GB/T 8430, ISO 4892-2, GB/T 14576, ASTM D529, GB/T 15102-2006, GB/T 15104-2006 |
| Brand | OEM |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 5,200 (Reference Only) |
| Internal Dimensions (D×W×H) | 500 × 760 × 500 mm |
| External Dimensions (D×W×H) | 1020 × 1090 × 1566 mm |
| Temperature Range | 0–80 °C (adjustable) |
| Humidity Range | 65–98% RH (adjustable) |
| Rainfall Duration | 0–9999 min (adjustable) |
| Rainfall Cycle | 1–240 min (interval adjustable) |
| Spectral Range | 290–800 nm |
| Xenon Lamp Total Power | 9.9 kW (rated life: 1600 h) |
| Temperature Control Accuracy | ±0.1 °C (setpoint & display) |
| Humidity Control Accuracy | ±1% RH (setpoint & display) |
| Black Panel Temperature Sensor | Dual-metal thermometric sensor |
| Heating System | Independent Ni-Cr alloy resistive heaters |
| Humidification System | External stainless-steel shallow-surface evaporative humidifier |
| Air Circulation | Low-noise, high-temp-rated centrifugal blower with multi-blade impeller |
| Construction | Exterior — cold-rolled steel with phosphating & electrostatic powder coating OR optional SUS304 brushed stainless steel |
| Standard Accessories | Radiation-resistant quartz viewport (1 pc), Xenon arc lamps (4 pcs) |
| Safety Protections | Leakage current protection, short-circuit interruption, overtemperature cutoff, low-water-level detection, motor thermal overload protection, overcurrent trip, controller power-loss memory |
| Power Supply | AC 380 V ±10%, 50 ±0.5 Hz, 3-phase 5-wire |
| Operating Environment | Ambient 5–30 °C, ≤85% RH |
| Key | Chamber Internal Dimensions: 400 × 1250 × 700 mm (D×W×H) |
|---|---|
| External Dimensions | 450 × 1350 × 1700 mm (D×W×H) |
| Temperature Range | RT+10°C to 70°C |
| Humidity Range | 65–95% RH |
| Sample-to-Lamp Distance | 240 mm |
| Spectral Range | 295–330 nm |
| Irradiance | 1000 µW/cm² @ 340 nm |
| Illumination & Condensation Cycle | Programmable |
| Lamp Configuration | 8 × 1200 mm, 40 W xenon arc lamps |
| Interior Material | SUS304 stainless steel |
| Control System | Fuji digital temperature controller (Japan) + programmable timer |
| Water Consumption | ~8 L/day (deionized or distilled water recommended) |
| Condensation Method | Gravity-fed, non-pressurized dew formation |
| Brand | OEM |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 5,300 (FOB) |
| Standards Compliance | GB/T 8427, GB/T 16422-2, ISO 4892-2, ASTM D529, GB/T 14576, GB/T 15102-2006, GB/T 15104-2006 |
| Chamber Models | OK-XD-100 / OK-XD-225 / OK-XD-500 / OK-XD-1000 |
| Internal Dimensions (W×D×H, cm) | 50×50×40 |
| Temperature Range | 0–150°C (chamber), 40–85°C (black panel) |
| Humidity Range | 20–75% RH (light cycle), 20–98% RH (dark cycle) |
| Control Accuracy | ±0.5°C (temp), ±2.0% RH (humidity) |
| Uniformity | ±2.0°C (temp), ±3.0% RH (humidity) |
| Irradiance | 550 W/m² ±10% (300–800 nm), 1000 W/m² ±10% (300–1200 nm) |
| Xenon Lamp Power | 1.8 kW / 2.5 kW / 6 kW |
| Lamp Life | ~1,500 h |
| Spray Cycle | 1–999 min (intermittent or continuous) |
| Spray Pressure | 70–127 kPa |
| Sample Holder | Dual-layer mesh tray or 500 mm diameter rotating turntable (0–3 rpm) |
| Construction | Interior — SUS304 stainless steel |
| Power Supply | AC 380 V ±5%, 50 Hz ±0.5 Hz |
| Brand | Other Brands |
|---|---|
| Origin | Imported |
| Manufacturer Type | General Distributor |
| Price | USD 5,300 (approx.) |
| Internal Dimensions (mm) | 500×500×400 to 1000×1000×1000 |
| Temperature Range | 0–100°C (optional up to 150°C) |
| Black Panel Temperature | 40–85°C |
| Humidity Range (Light Cycle) | 20–75% RH |
| (Dark Cycle) | 20–98% RH |
| Temperature Uniformity | ±2.0°C |
| Temperature Stability | ±0.5°C |
| Humidity Uniformity | ±3.0% RH |
| Humidity Stability | ±2.0% RH |
| Irradiance | 550 W/m² ±10% (300–800 nm), 1120 W/m² ±10% (300–1200 nm or 300–3000 nm) |
| Xenon Lamp Power | 1.8 kW / 2.5 kW / 6 kW |
| Lamp Life | ~1500 h |
| Spray Duration | 1–999 min (intermittent or continuous) |
| Spray Pressure | 70–127 kPa |
| Sample Mounting | Dual-layer flat mesh rack or 500 mm diameter rotating turntable (0–3 rpm) |
| Construction | Interior – 1.2 mm SUS304 stainless steel |
| Safety Protections | Over-temperature, compressor high/low pressure, short-circuit, overload, oil-pressure, travel limit, and leakage current protection |
| Optional Accessories | Ø50 mm cable port, SUS316 sample trays, liquid nitrogen inlet |
| Brand | OEM / Custom Brand |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Irradiance Setting Range | 450 W/m² (average, adjustable) |
| Lamp Life | ~1,500–2,000 hours |
| Black Panel Temperature Control Range | 30–110°C |
| Humidity Control Range | 10–95% RH (non-condensing) |
| Cooling Medium | R404A refrigerant |
| Compressor | Tecumseh/Taikang hermetic scroll compressor |
| Noise Level | <60 dB(A) |
| Standard Compliance | ISO 4892-2, ASTM G155, SAE J2527, GB/T 16422.2 |
| Filter System | Daylight-Q/B, Extended UV-Q, Window Glass-Q filters |
| Maintenance Interval | Lamp replacement every 1,500 h |
| Key | Power Supply: 380 V AC / 50 Hz |
|---|---|
| Total Power | 9 kW |
| Xenon Lamp | 6 kW water-cooled long-arc lamp (full solar spectrum) |
| Irradiance Control Range | 350–850 nm, nominal 550 W/m² |
| Optional Monitoring Wavelengths | 340 nm or 365 nm |
| Temperature Range | (RT + 10)°C to 70°C |
| Temperature Uniformity | ±2°C |
| Sample Rotation Speed | ≥1 rpm (stepless adjustment) |
| Wet/Dry Cycle Options | 60 min irradiation / 12 min spray or 102 min / 18 min |
| Chamber Interior Dimensions | 950 × 950 × 900 mm |
| Spray Pressure | 78–127 kPa |
| UV Cut-off Filter | <255 nm blocked (0%), 400–800 nm transmittance >90% |
| Construction | Cold-rolled steel exterior with powder coating, SUS304 stainless steel interior, silicone rubber door seal |
| Control System | South Korean TEMI850 touchscreen controller |
| Cooling | Closed-loop chiller system for xenon lamp |
| Radiation Measurement | Fiber-optic coupled broadband radiometer |
| Temperature Sensing | Wireless black panel thermometer (BPT) or black standard thermometer (BST) |
| Safety | Interlocked cooling-water circuit, overtemperature/overcurrent/short-circuit protection, low-water cutoff, grounding protection |
| Brand | OEM |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Price | USD 5,200 (Reference Only) |
| Humidity Range | 20–95% RH |
| Chamber Temperature Range | 20–65°C |
| Black Panel Temperature Range | 20–100°C |
| Irradiance Control | 0–1120 W/m² (300–800 nm) |
| Total Exposure Area | 6500 cm² |
| Light Source | Water-Cooled Xenon Arc Lamp |
| Construction | Cold-Rolled Steel Exterior with Powder Coating |
| Interior | SUS304 Stainless Steel |
| Sealing | High-Temperature Silicone Gasket |
| Humidification | Precision Spray System (Specimen Wetting) |
| Air Circulation | Long-Shaft Motor-Driven Forced Convection |
| Control System | TEMI850 Touchscreen Controller (South Korea) |
| Radiation Monitoring | “F-ZA” Full-Spectrum Radiometer |
| Temperature Sensors | Black Panel Thermometer (BPT) and/or Black Standard Thermometer (BST) |
| Optical Filtering | Standard Daylight & Extended UV Filters |
| Sample Mounting | Rotating Stainless Steel Rack with Tempered Glass View Window |
