| Brand | Geonica |
|---|---|
| Origin | Spain |
| Model | SunTracker-3000 |
| Power Consumption | <3 W |
| Azimuth & Elevation Accuracy | 0.1° (passive), 0.02° (active with optional radiometer feedback) |
| Payload Capacity | 30 kg |
| Operating Temperature | -20 to +60 °C |
| Relative Humidity | 0–100% RH |
| Weight | 25 kg |
| Dimensions | 460 × 490 × 490 mm |
| Drive Mechanism | Precision worm-gear train |
| Torque | 35 N·m |
| Angular Velocity | 9.4°/s |
| Angular Acceleration | 136.4°/s² |
| Mounting | Tripod base with dual bubble levels |
| Housing Material | Rust-resistant aluminum alloy, 304 stainless steel worm, bronze gear |
| Communication Interface | RS-485 (external control module), RS-232/422/485 & Ethernet (METEODATA data logger) |
| Time Synchronization | Internet NTP or integrated GPS receiver |
| Positioning Update Rate | Real-time, 1 Hz (solar zenith and azimuth) |
| Brand | Geonica |
|---|---|
| Origin | Spain |
| Model | SunTracker-2000 |
| Power Consumption | <2 W |
| Tracking Accuracy | 0.1° (passive), 0.02° (active with optional radiometer feedback) |
| Payload Capacity | 10 kg |
| Azimuth & Elevation Drive Speed | 9.4°/s |
| Operating Temperature | −20 °C to +60 °C |
| Humidity Range | 0–100% RH |
| Weight | 7 kg |
| Dimensions | 300 × 370 × 290 mm |
| Mounting | Tripod with dual bubble levels |
| Housing Material | Rust-resistant aluminum alloy |
| Worm Gear Material | 304 stainless steel worm and bronze gear |
| Communication Interface | RS-485 (integrated control module), compatible with METEODATA dataloggers via RS-232/422/485 or Ethernet |
| Time Synchronization | Internet NTP or integrated GPS receiver |
| Position Resolution | Real-time solar altitude and azimuth calculated and logged at 1 Hz |
