| Brand | Jiubin Instruments |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | JB-60L |
| Pricing | Upon Request |
| Brand | Jiubin Instruments |
|---|---|
| Origin | Shanghai, China |
| Model | JB-160-C |
| Chamber Volume Range | 2–30 m³ |
| Application | Standardized VOC & Formaldehyde Emission Testing per ISO 16000, ASTM D6007, GB/T 18883, GB 50325 |
| Construction | Stainless Steel Inner Wall, Double-Glass Insulated View Window, PID-Controlled Temperature & Humidity System |
| Air Exchange Rate | Adjustable 0.1–2.0 h⁻¹ (±0.02 h⁻¹) |
| Temperature Control Range | 15–40 °C (±0.5 °C) |
| Relative Humidity Control Range | 30–70 %RH (±3 %RH) |
| Airflow Uniformity | ≥90 % across test zone |
| Internal Surface Emission | <0.5 µg/m²·h (TVOC), <0.1 µg/m²·h (Formaldehyde) |
| Compliance | Designed to meet ISO 16000-9, ISO 16000-11, ASTM D5116, JIS A 1901, GB/T 31106–2014 |
| Brand | Jiubin Instruments |
|---|---|
| Model | JB-1000L |
| Chamber Volume | 1 m³ |
| Origin | Shanghai, China |
| Compliance | GB/T 18883–2022, GB 50325–2020, ISO 16000-9, ISO 16000-11, ASTM D6007, JIS A1901 |
| Temperature Control Range | 15–30 °C (±0.5 °C stability) |
| Relative Humidity Control Range | 30–70% RH (±3% RH uniformity) |
| Air Exchange Rate | 0.2–2.0 h⁻¹ (adjustable, calibrated per ISO 16000-1) |
| Internal Construction | SUS304 stainless steel with electropolished finish |
| Wall Insulation | High-density polyurethane foam (≥50 mm) |
| Fan System | Low-turbulence axial flow with laminar airflow design |
| Sampling Port | Dual 6-mm stainless steel ports (ISO-standardized, helium-leak tested) |
| Power Supply | 220 VAC ±10%, 50 Hz, 3.5 kW |
| Brand | JUDEEY |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | VOC |
| Pricing | Available Upon Request |
| Brand | Jiubin Instruments |
|---|---|
| Origin | Shanghai, China |
| Model | JB-160-B |
| Type | Walk-in Environmental Emission Test Chamber for Automotive Interior Materials and Whole Vehicles |
| Compliance Basis | ISO 12219-4, VDA 278, DIN 75201, GB/T 27630–2019, QC/T 922–2013 |
| Internal Volume | 160 m³ |
| Temperature Control Range | 15–80 °C (±0.5 °C uniformity) |
| Humidity Control Range | 10–90% RH (±3% RH accuracy) |
| Air Exchange Rate | 0.5–2.0 h⁻¹ (adjustable, traceable via mass flow meters) |
| Chamber Wall Material | 316L stainless steel with electropolished interior surface |
| Sealing Integrity | ≤0.5% volume loss per hour (per ASTM E283) |
| Power Supply | 380 VAC, 50 Hz, 3-phase |
| Brand | Jiubin Instruments |
|---|---|
| Origin | Shanghai, China |
| Model | JB-1m³L |
| Chamber Volume | 1 m³ |
| Temperature Control Range | 15–30 °C (±0.5 °C) |
| Relative Humidity Control Range | 30–70 % RH (±3 % RH) |
| Air Exchange Rate | 0.2–2.0 h⁻¹ (adjustable, ±5 % accuracy) |
| Internal Construction | Stainless Steel 316L with electropolished finish |
| Wall Insulation | High-efficiency polyurethane foam (≥50 mm thickness) |
| Airflow Uniformity | ≥90 % across test volume per ISO 16000-9 |
| Compliance | Designed to meet ISO 16000-9, ASTM D6007, JIS A 1901, GB/T 18883–2022, and EN 16516 requirements |
| Data Logging | Integrated real-time monitoring of T, RH, airflow, and chamber pressure |
| Interface | RS485 + Ethernet (Modbus TCP), optional USB export |
| Power Supply | 220 V AC ±10 %, 50 Hz, 3.5 kW |
| Key | Brand: Jiubin Instruments |
|---|---|
| Origin | Shanghai, China |
| Model | JB-160-1m³ |
| Chamber Volume | 1 m³ |
| Standard Compliance | GB/T 39897–2021 (Determination of Odor and VOC Emission from Building Materials and Automotive Interior Parts) |
| Configuration | Single-chamber, temperature/humidity-controlled, stainless steel interior, inert gas purge system, integrated sampling ports for TO-15/TO-17 canister or thermal desorption tube extraction |
| Brand | Jiubin Instruments |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China-made) |
| Model | JB-160-9C |
| Price | USD 1,180 (FOB Shanghai) |
