| Brand | Pri-eco |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | QCL2 500 |
| Pricing | Available Upon Request |
| Current Noise Density | ≤928 nA<sub>p-p</sub> (0.1–10 Hz) |
| RMS Noise | 36.7 nA/√Hz (1 Hz–100 kHz) |
| Output Current Range | 0–500 mA |
| Short-Term Stability | 310 ppm (after 1 h warm-up) |
| Long-Term Stability | 820 ppm (24 h after 1 h warm-up) |
| Temperature Coefficient | 6–15 ppm/°C |
| Output Voltage Compliance | ±24 VDC |
| Rise/Fall Time | 3.6 µs / 2.6 µs (RL = 36 Ω, 10%–90%) |
| Slew Rate | 160 A/ms |
| Leakage Current | ≤500 µA |
| Supply Voltage | ±18 to ±25 VDC |
| Dimensions | 78 × 108 × 40 mm |
| Weight | 0.13 kg |
