| Brand | Narishige |
|---|---|
| Model | IM-400 |
| Origin | Japan |
| Detection Time | 10 s (manual focusing) or 15 s (autofocusing) at ~1,000,000 cells/mL |
| Cell Concentration Range | 5×10⁴–10⁷ cells/mL |
| Sample Volume | 10 µL |
| Throughput | 50,000 cells |
| Detectable Cell Diameter | 1–60 µm |
| Operating Gas Pressure (Injection/Balance) | 0–0.5 MPa |
| Supply Pressure Range | 0.4–0.7 MPa |
| Power Input | AC 100–240 V, 50/60 Hz |
| Power Consumption | 15 W |
| Control Unit Dimensions | 120 × 211 × 264 mm, 3.1 kg |
| Manipulator Unit Dimensions | 130 × 153 × 61.5 mm, 780 g |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | IM-HD1T |
| Dimensions | 24 × 55 × 54 mm (W×D×H) |
| Weight | 58 g |
| Construction | Stainless steel housing with ergonomic form factor |
| Actuation | Pneumatic (external air supply required) |
| Control mode | Manual trigger + optional external TTL/relay interface for automated integration |
| Compatible syringes | Standard 10 µL–100 µL glass or plastic microsyringes (e.g., Drummond Nanoject, Hamilton 7000 series) |
| Accessories included | HI-9 injector holder, CT-4 polyimide tubing (0.28 mm ID), CT-1-1.5 fused silica capillary tubing (1.5 m length), HIO1PKO1 silicone O-rings, hex wrench |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | CT-4 |
| Material | 304 Stainless Steel (optional PTFE-lined) |
| Outer Diameter | 2.0 mm |
| Length per Coil | 1 m (standard) |
| Working Pressure | up to 20 MPa |
| Temperature Range | −20 °C to +150 °C |
| Surface Finish | Electropolished, Ra < 0.4 µm |
| Compliance | ISO 13485, RoHS, REACH, FDA-compliant variants available |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | CT-1 |
| Outer Diameter | 2.0 mm |
| Inner Diameter | 0.9 mm |
| Material | Polytetrafluoroethylene (PTFE) |
| Length | 1 m (standard) |
| Compatible with | NARISHIGE Oil-Hydraulic Micromanipulators and Injection Holders |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | CI-3 |
| Body Material | 316L Stainless Steel or PEEK |
| Max Operating Pressure | 25 MPa |
| Temperature Range | −30 °C to +180 °C |
| Valve Type | Normally Closed / Normally Open (Selectable) |
| Flow Rate | 0.1–30 L/min |
| Actuation Torque | ≤0.2 N·m |
| Sealing | Dual O-ring + Metal Seal |
| Cycle Life | ≥100,000 cycles |
| Interface Standards | 1/8″–1/4″ NPT / BSPP / BSPT |
| Dimensions | W21 × D8 × H17 mm |
| Weight | 10 g |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | IM-3 |
| Operating Pressure Range | 50–500 kPa |
| Time Setting Range | 10 ms – 99.99 s |
| Count Setting Range | 1–99 |
| Interval Setting Range | 10 ms – 99.99 s |
| Power Supply | AC 100–240 V (±5%), 50/60 Hz |
| Dimensions (Main Unit) | 240 × 215 × 130 mm |
| Weight (Main Unit) | 4 kg |
| Compatible Syringe Diameter | Ø5–Ø10 mm |
| Syringe Plunger Travel | 50 mm |
| Fine Adjustment Step | 500 µm |
| Accessories Included | HI-7 Syringe Holder, Tubing Connectors, Silicone O-Rings, AC Power Cord, Footswitch |
| Key | Brand: NARISHIGE |
|---|---|
| Origin | Japan |
| Model | IM-H2 |
| Application | Dedicated mounting system for IM-9C pneumatic microinjector with 1 mm capillary pipettes |
| Includes | HI-7 micromanipulator mount, CT-1 PTFE tubing (1 m), Type III connector, HI01PK01 silicone rubber gasket (2.5 mm ID, pack of 10) |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | IM-11-2 |
| Actuation Type | Pneumatic |
| Control Mechanism | Coaxial coarse/fine rotary knobs |
| Syringe Stroke | 40 mm |
| Dimensions (W×D×H) | 167–214 × 55 × 78 mm |
| Weight | 680 g |
| Tubing Length | 1.2 m |
| Accessories Included | HI-9 Injector Holder, Cleaning Rod, CT-1-1.5 & CT-4 Capillary Tubing, O-rings, Silicone Grease, HI01PK01 Silicone Gasket, Hex Wrench |
| Brand | Narishige |
|---|---|
| Model | CI-2 |
| Origin | Japan |
| Material | Medical-grade PEEK or 316L stainless steel |
| Interface | Luer Lock / universal threaded (optional) |
| Sealing Pressure | 0.5 MPa (dynamic) |
| Weight | 5 g |
| Dimensions (adapter body) | W20 × D7 × H6 mm |
| Compliance | ISO 9001, CE, USP Class VI |
| Sterilization | Autoclavable at 121°C for 20 min |
| Flow Rate | 1–200 µL/s (customizable) |
| Tolerance | ≤0.01 mm |
| Seal Configuration | Triple-ring (FKM fluorocarbon + silicone) |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Imported |
| Model | IM-H1 |
| Pricing | Available Upon Request |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | CT-2 |
| Inner Diameter | 0.9 mm |
| Outer Diameter | 2.0 mm |
| Material | Medical-Grade Polyethylene (PE) |
| Length | 1 m (100 cm) per piece |
| Pack Quantity | 3 pieces per pack |
| Compatible With | NARISHIGE MO-202, IM-300, IM-400 Micromanipulators |
| Chemical Resistance | Resistant to alcohols, glycerol, mineral oils, silicone oils, and common hydraulic fluids used in microinjection systems |
| Sterilization | Autoclavable (121°C, 20 min), gamma-irradiated options available upon request |
| Brand | Narishige |
|---|---|
| Origin | Japan |
| Model | IM-HD1 |
| Dimensions | 24 × 55 × 54 mm |
| Weight | 58 g |
| Compatible Pipettes | CT-4 (inner diameter 0.4 mm), CT-1-1.5 (inner diameter 1.5 mm) |
| Actuation | Pneumatic (foot or finger-controlled via manipulator linkage) |
| Includes | HI-9 Injector Holder, Cleaning Rod, HIO1PKO1 Silicone Gasket, Hex Wrench |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | CI-1 |
| Dimensions | 20 mm (W) × 7 mm (D) × 6 mm (H) |
| Weight | 2 g |
| Material | Stainless Steel |
| Seal Type | Integrated High-Performance Elastomeric Gasket |
| Compatible Tubing | PTFE Capillary Tubing (ID 0.1–0.5 mm) |
| Application | Secure Connection Between Micropipette and PTFE Tubing in Microinjection & Electrophysiology Setups |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | IM-21 |
| Plunger Stroke | 20 mm |
| Full Knob Rotation Displacement | 500 µm |
| Volume Control per Full Knob Rotation | ~10 µL |
| Compatible Capillary Tube Length | 1 m |
| Dimensions (W×D×H) | 127–147 × 56 × 78 mm |
| Weight | 620 g |
| Accessories | IM-H3 Injection Holder, HI01PK01 Cleaning Rod & Silicone Rubber Pad, IMO4 O-Ring, Silicone Grease |
| Brand | NARISHIGE |
|---|---|
| Origin | Japan |
| Model | IMS-3 |
| Syringe Travel Range | 5–10 mm |
| Plunger Displacement per Full Knob Rotation | 500 µm |
| Dimensions (W×D×H) | 50 × 30 × 120 mm |
| Weight | 115 g |
| Injection Volume Control via Interchangeable Syringes (Bore Diameter | 5–10 mm) |
| Accuracy | ±0.5% |
