| Brand | Auniontech |
|---|---|
| Origin | Imported |
| Manufacturer Type | Authorized Distributor |
| Model | AUM-LSV1310 |
| Optical Wavelength | 1310 nm |
| Laser Safety Class | Class I (IEC 60825-1) |
| Output Power | <5 mW |
| Frequency Range | DC to 2.5 MHz |
| Displacement Noise Density | 5 pm/√Hz |
| Displacement Resolution | 1.28 nm |
| Maximum Velocity Range | 4.5 m/s |
| Velocity Resolution | <1 µm/s (at 1 kHz) |
| Displacement Repeatability (>10 Hz) | ±1 nm |
| Displacement Repeatability (<10 Hz) | ±10 nm |
| Vibration Frequency Accuracy | ±0.02% |
| Dynamic Velocity Range | 20 m/s (peak) |
| Sampling Rate | 5 MS/s (real-time digital acquisition) |
| Signal Output | Ethernet (TCP/IP, UDP), Digital TTL sync |
| Power Supply | 12–24 V DC |
| Power Consumption | <4 W |
| Operating Temperature | 0–50 °C |
| Relative Humidity | 35–85% RH (non-condensing) |
| Housing Material | Anodized Aluminum Alloy |
| Dimensions | 83.7 × 50 × 22 mm |
| Weight | 180 g |
| Brand | Julight |
|---|---|
| Model | SP-LV-1000 |
| Laser Source | Semiconductor Diode |
| Interferometry Principle | Self-Mixing Interferometry (SMI) |
| Measurement Axis | Normal-to-surface displacement/velocity |
| Operating Distance | 0.1–5 m (customizable up to 50 m) |
| Scan Angle Range | ±25° × ±25° |
| Max Scan Points | 1024 × 1024 per frame |
| Scan Speed | 0.5–50 pts/s |
| Frequency Range | DC–50 kHz (standard) |
| Signal Output | Analog voltage proportional to displacement or velocity |
| Data Acquisition Resolution | Up to 25,600 spectral lines |
| Surface Compatibility | Diffuse, rough, unpolished metals, plastics, rubber, wood, composites |
| Integrated Imaging | 96× real-time color zoom (24× optical + 4× digital), auto-focus, on-screen point selection |
| Software Features | Automated grid generation, programmable scanning, modal analysis, FRF quality assessment, time/frequency domain recording, 3D animation & visualization |
| Compliance | Designed for GLP/GMP-aligned workflows |
