Showing 1–30 of 453 results
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | OEM Manufacturer |
| Instrument Type | Vickers Hardness Tester |
| Measurement Range | 0.001–6000 HV |
| Total Test Forces | 10, 25, 50, 100, 200, 300, 500, 1000 gf |
| Standards Compliance | GB/T 4340.2, JJG 151 |
| Objective Lenses | 10×, 40× |
| Total Optical Magnification | 100×, 400× (digital zoom up to ~1600×) |
| X-Y Motorized Stage | 50 mm × 50 mm travel, 185 mm × 140 mm platform, 50 kg load capacity |
| Maximum Specimen Height | 180 mm |
| Indenter-to-Column Distance | 130 mm |
| Dwell Time | 0–60 s (1 s increments) |
| Illumination | Adjustable LED brightness |
| Data Acquisition | Encoded digital measurement |
| Software Interface | Multilingual (English, Chinese, German, Spanish, Russian) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | 102XB Upright Metallurgical Microscope |
| Configuration | Upright |
| Image Analysis System | Not Included |
| Eyepieces | Widefield 10× (25 mm FOV), Widefield 10× (20 mm FOV) with 0.1 mm reticle scale |
| Objectives | 5×, 10×, 20×, 50× (Infinity-Corrected Plan Achromatic Long Working Distance) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic (China) |
| Model | 102XB-PC |
| Microscope Type | Upright |
| Image Analysis System | Not Included |
| Eyepieces | Widefield 10×/25 mm and 10×/20 mm with 0.1 mm reticle scale |
| Objectives | 5×/0.15 (WD 35 mm), 10×/0.28 (WD 35 mm), 20×/0.40 (WD 20 mm), 50×/0.55 (WD 13 mm) |
| Eyepiece Tube | 30° inclined trinocular head (interpupillary adjustment 50–75 mm) |
| Nosepiece | Four-position revolving nosepiece with centering adjustment |
| Stage | 190 × 140 mm mechanical stage, 50 × 40 mm travel range |
| Focus Mechanism | Coaxial coarse/fine focusing with rack-and-pinion drive |
| fine focus graduation | 2 µm |
| Filters | Slide-in green, blue, and neutral density filters |
| Illumination | 12 V / 50 W halogen lamp (AC 85–230 V), adjustable brightness, equipped with aperture and field diaphragms |
| Polarization System | Rotatable analyzer (0–360°), polarizer and analyzer both removable from optical path |
| Calibration Tool | 0.01 mm stage micrometer |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Upright Metallurgical Microscope |
| Eyepieces | Wide-Field 10× (Φ25 mm), Wide-Field 10× (Φ20 mm) with 0.1 mm reticle scale |
| Trinocular Head | 30° inclined hinge-type, interpupillary adjustment 50–75 mm |
| Objective Turret | Quadruple nosepiece with DIC slot |
| Infinity-Corrected Plan Objectives | 5×/0.10 (WD 29.4 mm), 10×/0.25 (WD 16 mm), 20×/0.40 (WD 10.6 mm), 40×/0.60 (WD 5.4 mm) |
| Mechanical Stage | Dual-layer, 190 × 160 mm, travel range 80 × 50 mm |
| Focus Mechanism | Coaxial coarse/fine focusing with rack-and-pinion drive |
| Condenser | NA 1.25 Abbe condenser with adjustable iris diaphragm and filter holder |
| Illumination | Reflected-light halogen illumination (adjustable aperture and field diaphragms) |
| Polarization System | Rotatable analyzer (0–360°), polarizer and analyzer both removable from optical path |
| Filter Set | Slide-in green, blue, and neutral density filters |
| Calibration Tool | 0.01 mm stage micrometer |
| Standard Accessories | Main unit, trinocular observation tube, pair of 10× eyepieces, four objectives (5×, 10×, 20×, 40×), 12 V halogen lamp, Abbe condenser, polarization kit, filter set, stage micrometer, certificate of conformity, warranty card, and user manual |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | 10XB-PC Upright Polarized Metallurgical Microscope |
| Eyepieces | Widefield 10× (25 mm FOV), Widefield 10× with 0.1 mm reticle graticule (20 mm FOV) |
| Objectives | 5×/0.1 (WD 29.4 mm), 10×/0.25 (WD 16 mm), 20×/0.4 (WD 10.6 mm), 40×/0.6 (WD 5.4 mm) |
| Tube | 30° inclined trinocular head (interpupillary adjustment 50–75 mm) |
| Nosepiece | Quadruple revolving nosepiece with DIC slot |
| Stage | Dual-layer mechanical stage (190 × 160 mm), travel range 80 × 50 mm |
| Focus | Coaxial coarse/fine focusing mechanism with rack-and-pinion drive |
| fine focus graduation | 2 µm |
| Condenser | N.A. 1.25 Abbe condenser with adjustable iris diaphragm and filter holder |
| Illumination | Reflected halogen illumination (with adjustable aperture and field diaphragms) |
| transmitted illumination | 12 V / 50 W halogen, AC 85–230 V, continuously variable brightness |
| Polarization System | Rotatable analyzer (0–360°), polarizer and analyzer both removable from optical path |
| Filters | Slide-in green, blue, and neutral density filters |
| Calibration Tool | 0.01 mm stage micrometer |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic (China) |
| Model | 11XB Research-Grade Upright Metallurgical Microscope with Transmitted/Reflected Light, Polarization, and Darkfield Capabilities |
| Configuration | Upright |
| Image Analysis System | Not Included |
| Eyepieces | Widefield 10× (23 mm field number), Widefield 10× (20 mm field number) with 0.1 mm reticle scale |
| Objectives | 5×, 10×, 20×, 50× (Infinity-Corrected Plan Apochromatic Long Working Distance) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China) |
| Model | 11XB-PC |
| Configuration | Inverted |
| Eyepieces | Widefield 10× (23 mm FOV), Graticule Eyepiece 10× (20 mm FOV) with 0.1 mm Divisions |
| Objectives | Infinity-Corrected Plan Apochromatic Long Working Distance: 5×/0.15 (WD 44 mm), 10×/0.30 (WD 44 mm), 20×/0.35 (WD 44 mm), 50×/0.50 (WD 44 mm) |
| Nosepiece | Four-Position Revolving Turret with DIC Slot and Centering Adjustment |
| Stage | 290 × 290 mm Mechanical Stage with 100 × 100 mm Travel Range and X/Y Rapid-Drive Mechanism |
| Focus System | Coaxial Coarse/Fine Focus |
| Fine Focus Graduation | 2 µm per Division |
| Z-Axis Vertical Travel | 150 mm |
| Illumination | Köhler Surface Illumination (12 V/50 W Halogen, AC 85–230 V, Continuous Brightness Control) + Telecentric Outline Illumination (12 V/50 W Halogen, AC 85–230 V) |
| Polarization System | Rotatable Analyzer (0–360°), Removable Polarizer and Analyzer |
| Display Interface | 0.5 µm Resolution Measurement Capability, Zero-Set Function, Axis Orientation Flip, Data Export (TTL-compatible Output) |
| Calibration Standard | 0.01 mm Stage Micrometer |
| Included Accessories | Main Unit, Trinocular Head (Upright Image, 30° Inclined, Interpupillary Adjustment 50–75 mm), Pair of 10× Eyepieces, Full Objective Set (5×, 10×, 20×, 50×), Two 12 V/50 W Halogen Lamps, Full Polarizing Kit, CCD Camera (Standard), 0.5× C-Mount Adapter, Documentation Set (Certificate of Conformance, Warranty Card, Manual) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | 300kN |
| Max Test Force | 300 kN |
| Force Measurement Range | 4–100% FS |
| Force Accuracy | ≤ ±1% |
| Stroke | 1,000 mm |
| Maximum Test Length (Gauge Length Extension) | 10 m |
| Piston Speed (No-Load) | ≥100 mm/min |
| Controlled Loading Speed | 0.5–80 mm/min |
| Control System | Electro-hydraulic servo with real-time PC-based closed-loop control |
| Display Interface | Industrial PC with LCD monitor and dedicated tensile testing software |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | 300kN Computer-Controlled Hydraulic Horizontal Tensile Testing Machine |
| Instrument Type | Hydraulic Tensile Testing Machine |
| Maximum Test Force | 300 kN |
| Force Measurement Range | 4–100% FS |
| Force Accuracy | ≤ ±1% FS |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Domestic |
| Model | 37XD Inverted Biological Microscope |
| Configuration | Trinocular |
| Observation Head | 30° inclined trinocular head, interpupillary distance adjustment range 48–75 mm |
| Eyepieces | Wide-field, high-eyepoint EW10×/22 mm |
| Objective Lenses | Infinity-corrected achromatic long-working-distance objectives — 4× (NA 0.10, WD 17.5 mm), 10× (NA 0.25, WD 8 mm), 20× (NA 0.40, WD 5.5 mm), 40× (NA 0.60, WD 3 mm) |
| Phase Contrast Objectives | PH10× (NA 0.25, WD 8 mm), PH20× (NA 0.40, WD 5.5 mm) |
| Nosepiece | Quadruple revolving nosepiece |
| Condenser | Long-working-distance condenser (NA 0.30, WD 72 mm) |
| Stage | Flat mechanical stage (160 × 250 mm) |
| Focus Mechanism | Coaxial coarse/fine focusing via nosepiece vertical movement |
| Illumination | 6 V / 30 W halogen lamp |
| Filters | 45 mm blue filter and ground glass diffuser |
| Phase Annuli | 10×–20× phase contrast annulus |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | 4XB Dual-Eyepiece Inverted Metallurgical Microscope |
| Configuration | Inverted |
| Image Analysis System | Not Integrated |
| Total Magnification Range | 100×–1000× |
| Eyepieces | Wide-Field 10× |
| Objectives | Achromatic 10×, 40× (Plan), 100× Oil Immersion |
| Objective Working Distances (mm) | 7.31, 0.65, 0.37 |
| Numerical Apertures | 0.25, 0.65, 1.25 |
| Mechanical Tube Length | 160 mm |
| Coarse/Fine Focus Travel | 7 mm total (graduated at 0.002 mm per division) |
| coarse focus range | 7 mm |
| Mechanical Stage Dimensions | 75 × 50 mm |
| Base Platform Size | 150 × 150 mm |
| X–Y travel range | 30 × 30 mm |
| Illumination | 6 V / 12 W halogen lamp with adjustable brightness, AC 220 V (50 Hz) |
| Filter Set | Yellow, Green, Blue, Ground Glass |
| Net Weight | 5 kg |
| Packing Dimensions | 360 × 246 × 350 mm |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted |
| Total Optical Magnification | 100×–1000× (up to 1600× with optional eyepieces) |
| Eyepieces | 10× wide-field (18 mm field number), adjustable diopter |
| Objective Lenses | 10×/0.25, 20×/0.40, 40×/0.60, 100×/1.25 (oil immersion), working distances: 8.8 mm, 8.6 mm, 3.7 mm, 0.44 mm |
| Mechanical Tube Length | 160 mm |
| Coaxial Coarse/Fine Focus | 30 mm travel, fine focus graduation 2 µm |
| Stage | Dual-layer mechanical stage (180 × 150 mm), 15 × 15 mm travel range, aperture options: Ø10 mm / Ø20 mm |
| Illumination | Köhler illumination with 6 V / 20 W halogen lamp, continuously variable brightness |
| Power Input | 220 V / 50 Hz (optional 110 V / 60 Hz) |
| Compliance | Designed for ISO 9001-manufactured quality control environments |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted Metallurgical Microscope |
| Model | 4XC-D |
| Optical Total Magnification | 100×–1000× (up to 1600× with optional eyepiece/camera configuration) |
| Eyepieces | 10× wide-field (18 mm field number), adjustable diopter |
| Objectives | 10×/0.25, 20×/0.40, 40×/0.60, 100×/1.25 (oil immersion), WD = 8.8 mm / 8.6 mm / 3.7 mm / 0.44 mm |
| Mechanical Tube Length | 160 mm |
| Coaxial Coarse/Fine Focus | 30 mm travel, fine focus graduation 2 µm |
| Stage | Dual-layer mechanical stage, 180 × 150 mm base, 15 × 15 mm travel range, aperture options Ø10 mm / Ø20 mm |
| Illumination | Köhler illumination, 6 V / 20 W halogen lamp, continuously adjustable brightness |
| Power Supply | 220 V / 50 Hz (optional 110 V / 60 Hz) |
| Compliance | Designed for ISO 9001-aligned manufacturing and ASTM E3–22 specimen evaluation workflows |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted |
| Optical Total Magnification | 100×–1000× (Optional Extended to 1600×) |
| Eyepieces | 10× wide-field (18 mm field number) |
| Objectives | 10×/0.25, 20×/0.40, 40×/0.60, 100×/1.25 (oil immersion) |
| Working Distances | 8.8 mm, 8.6 mm, 3.7 mm, 0.44 mm |
| Focusing | Coaxial coarse/fine adjustment |
| Fine focus graduation | 2 µm |
| Stage | Dual-layer mechanical stage (180 × 150 mm), travel range 15 × 15 mm |
| Illumination | Köhler illumination with 6 V / 20 W halogen lamp, intensity adjustable |
| Power Supply | 220 V / 50 Hz (optional 110 V / 60 Hz) |
| Tube | Inverted trinocular head, 30° inclination, interpupillary adjustment 53–75 mm, diopter compensation |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted |
| Optical Total Magnification | 100×–1000× (Optional Extended to 1600×) |
| Eyepieces | 10×, Field Number 18 mm |
| Objective Lenses | 10×/0.25, 20×/0.40, 40×/0.60, 100×/1.25 (Oil Immersion), Working Distances: 8.8 mm, 8.6 mm, 3.7 mm, 0.44 mm |
| Trinocular Head | Inclined 30°, Interpupillary Adjustment 53–75 mm, Diopter Adjustable |
| Fine Focus Resolution | 2 µm |
| Mechanical Stage | 180 × 150 mm, Travel Range 15 × 15 mm |
| Köhler Illumination | 6 V / 20 W Halogen Lamp, Brightness Continuously Adjustable |
| Power Supply | 220 V / 50 Hz (Optional 110 V / 60 Hz) |
| Tube Length | 160 mm |
| Compliance | Designed for ISO 9001-manufactured optical instrumentation environments |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted |
| Optical Total Magnification | 100×–1000× (Optional Extended to 1600×) |
| Eyepieces | 10×, Field Number 18 mm |
| Objectives | 10×/0.25, 20×/0.40, 40×/0.60, 100×/1.25 (Oil Immersion), Working Distances: 8.8 mm, 8.6 mm, 3.7 mm, 0.44 mm |
| Focusing | Coaxial coarse/fine adjustment, Fine Focus Graduation: 2 µm |
| Stage | Dual-layer mechanical stage, 180 × 150 mm base, 15 × 15 mm travel range |
| Illumination | Köhler illumination, 6 V / 20 W halogen lamp, adjustable brightness |
| Power Supply | 220 V / 50 Hz (optional 110 V / 60 Hz) |
| Tube | Inverted trinocular head, 30° inclination, interpupillary adjustment 53–75 mm, diopter adjustment available |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Upright (Note: “Inverted” in source is inconsistent with standard 4XI configuration |
| Model | 4XI Monocular Metallurgical Microscope |
| Total Magnification | 100×–1000× or 125×–1250× |
| Eyepieces | 10× (Field Number 18) or 12.5× (Field Number 15) |
| Objectives | 10×, 40× (Plan Achromat), 100× Oil Immersion |
| Mechanical Tube Length | 160 mm |
| Working Distances | 7.31 mm, 0.65 mm, 0.37 mm |
| Numerical Apertures | 0.25, 0.65, 1.25 |
| Fine Focus Graduation | 0.002 mm |
| Coarse Focus Travel | 7 mm |
| Stage Dimensions | 75 × 50 mm (Mechanical Stage), 150 × 150 mm (Base Platform) |
| X–Y Translation Range | 30 × 30 mm |
| Illumination | 6 V / 12 W Halogen Lamp (Brightness Adjustable, AC 220 V / 50 Hz) |
| Filter Set | Yellow, Green, Blue, Ground Glass |
| Net Weight | 5 kg |
| Packing Dimensions | 360 × 246 × 350 mm |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted |
| Total Magnification | 100×–1000× (optional up to 1600×) |
| Eyepieces | WF10×/22 mm, WF10×/20 mm with crosshair reticle and 0.1 mm scale |
| Objective Lenses | 50×, 80×, 100× (optional) |
| Optical Design | Köhler illumination, polarizing optics with rotatable analyzer (0–360°), removable polarizer/analyzer, adjustable aperture & field diaphragms |
| Stage | Dual-layer mechanical stage (242 × 172 mm), 75 × 50 mm travel range, central circular stage Ø110 mm |
| Focus Mechanism | Coaxial coarse/fine focus with gear-box drive |
| fine focus graduation | 2 µm |
| Illumination | 12 V / 30 W halogen lamp, AC 85–230 V input |
| Filters | Yellow, green, blue interference filters |
| Calibration Tool | 0.01 mm stage micrometer |
| Standard Accessories | Host unit, observation tube, pair of WF10× eyepieces, 0.01 mm micrometer slide, plan apochromatic objectives (4×, 10×, 20×, 40×), full polarizing kit, filter set, spare halogen bulb, certificate of conformity, warranty card, operation manual |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | 5XB-PC Inverted Polarizing Metallurgical Microscope |
| Configuration | Inverted |
| Optical Total Magnification | 100×–1000× |
| Optional Total Magnification | 1600× |
| Eyepieces | 10×, Field Number 18 mm |
| Objectives | 10×, 20×, 40×, 100× (oil immersion optional) |
| Head | 45° inclined trinocular head (interpupillary distance 50–75 mm) |
| Nosepiece | Quadruple revolving nosepiece |
| Objective Specifications | Plan metallurgical objectives — 4×/0.10 (W.D. 25 mm), 10×/0.25 (W.D. 11 mm), 20×/0.40 (W.D. 9 mm), 40×/0.60 (W.D. 3.8 mm) |
| Stage | Dual-layer mechanical stage (242 × 172 mm), travel range 75 × 50 mm, central circular stage Φ110 mm |
| Focus Mechanism | Coaxial coarse/fine focusing with gear-driven fine adjustment (graduation: 2 µm per division) |
| Illumination | Reflected Köhler illumination with adjustable aperture and field diaphragms |
| Polarization System | Rotatable analyzer (0–360°), polarizer and analyzer both removable from optical path |
| Filter Set | Yellow, green, blue interference filters |
| Calibration Tool | 0.01 mm micrometer scale |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Upright Metallurgical Microscope |
| Model | 6XB |
| Eyepieces | WF10× (18 mm field of view) |
| Objectives | PL5× (NA 0.12, WD 18.3 mm), PL10× (NA 0.25, WD 8.9 mm), PL40× (NA 0.60, WD 3.7 mm), PL60× (NA 0.75, WD 0.96 mm) |
| Focusing Mechanism | Coaxial coarse/fine focus with 2 μm fine-focus graduation, adjustable coarse-focus tension, locking and travel-limiting mechanism |
| Stage | Dual-layer mechanical stage (186 × 142 mm, 75 × 50 mm travel range) |
| Illumination | 6 V / 20 W halogen transmitted & reflected Köhler illumination system with adjustable brightness, field diaphragm, aperture diaphragm, and built-in polarizer |
| Viewing Head | 30° inclined binocular tube with integrated rotatable analyzer for polarized light observation |
| Scale Resolution | Vernier scale with 0.1 mm reading accuracy |
| Standard Accessories | One unit main frame, one observation head, one pair WF10× eyepieces, four plan achromat objectives (5×, 10×, 40×, 60×), one 6 V / 20 W halogen lamp, certificate of conformity, warranty card, and user manual |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | 6XB-PC Upright Metallurgical Microscope |
| Configuration | Upright (not inverted) |
| Image Analysis System | Not included (standalone imaging interface only) |
| Total Optical Magnification Range | 100×–1000× (standard) |
| Eyepieces | Wide-field 10× (18 mm field number) |
| Objective Lenses | Plan Achromatic, long-working-distance, coverslip-free: 5× (NA 0.12, WD 18.3 mm), 10× (NA 0.25, WD 8.9 mm), 40× (NA 0.60, WD 3.7 mm), 60× (NA 0.75, WD 0.96 mm) |
| Focusing Mechanism | Coaxial coarse/fine focus |
| fine focus graduation | 2 µm |
| Stage | Dual-layer mechanical stage (186 mm × 142 mm) |
| X–Y travel range | 75 mm × 50 mm |
| Illumination | 6 V / 20 W halogen transmitted & reflected Köhler illumination system |
| Eyepiece Tube | Inclined 30° binocular tube with internal analyzer for polarized light observation |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Upright |
| Model | 6XD Upright Polarizing Metallurgical Microscope |
| Eyepieces | Widefield 10× (18 mm FOV), 10× reticle eyepiece with 0.1 mm graduated scale |
| Objectives | 4×/0.10 WD 25 mm, 10×/0.25 WD 11 mm, 20×/0.40 WD 9 mm, 40×/0.60 WD 3.8 mm |
| Binocular Head | 30° inclined hinge-type, interpupillary adjustment 50–75 mm |
| Nosepiece | Quadruple revolving nosepiece |
| Stage | 140 × 140 mm mechanical stage with 75 × 50 mm travel range |
| Focus Mechanism | Coaxial coarse/fine focusing |
| fine focus graduation | 2 µm per division |
| Illumination | Dual-path halogen lighting — transmitted (6 V/20 W, AC 85–230 V) and reflected (6 V/20 W, AC 85–230 V), both intensity-adjustable |
| Polarizing System | Rotatable analyzer (0–360°), removable polarizer and analyzer, stress-free optical path design |
| Condenser | N.A. 1.25 Abbe condenser with adjustable iris diaphragm and slide-in green/blue/yellow filters |
| Accessories Included | 0.01 mm stage micrometer, two 6 V/20 W halogen bulbs, full polarizing kit, filter set, CCD camera (1×), 0.5× C-mount adapter, documentation set |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Upright |
| Total Magnification Range | 40×–400× |
| Eyepieces | 10× (Field Number 18) |
| Objective Lenses | 4× (NA 0.10, WD 17.91 mm), 10× (NA 0.25, WD 6.54 mm), 20× (NA 0.40, WD 1.05 mm), 40× (NA 0.65, WD 0.736 mm) |
| Nosepiece | Quadruple Revolving |
| Stage Dimensions | 350 mm × 255 mm, Travel Range: 200 mm × 200 mm |
| Focusing Mechanism | Coarse/Fine Combined, 25 mm Vertical Travel, Fine Focus Graduation: 2 µm per division, 0.2 mm per revolution |
| Illumination | 6 V / 20 W Halogen Lamp with Built-in Continuous Intensity Control |
| Mounting Medium | Dry |
| Optional Accessories | Long Working Distance Objectives (50×, 80×, 100×), Digital Camera Adapters, 12.5× or Reticle Eyepieces |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Inverted Metallurgical Microscope |
| Total Magnification Range | 40×–400× |
| Eyepieces | 10× (Field Number 18) |
| Objective Lenses | 4×, 10×, 20×, 40× (Dry, Finite Conjugate) |
| Numerical Apertures | 0.10, 0.25, 0.40, 0.65 |
| Working Distances | 17.91 mm, 6.54 mm, 1.05 mm, 0.736 mm |
| Stage Dimensions | 350 mm × 255 mm |
| Stage Travel Range | 200 mm × 200 mm |
| Coarse/Fine Focus Travel | 25 mm total |
| Fine Focus Graduation | 2 µm per division, 0.2 mm per revolution |
| Illumination | 6 V / 20 W Halogen Lamp with Built-in Continuous Intensity Control |
| Nosepiece | Quadruple Revolving Turret |
| Tube | Trinocular (Photo Port Enabled) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Upright Metallurgical Microscope |
| Eyepieces | WF10× (25 mm FOV), WF10× (20 mm FOV) with 0.1 mm十字 crosshair reticle |
| Nosepiece | Five-position brightfield/darkfield turret with DIC slots |
| Objectives | Plan infinity-corrected BF/DF objectives — 5×/0.1 BD, WD 29.4 mm |
| Stage | Dual-layer mechanical stage (350 × 310 mm base, 250 × 250 mm travel range) |
| Focus Mechanism | Coaxial coarse/fine focus with rack-and-pinion drive |
| fine focus graduation | 2 µm |
| Illumination | Episcopic halogen lamp (12 V / 100 W), AC 85–230 V, adjustable intensity, equipped with aperture and field diaphragms |
| Polarization System | Rotatable analyzer (0–360°), removable polarizer and analyzer |
| Filters | Slide-in blue, green, neutral density filters |
| Calibration Tool | 0.01 mm stage micrometer |
| Standard Accessories | Microscope body, observation tube, pair of WF10× eyepieces, four BF/DF objectives (5×, 10×, 20×, 40×), one 12 V / 100 W halogen bulb, full polarization kit, filter set, calibration micrometer, certificate of conformity, warranty card, and user manual |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic (China) |
| Model | 8XB-PC |
| Configuration | Inverted |
| Eyepieces | WF10× (25 mm FOV), WF10× (20 mm FOV) with 0.1 mm crosshair reticle |
| Objectives | 5×/0.1 BD (W.D. 29.4 mm), 10×/0.25 BD (W.D. 16 mm), 20×/0.40 BD (W.D. 10.6 mm), 40×/0.60 BD (W.D. 5.4 mm) |
| Stage | Dual-layer mechanical stage (350 × 310 mm, travel range 250 × 250 mm) |
| Illumination | Reflected Köhler illumination with adjustable 12 V / 100 W halogen lamp, aperture & field diaphragms |
| Focus Mechanism | Coaxial coarse/fine focusing, rack-and-pinion drive, fine focus graduation: 2 µm |
| Polarization System | Rotatable analyzer (0–360°), removable polarizer and analyzer |
| Filters | Insert-type blue, green, neutral density |
| Accessories Included | 0.01 mm stage micrometer, 0.5× C-mount adapter, USB digital camera (basic resolution), polarizing kit, filter set, documentation set |
| Optional | Long-working-distance BD objectives (50×, 80×, 100×), high-resolution digital cameras (2–12 MP), DIC modules (10×, 20×, 40×, 100×), research-grade image analysis software, C-mount adapters for DSLR/mirrorless systems |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | 9XB Upright Polarizing Metallurgical Microscope |
| Configuration | Upright |
| Image Analysis System | Not Included |
| Eyepieces | Widefield 10× (22 mm field number), Widefield 10× (20 mm field number) with 0.1 mm reticle scale |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | 9XB-PC Upright Polarizing Metallurgical Microscope |
| Microscope Orientation | Upright |
| Image Analysis System | Not Included |
| Eyepieces | Widefield 10× (22 mm field number), Widefield 10× with 0.1 mm reticle scale |
| Objectives | 10×/0.25 (WD 16 mm), 20×/0.4 (WD 10.6 mm), 40×/0.6 (WD 5.4 mm) |
| Binocular Tube | 30° inclined hinge-type trinocular head (interpupillary adjustment 55–75 mm) |
| Nosepiece | Quadruple revolving nosepiece |
| Stage | Dual-layer mechanical stage (180 × 150 mm, 75 × 50 mm travel range) |
| Focus Mechanism | Coaxial coarse/fine focusing with rack-and-pinion drive |
| fine focus graduation | 2 µm |
| Condenser | N.A. 1.25 Abbe condenser with adjustable iris diaphragm and filter holder |
| Illumination | Reflected Köhler illumination with adjustable aperture and field diaphragms |
| transmitted illumination | 12 V / 30 W halogen lamp, AC 85–230 V, continuously variable brightness |
| Polarization System | Rotatable analyzer (0–360°), polarizer and analyzer both removable from optical path |
| Filter Holder | Slide-in green, blue, and neutral density filters |
| Calibration Tool | 0.01 mm stage micrometer |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic (China) |
| Model | AMM-200D |
| Microscope Type | Upright (not inverted) |
| Image Analysis System Included | No |
| Eyepieces | Widefield 10× (18 mm field number), Widefield 16× (11 mm field number) |
| Objectives | Plan Achromatic, Cover-Slip-Free: 4×/NA 0.10, 10×/NA 0.25, 40×/NA 0.65 (Spring-Loaded), 63×/NA 0.85 (Spring-Loaded) |
| Mechanical Stage | 160 × 130 mm, Travel Range 76 × 50 mm, Vernier Resolution 0.1 mm |
| Nosepiece | Ball-Bearing Quadruple Revolving Nosepiece |
| Focus Mechanism | Coaxial Coarse/Fine Focus, Total Travel 40 mm, Fine Focus Graduation 2 µm |
| Illumination | Reflected (Epi-) Illuminator with 6 V / 20 W Halogen Lamp, Dual Voltage Input (110 V / 220 V), Adjustable Brightness, Optional Color Filters (Light Blue, Light Green) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Region of Origin | Domestic (China) |
| Model | AMM-200P |
| Microscope Type | Upright (not inverted) |
| Image Analysis System Included | No |
| Eyepieces | Widefield 10× (18 mm field number), Widefield 16× (11 mm field number) |
| Objectives | Plan Achromatic, Cover-Slip-Free: 4×/NA 0.10, 10×/NA 0.25, 40×/NA 0.65 (Spring-Loaded), 63×/NA 0.85 (Spring-Loaded) |
| Mechanical Stage | 160 × 130 mm, X–Y Travel 76 × 50 mm, Vernier Scale Resolution: 0.1 mm |
| Nosepiece | Ball-Bearing Mounted Quadruple Revolving Nosepiece |
| Focus Mechanism | Coaxial Coarse/Fine Adjustment, Total Travel: 40 mm, Fine Focus Graduation: 0.002 mm |
| Illumination | Vertical Epifluorescence-Compatible Reflected-Light Illuminator, Dual-Voltage (110 V / 220 V AC), 6 V / 20 W Halogen Lamp with Adjustable Brightness and Interchangeable Color Filters (Light Blue, Light Green) |
