Showing 541–570 of 649 results
| Brand | SpinChem |
|---|---|
| Origin | Sweden |
| Model | ProRBR |
| Construction Material | 316L Stainless Steel (customizable to Hastelloy C-276) |
| Operating Pressure | 0–10 bar |
| Temperature Range | −20 °C to +80 °C |
| Liquid Hold-up | 15 mL |
| Window Material | Borosilicate glass (>325 nm transmission) or fused quartz (>200 nm) |
| Heat Exchange | External thermal fluid jacket |
| Vessel Capacity | 1 L to several thousand liters |
| Configuration Options | Internal-mounted, External-loop, and IBC-integrated |
| Brand | SpinChem |
|---|---|
| Origin | Sweden |
| Model | S2 |
| Construction Material | Stainless Steel |
| Working Pressure | Medium-Pressure |
| Volume Capacity | 100–500 mL |
| Rotating Bed Dimensions | Ø45 mm × 30 mm (H), Volume: 28 mL, Mesh Pore Size: 104 µm, Shaft Length: 38 cm, Shaft Diameter: 10 mm, Net Weight: 85 g (317 g with shaft) |
| Rotation Direction | Clockwise |
| Speed Range | 300–1000 rpm (up to 500 rpm with shaft guide) |
| Vacuum Compatibility | 10–40 MPa (custom configuration required) |
| Brand | SpinChem |
|---|---|
| Origin | Sweden |
| Model | S3 |
| Construction Material | Stainless Steel |
| Working Pressure | Medium-Pressure |
| Volume Range | 300–2000 mL |
| Bed Dimensions | Ø70 mm × 30 mm |
| Bed Volume | 69 mL |
| Mesh Aperture | 104 µm |
| Shaft Length | 41 cm |
| Shaft Diameter | 10 mm |
| Net Weight | 148 g (397 g with shaft) |
| Rotation Direction | Clockwise |
| Speed Range | 200–800 rpm (500 rpm max with shaft guide) |
| Vacuum Capability | None |
| Brand | Milestone |
|---|---|
| Origin | Italy |
| Model | SynthWAVE |
| Type | Single-Reactor-Chamber Pre-Pressurized Microwave Synthesis System |
| Operating Temperature | Up to 280 °C (with pre-pressurization) |
| Maximum Pressure | 200 bar |
| Pre-Pressurization Range | 40–100 bar (inert gas) |
| Reaction Volume Capacity | 1–600 mL |
| Microwave Frequency | 2.45 GHz |
| Power Output | Adjustable, up to 1600 W |
| Stirring | Dual-mode — high-torque mechanical stirring + optional magnetic stirring |
| In-situ Sampling | Yes, under full temperature/pressure conditions |
| Chamber Material | Fully passivated 316L stainless steel |
| Compliance | FDA 21 CFR Part 11–compliant software architecture, GLP/GMP-ready audit trail |
| Brand | Syrris |
|---|---|
| Origin | United Kingdom |
| Model | Asia Flow Photochemical Reactor |
| Temperature Range | −40 °C to +80 °C (requires optional Asia Heater or Asia Cryo Controller) |
| Temperature Setpoint Accuracy | ±1 °C, Display Resolution: 0.1 °C |
| LED Module Capacity | Up to 8 interchangeable modules per reactor |
| Wavelength Options | 365, 385, 405, 420, 450, and 525 nm (monochromatic, high-power LEDs) |
| Reaction Volumes | 4 mL or 16 mL |
| Light Power Output | Adjustable from 10% to 100% (up to 120 W total optical output) |
| Safety | Fully interlocked housing with zero-light-leak design |
| Compatibility | Integrates natively with Syrris Asia flow chemistry platforms |
| Brand | Syrris |
|---|---|
| Origin | United Kingdom |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Asia Flow Photochemical Reactor |
| Price | Upon Request |
| Temperature Range | −40 °C to +80 °C (requires optional Asia Heater or Asia Cryo Controller) |
| Temperature Control Accuracy | Setpoint accuracy ±1 °C, Display resolution 0.1 °C |
| Reaction Modules | Up to 8 interchangeable high-power LED modules (monochromatic, multi-wavelength, or blank) |
| Wavelength Options | 365, 385, 405, 420, 450, and 525 nm |
| Reaction Volume | 4 mL or 16 mL per module |
| Light Power Output | Adjustable from 10% to 100%, up to 120 W total system output |
| Photonic Flux Monitoring | Real-time intensity and photon flux display |
| Safety | Fully interlocked housing with zero-light-leak design |
| Compatibility | Standalone operation or integrated into Syrris Asia flow chemistry platform |
| Brand | Syrris |
|---|---|
| Origin | United Kingdom |
| Model | Atlas-Sodium |
| Vessel Capacities | 100 mL, 160 mL, 300 mL, 450 mL |
| Construction Material | Stainless Steel 316 (standard), optional Hastelloy or Titanium |
| Maximum Operating Pressure | 200 bar |
| Maximum Temperature | 250 °C |
| Vacuum Capability | 10 mbar |
| Stirring | Mechanical up to 800 rpm, Magnetic up to 1200 rpm |
| Gas Selection | Up to 3 gases via front-panel or PC software control |
| Pressure Control | Automated setpoint regulation with venting logic |
| Data Logging | Real-time recording of temperature, pressure, stirring speed, gas selection, and timing events |
| Safety Certification | PED 2014/68/EU and ASME BPVC Section VIII compliant |
| Optional Extensions | Custom configurations up to 350 °C, 60 bar, 10 L capacity |
| Brand | Syrris |
|---|---|
| Origin | United Kingdom |
| Model | Potassium-02 |
| Vessel Volume | 250 mL – 2 L |
| Construction Material | Borosilicate Glass |
| Operating Pressure | Low-pressure (vacuum to slight overpressure) |
| Vacuum Level | 50 mbar |
| Temperature Range | −40 °C to 200 °C |
| Temperature Accuracy | ±0.1 °C (dependent on external circulator performance) |
| Max PCC Power | 50 W |
| Max HFC Power Density | 100 W/L |
| Thermal Sensitivity | <0.1 W/kg |
| Mechanical Stirring | 0–800 rpm |
| Magnetic Stirring | 0–1200 rpm |
| Gas Inlet/Outlet Ports | Yes (inert gas compatible) |
| Brand | Syrris |
|---|---|
| Origin | United Kingdom |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Atlas SonoLab |
| Usable Volume | Small-scale |
| Construction Material | Borosilicate Glass |
| Operating Pressure | Low-pressure (up to 1 bar gauge) |
| Capacity Range | 50 mL – 2 L |
| Vacuum Capability | Down to 50 mbar |
| Integrated Ultrasound System | Prosonix Flow Cell + Generator + Peristaltic Pump |
| Optional Sensors | Atlas Turbidity Probe, FBRM Particle Size Probe |
| Control Software | Atlas Platform (Windows-based, GLP-compliant) |
| Brand | Syrris |
|---|---|
| Origin | United Kingdom |
| Model | Atlas-sodium |
| Vessel Capacities | 100, 160, 300, 450 mL |
| Construction Material | Stainless Steel 316 (standard), optional Hastelloy or Titanium |
| Maximum Operating Pressure | 200 bar |
| Maximum Temperature | 250 °C |
| Mechanical Stirring Speed | up to 800 rpm |
| Magnetic Stirring Speed | up to 1200 rpm |
| Pressure Control | Automated via integrated pressure control module |
| Gas Selection | Up to 3 gases, switchable via front panel or PC software |
| Safety Certification | PED 2014/68/EU and ASME Section VIII compliant |
| Data Logging | Real-time recording of temperature, pressure, stirring speed, gas selection status, and event timestamps |
| Brand | Systag |
|---|---|
| Origin | Norway |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Calo2310 |
| Vessel Volume | Small-scale |
| Construction Material | Stainless Steel (316L) with Hastelloy C-276 wetted parts |
| Operating Pressure | Up to 100 bar (g) |
| Calorimetric Principle | Dual-mode — Heat-Flow and Heat-Balance Calorimetry |
| Temperature Control Range | −40 °C to +250 °C (via Huber or Julabo external circulators) |
| pH Control | Integrated auto-titrator with dynamic or setpoint control |
| Agitation | Variable-speed overhead stirrer with real-time torque measurement |
| Vapor Handling | Integrated reflux, distillation, and condensate return modules |
| Safety | Role-based user authentication (username/password), audit trail compliant with ALCOA+ principles |
| Brand | Systag |
|---|---|
| Origin | Switzerland |
| Model | Flexy CUBE |
| Reactor Volume Options | 100 / 250 / 400 mL |
| Material | Stainless Steel (316L) |
| Operating Pressure Range | Up to 10 bar(g) |
| Vacuum Capability | Down to 50 mbar(abs) |
| Temperature Control Range | –20 °C to +200 °C |
| Stirring Speed | 0–1200 rpm with Real-Time Torque Monitoring |
| Integrated Calorimetry | Heat Flow Measurement via Jacket Calorimetry |
| pH Control | Automatic Titration with Programmable Setpoints or Profile-Based Control |
| Liquid/Gas Dosing | Precision Syringe Pumps & Mass Flow Controllers |
| Distillation/Reflux | Automated Condenser & Receiver Management |
| In Situ Analytics | Turbidity, Particle Size (via focused beam reflectance), and FTIR Spectroscopy Interfaces |
| Software Compliance | 21 CFR Part 11 Ready with Audit Trail, Electronic Signatures, and User Access Levels |
| Brand | Systag |
|---|---|
| Origin | Imported (Switzerland) |
| Model | Flexy-TSC |
| Sample Volume Range | 2.5 mL to 1 L |
| Operating Pressure | Up to 200 bar (metal vessels) |
| Temperature Range | −10 °C to 400 °C |
| Temperature Resolution | 0.05 °C |
| Measurement Modes | Scanning, Isothermal, Adiabatic |
| Vessel Materials | Standard borosilicate glass (ambient pressure), optional stainless steel or Hastelloy (high-pressure) |
| Max. Simultaneous Samples | 6 |
| Compliance | ASTM E698, ISO 8232, UN GHS Test Series H.1–H.4, compatible with GLP/GMP data integrity requirements |
| Brand | TCT (Xiamen Tongchuang) |
|---|---|
| Origin | Fujian, China |
| Model | CSSE1000 |
| Reaction Pressure | Atmospheric (optional backpressure up to 0.5 MPa) |
| Reaction Temperature Range | Ambient to 1100 °C |
| Catalyst Bed Dimensions | 25 mm ID × 40 mm L |
| Gas Flow Control Range | 5 sccm – 30 SLPM |
| Temperature Control Accuracy | ±0.5 °C (heating zones & evaporator) |
| Gas Species Analyzed | CO, CO₂, CH₄, C₆H₁₄, C₃H₈, NO, NOₓ, O₂, NH₃, H₂O (optional), NO₂ (optional), SO₂ (optional) |
| Space Velocity Range | 3,000 – 50,000 h⁻¹ |
| Gas Mixing | Integrated turbulent-mixing chamber with flow conditioning baffle |
| Materials | 316L stainless steel tubing with VCR/SS-400 fittings |
| Condensate Management | Integrated inline condenser with phase separation prior to analyzer inlet |
| Liquid Dosing | Dual-plunger micropump or precision syringe pump (0.1–1000 mL/h) for controlled humidification |
| Compliance | Designed for GLP-compliant catalyst screening per ISO 21365, ASTM D7214, and SAE J1829 test protocols |
| Brand | Technobis |
|---|---|
| Origin | Netherlands |
| Model | ReactALL |
| Temperature Range | −25 to 150 °C |
| Temperature Control Accuracy | ±0.5 °C |
| Number of Reaction Units | 5 |
| Vessel Capacity | 16 mL vials |
| Sample Throughput per Unit | Up to 18 samples |
| Fluid Handling | Non-puncturing, pump-free, wide-bore fluidic path |
| Stirring Mechanism | CFD-optimized helical impeller |
| Detection | Integrated color camera + turbidity module |
| Interface | Open API for robotic integration |
| Compliance | Designed for GLP-compliant workflow execution |
| Brand | Binzhenghong |
|---|---|
| Capacity | 2000 mL |
| Material | High-Purity PTFE (Perfluoroalkoxy-Alkane Compatible) |
| Joint Type | 24/40 Standard Taper |
| Bottom Style | Flat-Bottom |
| Chemical Resistance | Full Compatibility with Hydrofluoric Acid (HF), Fuming Nitric Acid, Aqua Regia, and Molten Alkali Salts |
| Manufacturing Origin | Jiangsu, China |
| Manufacturer Type | Direct Producer |
| Brand | ThalesNano |
|---|---|
| Origin | Imported (Hungary) |
| Model | H-Cube Mini |
| Temperature Range | 25–100 °C |
| Pressure Range | 1–100 bar (1450 psi) |
| Flow Rate | 0.1–3 mL/min |
| H₂ Generation Rate | 0–30 cm³/min |
| Control Interface | Integrated Touchscreen with Real-time Parameter Adjustment |
| Catalyst Format | Cartridge-based Fixed-Bed Reactor |
| Safety Certification | CE, IEC 61010-1 Compliant |
| Brand | ThalesNano |
|---|---|
| Origin | Hungary |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | H-Cube Pro |
| Price Range | USD 65,000 – 105,000 |
| Reaction Throughput | 10 mg – 100 g |
| Temperature Range | Ambient to 150 °C |
| Pressure Range | Up to 100 bar |
| Flow Rate | Up to 3 mL/min |
| System Material | Standard 316L Stainless Steel |
| Power Supply | 110–220 V, 47–63 Hz |
| Electrolyte Requirement | Deionized water (conductivity ≤ 0.0714 µS/cm) |
| H₂ Concentration Control | Adjustable volumetric % in H₂/substrate stream |
| Safety Features | Integrated H₂ leak detection, automatic H₂ purge post-run, sealed CatCart catalyst cartridges |
| Brand | ThalesNano |
|---|---|
| Origin | Hungary |
| Model | PhotoCube |
| Temperature Range | 20–80 °C |
| Reaction Mode | Batch & Flow |
| Batch Volumes | 4 mL & 25 mL (glass) |
| Flow Loop Volume | 5–25 mL |
| Loop Material Options | FEP or PFA |
| Wavelengths | 365, 395, 457, 500, 523, 595, 623 nm + White LED |
| Max LED Power per Channel | 128 W |
| User-Configurable Parameters | Wavelength Selection, Irradiance Intensity, Stirring Speed, Temperature Setpoint & Feedback Control |
| Safety Features | Interlocked Light Shielding, UV/Visible Radiation Containment |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Model | 100L |
| Price Range | USD 14,000–21,000 (FOB) |
| Instrument Classification | Integrated Solvent Recovery System |
| Usable Volume | Large-Scale |
| Construction Material | Borosilicate Glass 3.3 |
| Operating Pressure | Medium Vacuum |
| Capacity | 100 L |
| Ultimate Vacuum | -0.098 MPa (i.e., ≤ 2 kPa absolute) |
| Temperature Range | -80 °C to +200 °C |
| Jacket Volume | ~30 L |
| Condenser Heat Transfer Area | 0.954 m² |
| Feed Tank Volume | 10 L |
| Dual Collection Flasks | 2 × 20 L |
| Stirring Motor | 370 W, Explosion-Proof (Exd II BT4), 50–500 rpm, Frequency-Controlled |
| Stirrer Type | Triple-blade PTFE-coated Propeller |
| Sealing Material | PTFE |
| Frame Material | SUS304 Stainless Steel |
| Temperature Sensor | Pt100, ±0.1 °C display resolution |
| Power Supply | 220–240 V~, 50/60 Hz |
| Ambient Operating Conditions | 5–35 °C, ≤70% RH |
| Overall Dimensions (W×D×H) | ~2200 × 900 × 2800 mm |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | CLZZ-20 |
| Instrument Category | Other Reactors |
| Usable Volume | Medium-Scale |
| Construction Material | Borosilicate Glass 3.3 (Glass Components), SUS304 Stainless Steel + 6061-F Aluminum Frame |
| Operating Pressure | Low Vacuum to Atmospheric |
| Capacity | 20 L Total System Capacity |
| Ultimate Vacuum | −0.098 MPa (≈ 20 mbar abs) |
| Filter Disc | PTFE Fritted Disc, 20–30 µm Porosity |
| Filtration Vessel Diameter | Ø300 mm |
| Collection Flask Volume | 10 L |
| Temperature Range | −80 °C to +200 °C |
| Frame Dimensions (W×D×H) | Approx. 650 × 650 × 1500 mm |
| Port Standards | 40# Flange (Liquid Feed), 24/29# Standard Taper Ground Joints (Vacuum & Vent) |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | CZLL-20 |
| Capacity | 30 L |
| Construction Material | Borosilicate Glass (Reaction Vessel), Stainless Steel (Frame) |
| Operating Pressure Range | Medium Vacuum |
| Ultimate Vacuum | 0.098 MPa (98 kPa absolute) |
| Vessel Volume Class | Medium-Scale |
| Filter Plate Options | Interchangeable Standard Sizes (e.g., Ø100 mm, Ø150 mm, Ø200 mm) |
| Filtration Visibility | Full Visual Process Monitoring Through Glass Body |
| Compliance | Designed for GLP-aligned laboratory workflows |
| Service Support | 1-Year Limited Warranty (excludes glass components), Lifetime Technical Support and Repair Services |
| Brand | The Great Wall |
|---|---|
| Model | GFY-20L |
| Capacity | 20 L |
| Material | Borosilicate Glass 3.3 (DURAN®-grade) |
| Frame | SUS304 Stainless Steel |
| Operating Pressure Range | −0.1 to 0.0 MPa (Vacuum to Atmospheric) |
| Temperature Range | −80 °C to +200 °C |
| Max ΔT Between Interior and Exterior | ≤80 °C |
| Stirring Motor Power | 90 W |
| Speed Control | Frequency Inverter |
| Speed Range | 50–500 rpm |
| Stirring Port | 50# Flange |
| Liquid Feed Port | 34/35 Standard Taper Joint |
| Vent Port | 34/35 Standard Taper Joint |
| Power Supply | 220–240 V~, 50 Hz |
| Drain Valve Mounting Height | 460 mm |
| Overall Dimensions (W×D×H) | 650 × 650 × 1720 mm |
| Vacuum Rating | −0.1 MPa (absolute) |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | GR-1-3 |
| Price Range | USD 2,800 – 7,200 (FOB) |
| Usable Volume | 1.0 L (Micro-to-Small Scale) |
| Construction Material | Borosilicate Glass 3.3 |
| Operating Pressure Range | −0.1 to 0.0 MPa (Vacuum to Atmospheric) |
| Jacket Capacity | ~0.3 L |
| Condenser Heat Transfer Area | ~0.025 m² |
| Constant-Pressure Funnel Capacity | 200 mL |
| Vacuum Level | ≤ −0.098 MPa (≤ 2 kPa absolute) |
| Temperature Range | −80 °C to +200 °C |
| Stirring Speed | 50–500 rpm (Infinitely Variable) |
| Stirring Torque | 70 N·cm |
| Stirring Power | 70 W |
| Temperature Sensor | Pt100 (±0.1 °C accuracy) |
| Sealing Material | PTFE |
| Frame Material | SUS304 Stainless Steel |
| Stirrer Shaft & Blades | SUS304 with PTFE coating |
| Stirrer Type | Anchor/Paddle-type with PTFE blades |
| Electrical Supply | 110 V / 60 Hz or 220–240 V / 50–60 Hz |
| Ambient Operating Conditions | 5–35 °C, ≤70% RH |
| Overall Dimensions (W×D×H) | ~480 × 420 × 1100 mm |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Model | GR-1 / GR-2 / GR-3 |
| Instrument Classification | Glass Reactor |
| Volume Range | 1 L, 2 L, 3 L (selectable) |
| Vessel Material | Borosilicate Glass 3.3 |
| Operating Pressure Range | –0.1 MPa to 0 MPa (vacuum to atmospheric) |
| Temperature Range | –80 °C to +200 °C |
| Jacketed Design | Dual-layer with stainless steel fluid ports |
| Stirring System | PTFE-coated SUS304 shaft, PTFE impeller, proprietary sealed bearing assembly |
| Frame | SUS304 structural frame + 6061-F aluminum panel with powder coating |
| Mobility | Locking casters with load-rated brakes |
| Compliance | Designed for GLP-compliant lab environments |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Model | GR-10 |
| Instrument Classification | Jacketed Glass Reactor |
| Usable Volume | Medium-Scale (10 L) |
| Construction Material | 3.3 Borosilicate Glass |
| Operating Pressure Range | Vacuum to Atmospheric (–0.1 MPa to 0 MPa) |
| Jacket Pressure Rating | ≤ 0.03 MPa |
| Temperature Range | –80 °C to +200 °C |
| Thermal Shock Resistance | 80 °C |
| Stirring Speed Range | 50–500 rpm |
| Speed Accuracy | ±1 rpm |
| Motor Power | 90 W |
| Drive Type | Three-Phase Asynchronous Motor with Frequency Inverter Control |
| Stirrer Shaft & Blades | 06Cr19Ni10 Stainless Steel Core with PTFE Cladding |
| Sealing System | Vacuum-Compatible Mechanical Seal with PTFE Bearings |
| Condenser Surface Area | 0.234 m² |
| Standard Ground Joint Sizes | 40/38, 35/30, 29/22, 80/60 |
| Main Flask Flange Diameter | 215 mm |
| Bottom Valve Inner Diameter | φ21 mm |
| Drain Port Outlet | φ33 mm |
| Chiller Hose Connection | Rc 3/4 |
| Temperature Sensor | PT100 (±0.1 °C accuracy) |
| Frame Material | 06Cr19Ni10 Stainless Steel + Powder-Coated Aluminum Alloy |
| Mobility | Locking Casters with Brake |
| Dimensions (W×D×H) | ≈ 825 × 665 × 1780 mm |
| Net Weight | ≈ 48 kg |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Model | GR-100 |
| Instrument Classification | Jacketed Reactor |
| Usable Volume | Large-Scale |
| Construction Material | Borosilicate Glass 3.3 |
| Operating Pressure | Low Pressure (Vacuum to Atmospheric) |
| Capacity | 100 L |
| Jacket Volume | 25 L |
| Temperature Range | −80 °C to +200 °C |
| Jacket Pressure Rating | ≤ 0.03 MPa |
| Thermal Shock Resistance | 80 °C |
| Stirring Speed Range | 50–500 rpm |
| Speed Accuracy | ±1 rpm |
| Motor Power | 250 W |
| Drive Type | Three-Phase AC Motor with Frequency Converter Control |
| Sealing System | Vacuum-Compatible Mechanical Seal with PTFE Components |
| Stirrer Configuration | Triple Impeller — Four-Blade Angled Turbine + Two Sets of Four-Blade Flat Turbine |
| Stirrer Shaft Material | 06Cr19Ni10 (AISI 304) with PTFE Cladding |
| Impeller Material | PTFE-Coated 06Cr19Ni10 |
| Temperature Sensor | PT100, Digital Display, ±0.1 °C Accuracy |
| Main Flange Diameter | 285 mm |
| Top Port Outer Diameter | 338 mm |
| Bottom Drain Valve ID | φ21 mm |
| Discharge Nozzle OD | φ33 mm |
| Condenser Heat Transfer Area | 0.954 m² |
| Condenser Port Standard | 40/38 |
| Constant-Pressure Dropping Funnel Capacity | 10,000 mL (φ12.5 mm Port) |
| Receiver Flask Capacity | 20,000 mL |
| Frame Material | 06Cr19Ni10 Stainless Steel + Powder-Coated Aluminum Alloy |
| Overall Dimensions (W×D×H) | ~1160 × 780 × 2400 mm |
| Net Weight | ~119 kg |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Model | GR-10Ex |
| Capacity | 10 L |
| Vessel Material | Borosilicate Glass 3.3 |
| Operating Pressure Range | -0.1 MPa to atmospheric |
| Temperature Range | -80 °C to 200 °C |
| Jacket Pressure Limit | ≤0.03 MPa |
| Stirring Speed Range | 50–500 rpm |
| Speed Accuracy | ±1 rpm |
| Motor Power | 180 W |
| Explosion-Proof Rating | Exdb II BT4 Gb |
| Stirring Shaft & Blade Material | 06Cr19Ni10 (AISI 304) with PTFE cladding |
| Sealing Type | Vacuum Mechanical Seal |
| Flange Diameter | 215 mm |
| Bottom Valve ID | φ21 mm |
| Discharge Port ID | φ33 mm |
| Jacket Volume | 8 L |
| Thermal Shock Resistance | 80 °C |
| Condenser Heat Transfer Area | ~0.234 m² |
| Ambient Operating Conditions | 5–35 °C, ≤70% RH |
| Dimensions (W×D×H) | ~825×720×1780 mm |
| Net Weight | ~61 kg |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Model | GR-10T |
| Price Range | USD 7,000–14,000 (FOB) |
| Vessel Capacity | 10 L |
| Instrument Material | Borosilicate Glass 3.3 |
| Operating Pressure Range | −0.1 to 0 MPa (gauge) |
| Vacuum Level | −0.098 MPa (absolute) |
| Jacket Volume | ~3.0 L |
| Condenser Heat Transfer Area | 0.234 m² |
| Constant-Pressure Dropping Funnel | 1000 mL |
| Distillation Column Dimensions | Ø85 × 715 mm |
| Packing | Glass Raschig Rings |
| Number of Ports on Reactor Head | 6 |
| Temperature Range | −80 °C to +200 °C |
| Max Allowable ΔT (Jacket vs. Vessel) | ≤80 °C |
| Jacket Max Pressure | +0.03 MPa |
| Stirring Motor Power | 90 W |
| Speed Control | Frequency Inverter |
| Speed Range | 50–500 rpm |
| Temperature Sensor | Pt100 (SUS304 sheath + PTFE jacket) |
| Temp Display Accuracy | ±0.1 °C |
| Seals & Valves | PTFE |
| Bottom Discharge Valve Height | 320 mm |
| Agitator Type | Paddle-type |
| Blade Material | PTFE-coated SUS304 shaft & blades |
| Frame Material | SUS304 stainless steel |
| Mobility | Locking Casters |
| Power Supply | 220–240 V~, 50/60 Hz |
| Ambient Operating Conditions | 5–35 °C, ≤70% RH |
| Overall Dimensions (W×D×H) | ~1080 × 650 × 2380 mm |
| Brand | The Great Wall |
|---|---|
| Origin | Henan, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | GR-150 |
| Price Range | USD 2,800 – 7,000 (FOB) |
| Usable Volume | 150 L (Large-Scale Lab Reactor) |
| Construction Material | Borosilicate Glass 3.3 |
| Operating Pressure Range | −0.1 to 0.0 MPa (Vacuum to Atmospheric) |
| Jacket Volume | ~45 L |
| Condenser Heat Exchange Area | ~1.32 m² |
| Feed Bottle Capacity | 10 L |
| Receiver Flask Capacity | 20 L |
| Temperature Range | −80 °C to +200 °C |
| Max. ΔT (Inner–Outer Wall) | ≤80 °C |
| Jacket Max. Pressure | ≤+0.03 MPa |
| Vacuum System Leak Rate | ≤2 kPa/h |
| Stirring Motor Power | 370 W |
| Speed Control | Variable-Frequency Drive (VFD) |
| Speed Range | 50–300 rpm |
| Temperature Sensor | Pt100 (±0.1 °C display accuracy) |
| Stirrer Type | Anchor/Paddle with PTFE-coated blades |
| Stirrer Shaft | SUS304 stainless steel with PTFE sheath |
| Seals & Gaskets | PTFE |
| Feed Ports | Two 34# standard ground joints, one 95# flange (solid feed), two 40# ground joints (feed bottles), 50# standard spherical joint (condenser), 60# flange (stirrer), 35# flange (Pt100) |
| Insulated Stainless Steel Flexible Hoses | 3/4″ male NPT |
| Discharge Valve Height | ~370 mm |
| Footwheel Design | Lockable casters |
| Power Supply | 220–240 V~, 50/60 Hz |
| Ambient Operating Conditions | 5–35 °C, RH ≤65% |
| Overall Dimensions (W×D×H) | ~1250 × 1100 × 2700 mm |
