| Brand | Ted Pella |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | 812-300 |
| Instrument Type | Precision Manual Cutting Machine |
| Operating Speed Range | 400–3400 rpm |
| Compatible Blade Sizes | 4" and 5" diamond wafering blades |
| Worktable Dimensions | 6" × 10" (152 mm × 254 mm) |
| Construction Material | Cross-linked polyethylene (corrosion-resistant, high-impact) |
| Standard Accessories | One 4" diamond blade, blade truing block, water-soluble coolant |
| Brand | Ted Pella |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | 650 |
| Instrument Type | Precision Low-Speed Diamond Wafering Saw |
| Blade Speed | 0–250 RPM |
| Maximum Blade Diameter | 175 mm |
| Sample Max Diameter | 70 mm |
| Sample Weight Capacity | 0–2000 g |
| Sample Mounting Diameter | 12.7 mm |
| Fine Feed Range | 0–25 mm (0.01 mm increments) |
| Coolant Reservoir Volume | 1200 mL |
| Power Supply | 220 VAC, 50/60 Hz |
| Construction | Cast Aluminum Housing |
| Drive System | Belt-Driven |
| Safety | Auto-Motor Stop on Obstruction |
| Compatible Coolants | Aqueous and Oil-Based |
| Dual Cutting Modes | Precision & Rough |
| Brand | Ted Pella |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | 812-381 |
| Instrument Type | Metallographic Cutting Machine |
| Drive System | Direct-Drive Motor |
| Worktable Dimensions | 12 × 13 in (300 × 330 mm) |
| Blade Type | Diamond-Coated Steel-Core Band Blade |
| Safety Feature | Shatter-Resistant Splash Guard |
| Cutting Guidance | Adjustable Miter Gauge for Linear and Angular Cuts |
| Coolant System | Integrated Water Reservoir (Water Only Recommended) |
| Blade Mounting | Tool-Free Quick-Release Mechanism |
| Brand | Guangzhou Jingying |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | JYDTQ-5 |
| Instrument Type | Precision Cutting Machine |
| Travel of Moving Carriage | 25 mm |
| Positioning Accuracy | 0.01 mm |
| Spindle Speed Range | 10–600 rpm |
| Blade Diameter | Φ100 × 0.5 × 20 mm |
| Power Rating | 80 W |
| Input Voltage | 220 V / 50 Hz |
| Overall Dimensions | 390 × 430 × 400 mm |
| Net Weight | 19 kg |
