| Brand | Artifex |
|---|---|
| Origin | Germany |
| Model | OPM1 |
| Type | Photodiode-based optical power meter |
| Measurement Range | 1 pW to 3 mW (typ.) |
| Wavelength Range | 190–1100 nm (Si), 800–1650 nm (InGaAs options) |
| Rise Time | 100 ns |
| NEP (RMS) | 7 µW |
| Output | Linear analog voltage (0–+4.5 V) |
| Interface | TTL-compatible modular control |
| Zero Offset Compensation | Up to ±7 V auto-zero |
| Compliance | CE, RoHS, ISO/IEC 17025 traceable calibration available |
| Brand | Artifex |
|---|---|
| Origin | Germany |
| Type | Import (Distributor-Sourced) |
| Model | IS |
| Construction | Semiconductor Laser–Optimized Integrating Sphere System |
| Cooling Options | Air-Cooled or Water-Cooled (Gold-Coated Models) |
| Spectral Range | 650 nm – 20 µm (Gold) / 350 nm – 1700 nm (Polymer) |
| Power Handling | Up to 5 kW/cm² (Gold, pulsed/average) |
| Interface Options | SMA or FC (standard dual-port |
| Detector Compatibility | Si, Ge, InGaAs, VIS-enhanced InGaAs, IR-extended InGaAs photodiodes |
| Internal Diameters | 10 mm, 20 mm, 50 mm, 100 mm |
| Coating | High-reflectance polymer (polymer spheres) or electroless gold (NIR–MIR spheres) |
| Compliance | Designed for ISO/IEC 17025-aligned optical calibration workflows |
| Brand | Artifex |
|---|---|
| Origin | Germany |
| Model | OPM150 |
| Detection Principle | Thermopile-based Absolute Power Measurement |
| Wavelength Range | 650 nm – 20 µm |
| Max. Incident Power Density | 5000 W/cm² |
| Cooling | Water-Cooled Gold-Coated Integrating Sphere |
| Interface | USB 2.0 |
| Software Mode | Real-Time Streaming, Transient Capture, Statistical Trending |
| Compliance | ISO 11554 (Laser Beam Parameter Measurements), EN 60825-1 (Laser Safety), Traceable to PTB Calibration Standards |
| Brand | Artifex |
|---|---|
| Origin | Germany |
| Model | OPM150 |
| Spectral Range | 190–2200 nm |
| Power Range | 1 nW – 20 W |
| Detector Type | Silicon, SiGe, InGaAs (multi-band) |
| Interface | USB (power + control), DB9, BNC |
| Bandwidth | 10 Hz – 100 kHz |
| Sampling Rate | 1500 S/s (direct readout), 30 S/s (GUI-controlled) |
| Gain Stages | 5 (1×, 10×, 100×, 1000×, 10000× V/mA) |
| Accuracy (Meter) | ±1% |
| Accuracy (Detector) | ±6% |
| Repeatability (Detector) | ±3% |
| Linearity (Detector) | ±0.2% |
| Response Time | 100 µs |
| Host Dimensions | 60 × 81 × 36 mm (W × L × H) |
| Detector Dimensions | Φ35 × 30 mm (D × L) |
| Calibration Data | Embedded in detector connector EEPROM |
| Software | GUI (VB.NET source included), LabVIEW® demo VI, virtual COM port command set |
| Compliance | CE, RoHS |
| Accessories | OD1–OD3 neutral density filters, SMA/FC fiber adapters, aperture reducers, lens mounts, detector heads |
| Brand | Artifex |
|---|---|
| Origin | Germany |
| Model | LDD100 |
| Output Current Range | 1–400 A (configurable variants: LDD100-40 / LDD100-120 / LDD100-200) |
| Rise Time | 50 ns (at 60 A, fast mode) |
| Pulse Width | 50 ns – 3 s |
| Pulse Repetition Rate | up to 100 kHz |
| Trigger Options | Internal / External (sequential or single-shot) |
| Interface | USB 2.0 |
| Compliance | CE, RoHS |
| Cooling | Passive (L-Version) or Active (F-Version) |
| Dimensions (Control Unit) | 250 × 235 × 150 mm |
| Input Power | 88–264 VAC, 47–63 Hz, PF ≥ 0.95 |
| Accuracy | ±2%, Repeatability: ±1%, Linearity: ±1% |
| Connector Types | LEMO for control, stripline for laser head |
| Origin | Beijing |
|---|---|
| Manufacturer Type | Distributor |
| Origin Category | Domestic (China) |
| Model | GGR01 |
| Price Range | USD 72–143 |
| Component Category | Optical Element |
| Substrate Material | Float Glass |
| Surface Quality | Grade 4 |
| Dimensional Tolerance | ±0.5 mm |
| Thickness Tolerance | ±0.5 mm |
| Diffraction Efficiency | 60–80% @ Blaze Wavelength |
| Clear Aperture | ≥90% |
| Laser Damage Threshold | 350 mJ/cm² (200 ns pulsed, 10.6 µm) |
| Groove Density Options | 75, 100, 150 lines/mm (IR) |
| Blaze Wavelengths | 30 nm, 500 nm, 1000 nm, 10.6 µm |
| Blaze Angles | 2°34′ to 35°0′ |
| Dispersion | 3.30–12.3 nm/mrad |
| Brand | Solar Light |
|---|---|
| Origin | USA |
| Model | PMA2106 |
| Detection Principle | Broadband Non-Weighted UVB (280–320 nm) |
| Spectral Response | Flat, Unfiltered Silicon Photodiode with UVB-optimized optical filter |
| Angular Response | Lambertian (Cosine-corrected, ±5% up to 60° incidence) |
| Measurement Range | 0.001–200 mW/cm² (0.01–2000 W/m²) |
| Resolution | 0.001 mW/cm² / 0.01 W/m² |
| Operating Temperature | 0–50 °C (32–120 °F), non-condensing |
| Temperature Coefficient | ±1 %/°C (for solar UVB irradiance) |
| Cable | Retractable coaxial, 0.3–1.5 m |
| Dimensions | Ø40.6 mm × H45.8 mm |
| Weight | 200 g |
| Calibration | NIST-traceable, factory-calibrated for UVB irradiance (mW/cm² and W/m²) |
